Carburetor Assembly Wmc 17\17b\17c,18\18a\18b, 20 / 20a / 20b,23 for Mercury / Mariner (6 / 8 HP 9.9 / 15 HP) Engine
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]
| #1 — 9503A11 — CARBURETOR (6)(WMC-20B) (1 required per assembly) | ||
  |
1392-9503A11 - Carburetor [ More info ] Unavailable |
|
  |
|
1392-9503A13 - 1392-9503A13 - CARBURETOR [ More info ] Unavailable Replaced by 1392-9503A15 |
  |
1392-9503A15 - Carburetor [ More info ] Unavailable |
|
  |
1392-9503A20 - Carburetor [ More info ] Unavailable |
|
  |
|
1392-9503T21 - Carburetor [ More info ] Unavailable |
| #1 — 9266A12 — CARBURETOR (8)(WMC-18B) (1 required per assembly) | ||
  |
1392-9266A12 - Carburetor [ More info ] Unavailable |
|
  |
1392-9266A14 - Carburetor [ More info ] Unavailable |
|
  |
1392-9266A16 - Carburetor [ More info ] Unavailable |
|
  |
1392-9266A21 - Carburetor [ More info ] Unavailable |
|
  |
|
1392-9266T22 - Carburetor [ More info ]
|
| #1 — 8846A14 — CARBURETOR (9.9)(WMC-23) (1 required per assembly) | ||
  |
1392-8846A14 - Carburetor [ More info ] Unavailable |
|
  |
|
1392-8846A24 - Carburetor Kit [ More info ] Unavailable |
| #2 — 9473 — THROTTLE VALVE (1 required per assembly) | ||
  |
|
1395-9473 - Throttle Valve [ More info ]
|
| #2 — 815133 — THROTTLE VALVE (WMC-23) (1 required per assembly) | ||
  |
|
815133 - VALVE-THROTTLE,NLA [ More info ] Unavailable |
| #3 — 9472 — THROTTLE SHAFT (WMC-17/18/20) (1 required per assembly) | ||
  |
1395-9472 - Throttle Shaft [ More info ] Unavailable |
|
  |
1395-9698 - SHAFT-THROTTLE [ More info ] Unavailable |
|
  |
|
1395-804707 - Throttle Shaft [ More info ] Unavailable |
| #3 — 9698 — SHAFT (WMC-17C/18A/18B/20A/20B) (1 required per assembly) | ||
| #3 — 813022 — SHAFT (WMC-23)(INCL.SCREW/SPRING) (1 required per assembly) | ||
  |
|
813022 - Throttle Shaft [ More info ]
|
| #4 — 9164 — FUEL BOWL (1 required per assembly) | ||
  |
|
1395-9164 - Fuel Bowl [ More info ]
|
| #5 — 9169 — FLOAT (1 required per assembly) | ||
  |
1395-9169 - Float [ More info ] Unavailable |
|
  |
|
1395-9169 1 - Float [ More info ]
|
| #6 — 9855 — INLET NEEDLE VALVE (1 required per assembly) | ||
  |
1395-9855 - Valve-Inlet [ More info ] Unavailable |
|
  |
1395-879194048 - VALVE-INLET [ More info ] Unavailable |
|
  |
|
1395-803861 - Inlet Valve [ More info ]
|
| #7 — 5315 — MAIN FUEL JET (0.42)(6) (1 required per assembly) | ||
  |
|
1399-5315 - Jet -.042 - See Note On Detail Page [ More info ] Unavailable |
| #7 — 5317 — MAIN FUEL JET (.046)(8) (1 required per assembly) | ||
  |
|
1399-5317 - Jet -.046 [ More info ]
|
| #7 — 5213 — MAIN FUEL JET (.056)(9.9) (1 required per assembly) | ||
  |
|
1399-5213 - Jet -.056 [ More info ]
|
| #7 — 6359 — MAIN FUEL JET (.052)(9.9) (1 required per assembly) | ||
  |
|
1395-6359 - Jet -.052 [ More info ]
|
| #8 — 9171 — PLUG, JET RETAINER (1 required per assembly) | ||
  |
|
1395-9171 - Plug [ More info ]
|
| #9 — 813618 — COVER, DIAPHRAGM (1 required per assembly) | ||
  |
|
813618 - Cover [ More info ] Unavailable |
| #10 — 9174 — SCREW( WMC-17/18/20) (4 required per assembly) | ||
  |
1395-9174 - Screw Assembly, NLA [ More info ] Unavailable |
|
  |
|
1395-9697 - Screw Assembly [ More info ] Unavailable |
| #10 — 9697 — SCREW (WMC-17B/17C/18A/18B/10A/20B/23) (4 required per assembly) | ||
| #11 — 15827A 1 — FUEL PUMP KIT (1 required per assembly) | ||
  |
|
15827A 1 - ORD1395-9702 [ More info ] Unavailable |
| #12 — 9643 — SCREW, FUEL PUMP COVER (5 required per assembly) | ||
  |
|
1395-9643 - Screw Assembly [ More info ]
|
| #13 — 9177 — PLATE (WMC-17/18/20) (1 required per assembly) | ||
  |
|
1395-9177 - Plate [ More info ] Unavailable |
| #13 — 9699 — PLATE (WMC-17B/17C/18A/18B/20A/20B/23) (1 required per assembly) | ||
  |
|
1395-9699 - Cover Plate [ More info ] Unavailable |
| #14 — 9172 — SCREW (WMC-17/18/20) (2 required per assembly) | ||
  |
1395-9172 - Screw Assembly [ More info ] Unavailable |
|
  |
|
1395-9696 - Screw Assembly [ More info ] Unavailable |
| #14 — 9696 — SCREW (WMC-17B/17C/18A/18B/20A/20B/23) (2 required per assembly) | ||
| #15 — 9725 — GASKET/DIAPHRAGM KIT (1 required per assembly) | ||
  |
1395-9725 - Carburetor Gasket And Diaphragm Kit [ More info ] Unavailable |
|
  |
|
1300-36004 - Carburetor Kit - Mercury 1395-9761 1 [ More info ]
|
  |
|
1395-9761 1 - Gasket and Diaphragm Kit [ More info ]
|
  |
|
18-7212 - Carburetor and Fuel Pump Diaphragm Kit, 1395-9761 1 [ More info ]
|
| #16 — 9648 — REPAIR PARTS KIT (1 required per assembly) | ||
  |
1395-9648 - Carburetor Repair Kit [ More info ] Unavailable |
|
  |
|
1395-9648 1 - Carburetor Repair Kit [ More info ] Unavailable |
| #16 — 813023 — REPAIR PARTS KIT(WMC-23) (1 required per assembly) | ||
  |
813023 - Carburetor Repair Kit [ More info ] Unavailable |
|
  |
|
1395-823707 2 - Carburetor Repair Kit, Float NOT included [ More info ]
|
  |
|
18-97350 - Carb Kit, Mercury 1395-823707 2, Float Not Included [ More info ]
|
| #17 — 9637 — COVER, FUEL PUMP (1 required per assembly) | ||
  |
|
1395-9637 - Cover [ More info ]
|
| #18 — 9762 — PLUG (1 required per assembly) | ||
  |
|
1395-9762 - Plug [ More info ] Unavailable |
| #19 — 19206 1 — GASKET, CARBURETOR (1 required per assembly) | ||
  |
|
27-19206 1 - Gasket [ More info ]
|
| #19A — 9635 — DIAPHRAGM (1 required per assembly) | ||
  |
|
1395-9635 - Diaphragm [ More info ]
|
| #20 — 44554 1 — IDLE WIRE (1 required per assembly) | ||
  |
|
44554 1 - Wire - Idle [ More info ]
|
| #21 — 12805 3 — FAST IDLE LEVER (1 required per assembly) | ||
  |
|
12805 3 - Fast Idle Lever [ More info ]
|
| #22 — 12803 — PRIMER BRACKET (1 required per assembly) | ||
  |
|
12803 - Primer Bracket [ More info ]
|
| #23 — 97877 — PUSHNUT (1 required per assembly) | ||
  |
11-97877 - Nut, Push [ More info ] Unavailable |
|
  |
|
|
| #24 — 79964 — SCREW (1 required per assembly) | ||
  |
10-79964 - Screw [ More info ] Unavailable |
|
  |
|
10-12110 - Screw [ More info ]
|
| #25 — 11277 — SPRING (1 required per assembly) | ||
  |
|
24-11277 - Spring, Tension [ More info ]
|
| #26 — 40056110 — SCREW(M5X 8 X 30) (2 required per assembly) | ||
  |
|
10-40056110 - Screw [ More info ]
|
| #26 — 40001 8 — SCREW(M5 X 8 X 12) (2 required per assembly) | ||
  |
|
10-40001 8 - Screw - Priced Individually [ More info ]
|
| #27 — 79965 — SCREW (1 required per assembly) | ||
  |
|
10-79965 - Screw [ More info ]
|
| #28 — 11273 1 — PRIMER LEVER (1 required per assembly) | ||
  |
|
11273 1 - LEVER Primer [ More info ] Unavailable |
| #29 — 11280 — CAM BLOCK (1 required per assembly) | ||
  |
|
11280 - Cam Block [ More info ]
|
| #30 — 11278 — RETAINING CLIP (1 required per assembly) | ||
  |
|
53-11278 - Ring - Retaining [ More info ]
|
| #31 — 12804A 1 — CHOKE BEZEL (1 required per assembly) | ||
  |
|
12804A 1 - Bezel Assembly [ More info ]
|
| #32 — 12802 2 — PRIMER KNOB (1 required per assembly) | ||
  |
|
|
| #33 — 92799 — SCREW(SELF-TAPPING) (1 required per assembly) | ||
  |
|
10-92799 - Screw [ More info ]
|
| #34 — 40021 1 — NUT (1 required per assembly) | ||
  |
|
11-40021 1 - Nut [ More info ]
|
| #35 — 17442 — COVER (1 required per assembly) | ||
  |
|
17442 - Carburetor Cover [ More info ] Unavailable |
| #36 — 47579 — PLUG (1 required per assembly) | ||
  |
|
19-47579 - Plug - Priced Individually [ More info ]
|
  |
|
18-3232-9 - Plug, 19-47579, 5PK [ More info ]
|
| #37 — 823433 — ELECTRIC CHOKE (1 required per assembly) | ||
  |
|
1395-823433 - Solenoid [ More info ] Unavailable |
| #38 — 44426 — GASKET, ELECTRIC CHOKE (1 required per assembly) | ||
  |
|
27-44426 - Electric Choke Gasket [ More info ]
|
| #39 — 12970 — DECAL (SLOW/FAST) (1 required per assembly) | ||
  |
37-12970 - DECAL [ More info ] Unavailable |
|
  |
|
37-12970 1 - Decal [ More info ]
|
