Parts for Mercury Marine 8 HP Cowls
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 2191-9205A13 | TOP COWL (BLACK) (1 required per assembly) |
  |
2191-9205A13 - Top Cowl - BLK [ More info ] Unavailable |
|
  |
2191-9420A10 - COWL-TOP-BLACK [ More info ] Unavailable |
|
  |
|
2191-9420T10 - Cowl - Top - Black [ More info ]
|
| #1 | 2191-9420A 9 | TOP COWL (GRAY) (1 required per assembly) |
  |
2191-9420A 9 - COWL-TOP-GRAY [ More info ] Unavailable |
|
  |
2191-9420T 9 - COWL-TOP-GRAY [ More info ] Unavailable |
|
  |
2191-9420T12 - Ord 2191-9420T10 [ More info ] Unavailable |
|
  |
|
21918M0094069 - Top Cowl [ More info ]
|
| #2 | 44462 1 | SEAL (1 required per assembly) |
  |
|
44462 1 [ More info ] Unavailable 44462 1 - replaced by 8M0043151 |
  |
|
8M0043151 - Motor Cowl Seal [ More info ]
|
| #3 | 13691A 1 | BLANKET KIT (1 required per assembly) |
  |
13691A 1 - Sound Blanket [ More info ] Unavailable |
|
  |
|
13691A02 - Sound Blanket Kit [ More info ]
|
| #4 | 16471A 1 | COWL LATCH (W/O ROLLER-SEE REF #4) (1 required per assembly) |
  |
|
16471A 1 - Cowl Latch, NLA [ More info ] Unavailable |
| #5 | 817104A 3 | COWL LATCH (W/ROLLER - SEE REF.#5) (1 required per assembly) |
  |
|
817104A 3 - Cowl Latch Assembly [ More info ]
|
| #6 | 18040 2 | LATCH HOOK (1 required per assembly) |
  |
|
18040 2 - Latch - Hook [ More info ]
|
| #7 | 11354 | SHIELD, REAR (BLACK) (1 required per assembly) |
  |
|
11354 - Shield, Rear Black, NLA [ More info ]
|
| #7 | 12873 | SHIELD, REAR (GRAY) (1 required per assembly) |
  |
12873 - SHIELD [ More info ] Unavailable |
|
  |
|
|
| #8 | 10-40001 8 | SCREW, REAR SHIELD (2 required per assembly) |
  |
|
10-40001 8 - Screw - Priced Individually [ More info ]
|
| #9 | 2192-9204A 1 | BOTTOM COWL (BLACK) (1 required per assembly) |
  |
|
2192-9204A 1 - Cowl Assembly -bot- Black [ More info ]
|
| #9 | 2192-9204A 2 | BOTTOM COWL (GRAY) (1 required per assembly) |
  |
|
2192-9204A 2 - COWL ASSY-BOT-GR,NLA [ More info ] Unavailable |
| #9A | 15061 | PLUG (1 required per assembly) |
  |
15061 - Plug [ More info ] Unavailable |
|
  |
|
|
| #10 | 12154 | PLUG, BOTTOM COWL (MANUAL) (1 required per assembly) |
  |
|
12154 - Bottom Cowl Plug [ More info ]
|
| #10 | 12153 2 | PLUG, BOTTOM COWL (ELECTRIC) (1 required per assembly) |
  |
|
12153 2 - Grommet [ More info ]
|
| #11 | 87-11083A 6 | STOP SWITCH ASSEMBLY (1 required per assembly) |
  |
|
87-11083A 6 - Stop Switch Kit [ More info ]
|
| #12 | 15920A54 | LANYARD ASSEMBLY (1 required per assembly) |
  |
15920A54 - Lanyard Assembly [ More info ] Unavailable |
|
  |
|
15920Q54 - Stop Switch Lanyard- Priced Individually [ More info ] Unavailable |
| #13 | 12044 1 | RETAINER, STOP SWITCH (1 required per assembly) |
  |
12044 1 - Retainer [ More info ] Unavailable |
|
  |
|
8M0032846 - Brass Retainer [ More info ]
|
| #14 | 44461A 1 | LEVER, COWL LATCH (1 required per assembly) |
  |
|
44461A 1 - Lever [ More info ]
|
| #15 | 23-76470 | BUSHING, COWL LATCH LEVEER (1 required per assembly) |
  |
|
23-76470 - Bushing [ More info ]
|
| #16 | 11394 | SPACER, LATCH (1 required per assembly) |
  |
|
11394 - Latch Spacer [ More info ]
|
| #17 | 10-40019130 | SCREW, LATCH AND LEVER (30MM) (1 required per assembly) |
  |
|
10-40019130 - Screw [ More info ]
|
| #17 | 10-40019131 | SCREW, LATCH AND LEVER (35MM) (1 required per assembly) |
  |
|
10-40019131 - Screw [ More info ]
|
| #18 | 13-69708 | WAVE WASHER, LATCH AND LEVER SCREW (1 required per assembly) |
  |
|
13-69708 - Wave Washer [ More info ]
|
