Gear Hsg (Prop Shaft) Design I for Mercury / Mariner (6 / 8 HP 9.9 / 15 HP) Engine
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]
| # — 8833A10 — GEAR HOUSING, COMPLETE (LONG) (BLACK) (1 required per assembly) | ||
  |
1666-8833A10 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
1666-8833A15 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
|
1666-8833T15 - Gear Housing Assembly [ More info ]
|
| # — 42364A92 — ENGINE/POWERHEAD GASKET SET (1 required per assembly) | ||
  |
|
27-42364A92 - Engine Gasket Set [ More info ]
|
| # — 8833A12 — GEAR HOUSING, COMPLETE (LONG) (GRAY) (1 required per assembly) | ||
  |
1666-8833A12 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
1666-8833A16 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
|
1666-8833T16 - Ord 1666-8833T15, NLA [ More info ] Unavailable |
| # — 8833A 9 — GEAR HOUSING, COMPLETE (SHORT) (BLACK) (1 required per assembly) | ||
  |
1666-8833A 9 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
1666-8833A13 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
|
1666-8833T13 - Gear Housing Assembly [ More info ]
|
| # — 41365A 3 — DRIVESHAFT HOUSING SEAL KIT (1 required per assembly) | ||
  |
|
26-41365A 3 - Seal Kit [ More info ]
|
| # — 8833A11 — GEAR HOUSING, COMPLETE (SHORT) (GRAY) (1 required per assembly) | ||
  |
1666-8833A11 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
1666-8833A14 - Gear Housing Assembly [ More info ] Unavailable |
|
  |
|
1666-8833T14 - Gear Housing - Short-g, NLA [ More info ] Unavailable |
| #1 — 8833A 1 — GEAR HOUSING (BLACK) (1 required per assembly) | ||
  |
|
1666-8833A 1 - Ord Complete Housing, NLA [ More info ] Unavailable |
| #1 — 8833A 4 — GEAR HOUSING (GRAY) (1 required per assembly) | ||
  |
|
1666-8833A 4 - Gear Housing -Basic-gr [ More info ] Unavailable |
| #41 — 13403 — SCREW (1 required per assembly) | ||
  |
10-13403 - SCREW [ More info ] Unavailable |
|
  |
|
10-824071 10 - Screw W/Washer [ More info ]
|
| #42 — 13402 — SCREW (2 required per assembly) | ||
  |
10-13402 - Screw [ More info ] Unavailable |
|
  |
|
10-824071 7 - Screw [ More info ]
|
| #43 — 41347A 1 — ROLLER BEARING (1 required per assembly) | ||
  |
31-41347A 1 - Tapered Roller Bearing [ More info ] Unavailable |
|
  |
|
31-821321A 1 - Bearing Kit [ More info ]
|
| #44 — 41371A 1 — FORWARD GEAR (1 required per assembly) | ||
  |
|
43-41371A 1 - Forward Gear [ More info ]
|
| #45 — 41367 — BUSHING (1 required per assembly) | ||
  |
|
23-41367 - Bushing [ More info ]
|
| #46 — 813139 — CAM FOLLOWER (1 required per assembly) | ||
  |
|
813139 - Cam Follower [ More info ]
|
| #47 — 32449 — RETAINING RING (1 required per assembly) | ||
  |
|
53-32449 - Retaining Ring [ More info ]
|
| #48 — 43217 — CLUTCH (1 required per assembly) | ||
  |
|
52-43217 - Clutch [ More info ]
|
| #49 — 30535 — CROSS PINT (1 required per assembly) | ||
  |
|
17-30535 - Cross Pin - Ratchet To Propeller Shaft,NLA [ More info ]
|
| #50 — 42204 — SPRING (1 required per assembly) | ||
  |
|
24-42204 - Spring [ More info ]
|
| #51 — 41370 — PROPELLER SHAFT (1 required per assembly) | ||
  |
|
44-41370 - Prop Shaft [ More info ]
|
| #52 — 44115 — REVERSE GEAR (1 required per assembly) | ||
  |
43-44115 - REVERSE GEAR [ More info ] Unavailable |
|
  |
|
43-44115T - Reverse Gear [ More info ]
|
| #53 — 42144A 2 — BEARING CARRIER (1 required per assembly) | ||
  |
42144A 2 - Bearing Carrier [ More info ] Unavailable |
|
  |
|
42144T 2 - Bearing Carrier [ More info ]
|
| #54 — 33145 — O-RING (1 required per assembly) | ||
  |
25-33145 - O-ring, (1.984 X .139) [ More info ] Unavailable |
|
  |
|
18-7162-9 - (PK5) O-Ring 25-33145 [ More info ]
|
  |
|
25-8M0214923 - O RING, sold individually [ More info ]
|
| #55 — 41368 — BUSHING (1 required per assembly) | ||
  |
|
23-41368 - Bushing [ More info ]
|
| #56 — 66022 — OIL SEAL (1 required per assembly) | ||
  |
|
26-66022 - Seal - Priced Individually [ More info ]
|
  |
|
18-0584 - Seal, 26-66022 [ More info ]
|
| #57 — 42037 — THRUST HUB (1 required per assembly) | ||
  |
|
42037 - Thrust Washer [ More info ] Unavailable |
| #58 — 42201 — CAP (1 required per assembly) | ||
  |
|
42201 - Cap, NLA [ More info ]
|
| #59 — 42522A12 — PROPELLER (9" X 9") (1 required per assembly) | ||
  |
48-42522A12 - ALUM 9.00X9.00 [ More info ] Unavailable |
|
  |
|
48-828156A12 - Propeller, Black Max 9R9 [ More info ]
|
  |
|
Solas Amita 3 Blade Aluminum 9P Mercury 1111-093-09 [ More info ]
|
| #59 — 17874A12 — PROPELLER (9" X 10-1/2") (1 required per assembly) | ||
  |
48-17874A12 - Prop, Aluminum 9.00X10.5 [ More info ] Unavailable |
|
  |
|
48-828158A12 - Propeller, Black Max 9R10 1/2 [ More info ]
|
  |
|
Solas Amita 3 Blade Aluminum 10P Mercury 1111-093-10 [ More info ]
|
| #59 — 42524A12 — PROPELLER (SAILPOWER) (1 required per assembly) | ||
  |
48-42524A12 - Prop, Aluminum 9.75 X 6.50 [ More info ] Unavailable |
|
  |
|
48-828150A12 - Propeller, Black Max 9 3/4 R 6 1/2 [ More info ]
|
| #60 — 42091 — SPACER (1 required per assembly) | ||
  |
23-42091 - Spacer [ More info ] Unavailable |
|
  |
|
23-420911 - SPACER [ More info ] Unavailable |
| #61 — 13914 — PROPELLER NUT (1 required per assembly) | ||
  |
11-13914 - Nut (M10 X 1.5) [ More info ] Unavailable |
|
  |
|
11-40140 - Nut, (M10) [ More info ]
|
