Parts for Mercury Marine 7.5 HP Electric Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 50-73531 | STARTER MOTOR (1 required per assembly) |
  |
|
50-73531 - Starter,NLA [ More info ] Unavailable |
| #2 | 11-20361 | NUT, STARTER MOTOR STUD (2 required per assembly) |
  |
|
|
  |
|
11-826708 9 - Nut - Priced Individually [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #3 | 54-47993 | CLAMP, STARTER MOTOR ATTACHING (1 required per assembly) |
  |
|
54-47993 - Clamp, NLA [ More info ] Unavailable |
| #4 | 10-34615 | SCREW, STARTER MOTOR CLAMP (1") (1 required per assembly) |
  |
10-34615 - Screw, NLA [ More info ] Unavailable |
|
  |
|
10-46378 - Screw, NLA [ More info ]
|
| #5 | 11-20088 | NUT, CLAMP SCREW (1 required per assembly) |
  |
|
11-20088 - Nut (.250X28) [ More info ]
|
| #6 | 84-73539A 1 | WIRE ASSEMBLY, STARTING SWITCH (YELLOW) (1 required per assembly) UNITED STATES 3801458 THRU 4691221 AUSTRALIA 8015315 THRU 8045674 BELGIUM 9043194 THRU 9150904 CANADA 7028598 THRU 7095422 |
  |
84-73539A 1 - WIRE ASSY [ More info ] Unavailable |
|
  |
|
84-76741A 1 - Wire Assembly, NLA [ More info ] Unavailable |
| #6 | 84-76741A 1 | WIRE ASSEMBLY, STARTING SWITCH (YELLOW) (1 required per assembly) UNITED STATES 4691222 AND UP AUSTRALIA 8045675 AND UP BELGIUM 9150905 AND UP CANADA 7095423 AND UP |
| #7 | 87-73883 | SWITCH, STARTING (1 required per assembly) |
  |
|
87-73883 - Switch [ More info ] Unavailable |
| #8 | 12-30516 | WASHER, STARTING SWITCH (1 required per assembly) |
  |
|
12-30516 - Washer, Rubber - Upper Mount Bolt, NLA [ More info ]
|
| #9 | 11-74394 | NUT, STARTING SWITCH (1 required per assembly) |
  |
|
11-74394 - Nut, Starting Switch,NLA [ More info ]
|
| #10 | 74515 | PROTECTOR, STARTING SWITCH (1 required per assembly) |
  |
|
74515 - PROTECTOR,NLA [ More info ] Unavailable |
| #11 | 84-73573 | CABLE, BATTERY (1 required per assembly) |
  |
84-73573 - Battery Cable [ More info ] Unavailable |
|
  |
|
84-72535A 4 - Cable Assembly [ More info ]
|
| #12 | 25-74444 | GROMMET, BATTERY CABLE (1 required per assembly) |
  |
|
25-74444 - Grommet, NLA [ More info ] Unavailable |
| #13 | 10-45742 | SCREW, BATTERY CABLE ATTACHING (5/16") (1 required per assembly) |
  |
|
10-45742 - Screw [ More info ]
|
| #14 | 10-20031 | SCREW, BATTERY CABLE ATTACHING (7/8") (1 required per assembly) |
  |
|
10-20031 - Screw - Priced Individually [ More info ]
|
  |
|
10-98253 - Screw [ More info ]
|
| #15 | 74367A 2 | LIGHTING STATOR ASSEMBLY (1 required per assembly) UNITED STATES 3801458 THRU 4691221 AUSTRALIA 8015315 THRU 8045674 BELGIUM 9043194 THRU 9150904 CANADA 7028598 THRU 7095422 |
  |
74367A 2 - LIGHTING Stator [ More info ] Unavailable |
|
  |
74367A 8 - Stator Assembly [ More info ] Unavailable |
|
  |
74367A12 - Stator [ More info ] Unavailable |
|
  |
|
74367A15 - Stator, NLA [ More info ] Unavailable |
| #15 | 74367A 8 | LIGHTING STATOR ASSEMBLY (1 required per assembly) UNITED STATES 4691222 AND UP AUSTRALIA 8045675 AND UP BELGIUM 9150905 AND UP CANADA 7095423 AND UP |
| #16 | 10-73696 | SCREW, LIGHTING STATOR ATTACHING (1 5/8") (2 required per assembly) |
  |
|
10-73696 - SCREW,NLA [ More info ]
|
| #17 | 62351A 2 | RECTIFIER ASSEMBLY (1 required per assembly) |
  |
62351A 2 - Rectifier [ More info ] Unavailable |
|
  |
62351A 1 - Rectifier [ More info ] Unavailable |
|
  |
816770 - Rectifier [ More info ] Unavailable |
|
  |
816770T - 8M0058226 [ More info ] Unavailable |
|
  |
|
8M0058226 - Rectifier - Outboard [ More info ]
|
  |
|
18-99416 - Regulated Rectifier 445114, 193-5114 [ More info ]
|
  |
|
18-5707 - Rectifier 816770 [ More info ]
|
  |
|
300-01404 - Rectifier, 8M0058226 [ More info ]
|
  |
|
AR351 - Rectifier [ More info ]
|
| #18 | 10-48408 | SCREW, RECTIFIER TO MANIFOLD COVER (1/2") (2 required per assembly) |
  |
|
10-48408 - Screw - Priced Individually [ More info ]
|
| #19 | 23-62769 | SPACER, RECTIFIER SCREW (2 required per assembly) |
  |
|
23-62769 - SPACER ,NLA [ More info ]
|
| #20 | 11-45076 | NUT, RECTIFIER TERMINAL (3 required per assembly) |
  |
|
11-45076 - Nut (#10-32) (brass) [ More info ]
|
| #21 | 84-61393A 6 | WIRE ASSEMBLY, RECTIFIER TO STARTING SWITCH (RED) (1 required per assembly) |
  |
|
84-61393A 6 - Cable, NLA [ More info ] Unavailable |
| #22 | 75076 | VOLTAGE REGULATOR (1 required per assembly) BELGIUM 9115165 AND UP |
  |
75076 - Voltage Regulator [ More info ] Unavailable |
|
  |
95845 - Voltage Regulator [ More info ] Unavailable |
|
  |
|
95845T - Voltage Regulator, NLA [ More info ]
|
| #23 | 10-74841 | SCREW, VOLTAGE REGULATOR TO MANIFOLD COVER (1") (2 required per assembly) BELGIUM 9115165 AND UP |
  |
|
10-74841 - SCREW,NLA [ More info ] Unavailable |
| #26 | 84-74725A 1 | HARNESS ASSEMBLY, VOLTAGE REGULATOR (BLACK/RED) (1 required per assembly) BELGIUM 9115165 AND UP |
  |
|
84-74725A 1 - Harness, NLA [ More info ] Unavailable |
| #27 | 71663 | PLUG, HARNESS (1 required per assembly) BELGIUM 9115165 AND UP |
  |
|
|
| #28 | 74361 | PLUG, HARNESS TO BOTTOM COWL (1 required per assembly) BELGIUM 9115165 AND UP |
  |
|
|
| #29 | 84-65017A 2 | HARNESS ASSEMBLY, LIGHTING (EXTERNAL) (1 required per assembly) BELGIUM 9115165 AND UP |
  |
|
84-65017A 2 - Harness Assembly [ More info ]
|
