Parts for Mercury Marine 9.8 (2 Cylinder) (International) Gear Housing (Driveshaft)

Revise Search: All Models > 9.8 (2 Cylinder) (International) > 0N007788 - 0N055109 > Gear Housing (Driveshaft)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

LOOKING FOR A PROP?
• Try our prop finder.

COMPLETE GEARCASE?
• Aftermarket gearcase may be available for less than $900 USD. 70 HP+ only. Please call.

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	853792A 5	REPAIR KIT, Water Pump (1 required per assembly)
		853792A 5 - Ord 46-803750A03, NLA [ More info ] Unavailable
		46-803750A03 - Water Pump Repair Kit [ More info ] $143.70 Available to Order: Shipping delay up to 10 days.
		46-47810 - Water Pump Kit with Housing, without Base [ More info ] $73.99 $56.59 2 In Stock.
#	1668-803729A 5	GEAR HOUSING ASSEMBLY, Complete (Short) (1 required per assembly)
		1668-803729A 5 - 1668-803729A 5 - GEAR HOUSING ASSE [ More info ] Unavailable Replaced by 1668-803729T11
		1668-803729T11 - 1668-803729T11 - GC 6-9.8 S INT L [ More info ] Unavailable Replaced by 1668-8M0070901
		16688M0070901 - Gearcase 6-9.8 2S SH [ More info ] Unavailable
		1600-8M0172380 - GC 6-9.8 2S SH [ More info ] Unavailable
#	27-804908A00	GASKET SET, Lower Unit (1 required per assembly)
		27-804908A00 - Lower Unit Gasket Set [ More info ] Unavailable
		27-8M0060176 - 27-8M0060176 - GASKET SET [ More info ] Unavailable Replaced by -804908A02
		27-804908A02 - Gasket Set [ More info ] Unavailable
		278M0065830 - Gasket Set [ More info ] Unavailable
		278M0082883 - Gasket Set [ More info ] Unavailable
		27-8M0130156 - Gasket Set [ More info ] $111.99 Available to Order: Shipping delay up to 10 days.
#	1668-803729A 6	GEAR HOUSING ASSEMBLY, Complete (Long) (1 required per assembly)
		1668-803729A 6 - 1668-803729A 6 - GEAR HOUSING ASSE [ More info ] Unavailable Replaced by 1668-803729T12
		1668-803729T12 - GC 6-9.8 LG INT L [ More info ] Unavailable
		16688M0070902 - GC 6-9.8 2S LG [ More info ] Unavailable
#1	1668-803729A 4	GEAR HOUSING ASSEMBLY, Basic (1 required per assembly)
		1668-803729A 4 - 1668-803729A 4 - GEAR HOUSING ASSE [ More info ] Unavailable Replaced by 1668-803729T04
		1668-803729T04 - ORD1668-803729A14 NLA [ More info ] Unavailable
#2	31-803675 3	BEARING, Needle (1 required per assembly)
		31-803675 3 - Bearing-Needle [ More info ] $35.49 Available to Order: Shipping delay up to 10 days.
#3	10-823042 30	BOLT (4 required per assembly)
		10-823042 30 - BOLT [ More info ] Unavailable
		10-879194265 - Bolt [ More info ] Unavailable
		108M0098606 - Bolt [ More info ] Unavailable
		10-8M0147119 - BOLT [ More info ] Unavailable
#4	22-95368 3	PLUG (2 required per assembly)
		22-95368 3 - Oil Plug [ More info ] Unavailable
#6	27-95220	GASKET (3 required per assembly)
		27-95220 - Plug Gasket [ More info ] Unavailable
		18-60103 - Gasket, Drain Plug 332600060M [ More info ] $1.99 $1.70 Available to Order: Shipping delay up to 10 days.
		8M0082880 - Seal - Priced Individually [ More info ] $6.09 10+ In Stock.
#7	823913	ANODE (1 required per assembly)
		823913 - Anode [ More info ] Unavailable
		97-823913Q - Anode, Aluminum [ More info ] $20.49 Available to Order: Shipping delay up to 10 days.
#8	10-16832	BOLT, (M6 x 16) (1 required per assembly)
		10-16832 - Bolt [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#9	45-803738 2	DRIVESHAFT (Short) (1 required per assembly)
		45-803738 2 - 45-803738 2 - DRIVESHAFT [ More info ] Unavailable Replaced by 45-803738015
		45-803738015 - 45-803738015 - DRIVESHAFT-SHORT [ More info ] Unavailable Replaced by 45-803738T15
		45-803738T15 - Drive Shaft [ More info ] Unavailable
#9	45-803738 3	DRIVESHAFT (Long) (1 required per assembly)
		45-803738 3 - 45-803738 3 - DRIVESHAFT [ More info ] Unavailable Replaced by 45-803738016
		45-803738016 - 45-803738016 - DRIVESHAFT-LONG [ More info ] Unavailable Replaced by 45-803738T16
		45803738T16 - Drive Shaft [ More info ] $118.49 Available to Order: Shipping delay up to 10 days.
#10	30-16132 6	BEARING, Ball (1 required per assembly)
		30-16132 6 - Bearing [ More info ] $24.89 Available to Order: Shipping delay up to 10 days.
#11	43-803740 1	GEAR, Pinion (1 required per assembly)
		43-803740 1 - Gear [ More info ] Unavailable
#12	47-803748 1	IMPELLER (1 required per assembly)
		47-803748 1-New # is 8M0214945 [ More info ] Unavailable
#13	17-95218 11	PIN, Roll - Stainless Steel (1 required per assembly)
		17-95218 11 - Pin, Roll - Stainless Steel [ More info ] $4.09 1 In Stock.
#14	46-803750 2	HOUSING, Water Pump - Upper (1 required per assembly)
		46-803750 2 - Water Pump Housing [ More info ] Unavailable
		46-803750A02 - Water Pump Upper Housing [ More info ] $69.49 Available to Order: Shipping delay up to 10 days.
#15	803751 1	LINER, Stainless Steel (1 required per assembly)
		803751 1 - Water Pump Liner [ More info ] $20.79 Available to Order: Shipping delay up to 10 days.
#16	803753 1	GUIDE PLATE, Stainless Steel (1 required per assembly)
		803753 1 - Guide Plate [ More info ] $11.79 Available to Order: Shipping delay up to 10 days.
#17	27-16158 5	GASKET (1 required per assembly)
		27-16158 5 - Gasket [ More info ] Unavailable
		27-16158015 - Gasket [ More info ] Unavailable
		27-8M0072137 - Gasket [ More info ] $6.19 2 In Stock.
#18	27-16158 6	GASKET (1 required per assembly)
		27-16158 6 - Gasket [ More info ] Unavailable
		27-16158014 - Gasket [ More info ] Unavailable
		278M0072138 - Gasket [ More info ] $6.79 1 In Stock.
#19	10-16126 8	BOLT, Stainless Steel (4 required per assembly)
		10-16126 8 - BOLT [ More info ] Unavailable
		10-879194305 - Bolt [ More info ] $10.09 Available to Order: Shipping delay up to 10 days.
#20	12-16826	WASHER, Stainless Steel (4 required per assembly)
		12-16826 - Washer, Stainless Steel [ More info ] $3.29 1 In Stock.
#21	46-803750 3	HOUSING, Water Pump - Lower (1 required per assembly)
		46-803750 3 - Water Pump Housing [ More info ] Unavailable
		46-803750A01 - Base for Water Pump [ More info ] $37.99 Available to Order: Shipping delay up to 10 days.
#22	27-16158 7	GASKET (1 required per assembly)
		27-16158 7 - Gasket [ More info ] Unavailable
		278M0072139 - Gasket [ More info ] $18.49 Available to Order: Shipping delay up to 10 days.
#23	26-95348	SEAL, Oil (1 required per assembly)
		26-95348 - Oil Seal [ More info ] $15.99 1 In Stock.
#24	15-853795 5	SHIM (AR required per assembly)
		15-853795 5 - Shim [ More info ] $7.49 Available to Order: Shipping delay up to 10 days.
#25	32-803755 2	PIPE, Water (Short) (1 required per assembly)
		32-803755 2 - Water Tube-Short [ More info ] $26.99 Available to Order: Shipping delay up to 10 days.
#25	32-803755 3	PIPE, Water (Long) (1 required per assembly)
		328037553 - Water Tube-LONG [ More info ] $18.09 Available to Order: Shipping delay up to 10 days.
#26	25-804899 1	GROMMET (1 required per assembly)
		258048991 - Grommet [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#27	25-804903	GROMMET (1 required per assembly)
		25-804903 - Grommet [ More info ] $5.99 Available to Order: Shipping delay up to 10 days.
#28	16165	RETAINER (1 required per assembly)
		16165 - Retainer [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#29	10-823042	BOLT (1 required per assembly)
		10-823042 - Bolt [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
