Parts for Mercury Marine 75 HP (3 Cylinder) Electrical Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 42968 2 | IGNITION PLATE (1 required per assembly) |
  |
42968 2 - Ignition Plate [ More info ] Unavailable |
|
  |
|
42968A23 - IGNITION PL,NLA [ More info ] Unavailable |
| #2 | 332-7778A12 | SWITCH BOX (1 required per assembly) |
  |
|
332-7778A12 - Switch Box [ More info ]
|
  |
|
18-5775-1 - Switch Box, 332-7778A3, 12, 14, 114-7778 [ More info ]
|
  |
|
18-5775-1 - Switch Box, 332-7778A3, 12, 14, 114-7778 [ More info ]
|
  |
|
300-01852 - Switch Box [ More info ]
|
| #3 | 10-69079 | SCREW, (#10-16 x .440) (1 required per assembly) |
  |
|
10-69079 - Screw [ More info ]
|
| #4 | 10-40007110 | SCREW, (M5 X 30) (2 required per assembly) |
  |
|
10-40007110 - Screw, NLA [ More info ] Unavailable |
| #5 | 23-94304 | SPACER (2 required per assembly) |
  |
|
23-94304 - Spacer - Switch Box Screw [ More info ]
|
| #7 | 84-41592A 4 | HARNESS ASSEMBLY (1 required per assembly) |
  |
|
84-41592A 4 - Harness, NLA [ More info ]
|
| #8 | 84-813715A 7 | CABLE (1 required per assembly) |
  |
|
84-813715A 7 - Ignition Cable Set [ More info ]
|
| #9 | 85-63709A 1 | BOOT KIT (3 required per assembly) |
  |
|
85-63709A 1 - Boot Kit - Black - Priced Individually [ More info ]
|
| #10 | 33-97182 | SPARK PLUG (3 required per assembly) (NGK #BUHW-2) |
  |
33-97182 - NGK BUHW-2 Note: Priced Individually [ More info ] Unavailable |
|
  |
33-97182Q - NGK Spark Plug BUHW-2 - Priced Individually [ More info ] Unavailable |
|
  |
|
33-896329833 - Spark Plug - L78V - Priced Individually [ More info ] Unavailable |
  |
|
L78V - Champion Spark Plug ( #833M) [ More info ]
|
| #10 | 33-14103570 | SPARK PLUG (3 required per assembly) (Belgium/Canada) (NGK #BUZHW-2) |
  |
33-14103570 - NGK Spark Plug BUZHW-2 - Priced Individually [ More info ] Unavailable |
|
  |
|
33-14103Q - NGK BUZHW-2 - Priced Individually [ More info ] Unavailable |
| #11 | 10-821550 25 | SCREW, (M8 x 25) (3 required per assembly) |
  |
|
10-821550 25 - Screw - Priced Individually [ More info ]
|
| #12 | 339-7370A13 | IGNITION COIL ASSEMBLY (3 required per assembly) |
  |
339-7370A13 - Ignition Coil [ More info ] Unavailable |
|
  |
339-832757A 4 - Ignition Coil [ More info ] Unavailable |
|
  |
|
8M0230859 - Ignition Coil [ More info ]
|
  |
|
18-5186 - Ignition Coil 339-7370A13 [ More info ]
|
| #13 | 11-45076 | NUT, (#10-32) (6 required per assembly) |
  |
|
11-45076 - Nut (#10-32) (brass) [ More info ]
|
| #14 | 43542 | COVER (1 required per assembly) |
  |
|
43542 - Coil Cover [ More info ] Unavailable |
| #15 | 10-40007115 | SCREW, (M5 X 55) (6 required per assembly) |
  |
|
10-40007115 - Screw, NLA [ More info ]
|
| #16 | 12-89302 | WASHER, (.203 x .406 x .040) (6 required per assembly) |
  |
|
12-89302 - Washer (.203 X .406 X .040) [ More info ]
|
| #17 | 17602A 1 | TERMINAL BLOCK, Black (1 required per assembly) |
  |
|
17602A 1 - Rectifier Assembly [ More info ]
|
| #17 | 17602A 2 | TERMINAL BLOCK, Gray (1 required per assembly) |
  |
17602A 2 - Rectifier Assembly [ More info ] Unavailable |
|
  |
|
17602T02 - Rectifier - Terminal Block [ More info ]
|
| #18 | 10-40056107 | SCREW, (M5 x 16) (2 required per assembly) |
  |
|
10-40056107 - Screw [ More info ]
|
| #20 | 16731A 1 | MERCURY SWITCH, Old Design (1 required per assembly) |
  |
16731A 1 - Switch Assembly [ More info ] Unavailable |
|
  |
|
16731T01 - Switch Assembly [ More info ]
|
| #22 | 45915 | TERMINAL BLOCK (2 required per assembly) |
  |
|
86-45915 - Terminal Block [ More info ]
|
| #23 | 10-48408 | SCREW, (#10-16 x .500) (4 required per assembly) |
  |
|
10-48408 - Screw - Priced Individually [ More info ]
|
| #24 | 84-41591A 7 | ENGINE HARNESS (1 required per assembly) SN# D252461 & Up |
  |
|
84-41591A 7 - ENGINE Harness, NLA [ More info ] Unavailable |
| #24 | 84-41591A 3 | WIRING HARNESS ASSEMBLY (1 required per assembly) SN# D252460 & Below |
  |
|
84-41591A 3 - Wiring Harness [ More info ]
|
| #24 | 84-41591A 5 | ENGINE HARNESS, Use Without Reference Number 20 And 21 (1 required per assembly) |
  |
84-41591A 5 - ENG HARNESS ASY [ More info ] Unavailable |
|
| #25 | 88-79091 | FUSE, (20 Ampere) (1 required per assembly) |
  |
|
88-79091 - Fuse - 20 Amp - Priced Individually [ More info ]
|
  |
|
888M0207796 - FUSE-20 AMP Note: Priced Individually [ More info ]
|
| #26 | 84-88439A 3 | BATTERY CABLE, Positive (1 required per assembly) |
  |
|
84-88439A 3 - Battery Cable Assembly [ More info ]
|
| #26 | 84-88439A 4 | BATTERY CABLE, Negative (1 required per assembly) |
  |
|
84-88439A 4 - Cable Assembly -neg [ More info ]
|
| #27 | 89-818998A 1 | STARTER SOLENOID, ( 8-32 .250-20 Terminals) (1 required per assembly) |
  |
89-818998A 1 - Solenoid [ More info ] Unavailable |
|
  |
89-818998A 2 - Solenoid [ More info ] Unavailable |
|
  |
89-850187A 1 - Solenoid [ More info ] Unavailable |
|
  |
|
89-850187T 1 - Solenoid Assembly [ More info ] Unavailable |
  |
|
89-8M0185146 - Solenoid, Starter or Trim [ More info ]
|
  |
|
SW097 - Solenoid [ More info ]
|
| #27A | 25-818967 | GROMMET (2 required per assembly) |
  |
|
25-818967 - Grommet [ More info ]
|
  |
|
258M0207785 - Grommet [ More info ]
|
| #27B | 23-818968 | BUSHING (2 required per assembly) |
  |
23-818968 - Bushing [ More info ] Unavailable |
|
  |
|
238M0214955 - Bushing [ More info ]
|
| #28 | 10-40011109 | SCREW, (M5 x 25) (2 required per assembly) |
  |
|
10-40011109 - Screw [ More info ]
|
| #29 | 12-40023 14 | WASHER (2 required per assembly) |
  |
|
12-40023 14 - Washer - Priced Individually [ More info ]
|
| #30 | 84-88807A 6 | WIRE, (3.50 Inches) Black, Quantity Of Three On Power Trim (1 required per assembly) |
  |
|
84-88807A 6 - Wire Assembly [ More info ]
|
| #31 | 13-26992 | LOCKWASHER, (.250) (2 required per assembly) |
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #32 | 11-64015 | NUT, ( #8-32) (2 required per assembly) |
  |
|
11-64015 - Nut (1 /4-20) [ More info ]
|
| #33 | 11-26419 | NUT, (#8-32) (2 required per assembly) |
  |
|
11-26419 - Nut (#8-32) (brass) [ More info ]
|
| #34 | 13473 1 | FUSE HOLDER, Old Design (1 required per assembly) |
  |
|
13473 1 - Fuse Holder, NLA [ More info ]
|
| #35 | 12417 1 | COVER (1 required per assembly) |
  |
12417 1 - COVER [ More info ] Unavailable |
|
  |
|
12417 4 - Cover, NLA [ More info ]
|
| #36 | 10-40011114 | SCREW, (50 MM) (3 required per assembly) |
  |
10-40011114 - Screw [ More info ] Unavailable |
|
  |
|
10-40007114 - Screw [ More info ]
|
| #41 | 84-12201A 2 | HARNESS ASSEMBLY (1 required per assembly) (Use With Black Terminal Block) |
  |
|
84-12201A 2 - Harness Assembly, NLA [ More info ]
|
| #42 | 12082A 8 | VOLTAGE REGULATOR (1 required per assembly) (Use With Black Terminal Block) |
  |
12082A 8 - Voltage Regulator [ More info ] Unavailable |
|
  |
|
815279A 2 - Voltage Regulator Kit [ More info ]
|
  |
|
18-5743-1 - Voltage Regulator, Mercury [ More info ]
|
  |
|
18-5741 - Voltage Regulator, 815279A2 [ More info ]
|
  |
|
300-26072 - Voltage Regulator, 815279A2 [ More info ]
|
| #43 | 10-40106 30 | SCREW, (M6 x 30) (3 required per assembly) (Use With Black Terminal Block) |
  |
|
10-40106 30 - Screw [ More info ]
|
| #44 | 815279T | VOLTAGE REGULATOR (1 required per assembly) (Two Female/Three Male Terminals) |
  |
815279T - Voltage Regulator [ More info ] Unavailable |
|
  |
815279 5 - Voltage Regulator [ More info ] Unavailable |
|
  |
830179 2 - Voltage Regulator [ More info ] Unavailable |
|
  |
854515 - Voltage Regulator [ More info ] Unavailable |
|
  |
854515T 1 - Voltage Regulator [ More info ] Unavailable |
|
  |
883072T - Voltage Regulator [ More info ] Unavailable |
|
  |
|
8M0084173 - Voltage Regulator [ More info ]
|
  |
|
18-5743 - Voltage Regulator, 815279-3, 81527 [ More info ]
|
  |
|
300-76382 - Rectifier/Regulator, Mercury Mariner, EMP [ More info ]
|
| #44 | 815279A 2 | VOLTAGE REGULATOR, Five Ring Terminals (1 required per assembly) |
| #45 | 10-40106 35 | SCREW, (M6 x 35) (2 required per assembly) |
  |
|
10-40106 35 - Screw [ More info ]
|
| #46 | 84-821546A 1 | HARNESS (1 required per assembly) (Use With 815279--3 Voltage Regulator) |
  |
84-821546A 1 - Harness Assembly [ More info ] Unavailable |
|
  |
|
84-821546A 3 - Harness Assembly [ More info ]
|
