Parts for Mercury Marine 650 (3 Cylinder) Starter Motor, Starter Solenoid & Rectifier Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 62351A 1 | RECTIFIER ASSEMBLY (1 required per assembly) |
  |
62351A 1 - Rectifier [ More info ] Unavailable |
|
  |
816770 - Rectifier [ More info ] Unavailable |
|
  |
816770T - 8M0058226 [ More info ] Unavailable |
|
  |
|
8M0058226 - Rectifier - Outboard [ More info ]
|
  |
|
18-99416 - Regulated Rectifier 445114, 193-5114 [ More info ]
|
  |
|
18-5707 - Rectifier 816770 [ More info ]
|
  |
|
300-01404 - Rectifier, 8M0058226 [ More info ]
|
  |
|
AR351 - Rectifier [ More info ]
|
| #2 | 10-38055 | SCREW, RECTIFIER TO PLATE (5/8") (2 required per assembly) |
  |
|
10-38055 - Screw - Priced Individually [ More info ]
|
| #3 | 13-26996 | LOCKWASHER, RECTIFIER SCREW (2 required per assembly) |
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #4 | 11-45076 | NUT, RECTIFIER TERMINAL (3 required per assembly) |
  |
|
11-45076 - Nut (#10-32) (brass) [ More info ]
|
| #5 | 89-68258 | STARTER SOLENOID (1 required per assembly) |
  |
89-68258 - Solenoid [ More info ] Unavailable |
|
  |
89-68258A 4 - Solenoid [ More info ] Unavailable |
|
  |
|
89-853654A 1 - Solenoid [ More info ]
|
  |
|
18-5815 - Solenoid 89-853654A1 [ More info ]
|
  |
|
89-02815 - Solenoid, 89-853654A1 [ More info ]
|
  |
|
SW275 - Solenoid, 89-853654A 1 [ More info ]
|
| #7 | 11-68219 | NUT, SOLENOID TERMINAL (#10) (2 required per assembly) |
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
| #8 | 13-26993 | LOCKWASHER, SOLENOID TERMINAL (5/16") (2 required per assembly) |
  |
|
13-26993 - LockWasher - Priced Individually [ More info ]
|
  |
|
138M0204647 - LOCKWASHER, Priced Individually [ More info ]
|
| #9 | 11-68292 | NUT, SOLENOID TERMINAL (5/16") (2 required per assembly) |
  |
|
11-68292 - Nut (5/16 Inch) [ More info ]
|
  |
|
11-8M0204668 - NUT @5 [ More info ] Unavailable |
| #10 | 46265 | BOOT, TERMINAL-STARTER SOLENOID (1 required per assembly) |
  |
|
|
| #11 | 10-69054 | SCREW, SOLENOID TO TOP COVER (3/4") (2 required per assembly) |
  |
|
10-69054 - Screw, NLA [ More info ]
|
| #12 | 13-26992 | WASHER, SOLENOID SCREW (2 required per assembly) |
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #13 | 50-65436 | STARTER MOTOR ASSEMBLY (1 required per assembly) |
  |
50-65436 - Starter Motor [ More info ] Unavailable |
|
  |
|
50-44369A 1 - Starter Kit, 7 inch starter with adapter for 8 inch applications [ More info ] Unavailable |
  |
|
18-5642 - Starter 50-66015, 8 inch, See Detail Page for Important Information [ More info ]
|
  |
|
5388 - Outboard Starter, Mercury, 50-60HP, 7 inch, See detail page for more info [ More info ]
|
  |
|
5375 - Starter, 50-66015, 10 Tooth, 8 inch, See detail page for more [ More info ]
|
| #14 | 57247 | STOP, RUBBER- STARTER MOTOR (2 required per assembly) |
  |
|
|
  |
68042 - Rubber Stop [ More info ] Unavailable |
|
  |
|
8M0043376 - Stop [ More info ]
|
| #15 | 84-60872 | CABLE, STARTER TO SOUND ATTENTUATOR-BLACK (9 1/2") (1 required per assembly) |
  |
|
84-60872 - Battery Cable,NLA [ More info ] Unavailable |
| #16 | 10-28635 | SCREW, CABLE TO STARTER MOTOR (5/8") (1 required per assembly) |
  |
|
10-28635 - Screw - Priced Individually [ More info ]
|
| #17 | 84-73453 | CABLE, SOLENOID TO STARTER MOTOR-YELLOW (9 1/2") (1 required per assembly) |
  |
84-73453 - Battery Cable [ More info ] Unavailable |
|
  |
|
84-93389A 6 - WIRE ASSY,NLA [ More info ] Unavailable |
| #19 | 11-20890 | NUT, STARTER MOTOR TERMINAL (1 required per assembly) |
  |
|
11-20890 - Nut (1/4 x20) [ More info ]
|
| #20 | 56703 | COLLAR, RUBBER-STARTER MOUNT (2 required per assembly) |
  |
56703 - Collar [ More info ] Unavailable |
|
  |
23-8M0001391 - COLLAR [ More info ] Unavailable |
|
  |
|
23-8M0034918 - Collar [ More info ]
|
| #21 | 23-56774 | SPACER, COLLAR TO MOUNTING BRACKETS (AR required per assembly) |
  |
|
23-56774 - Spacer, NLA [ More info ] Unavailable |
| #22 | 84-73452 | CABLE, BATTERY TO STARTER SOLENOID (1 required per assembly) |
  |
84-73452 - Battery Cable [ More info ] Unavailable |
|
  |
84-62862A 3 - Cable [ More info ] Unavailable |
|
  |
|
84-62862A 4 - Cable Assembly [ More info ]
|
| #23 | 84-73204 | WIRING HARNESS (INTERNAL) (1 required per assembly) |
  |
|
84-73204 - Wiring Harness, NLA [ More info ] Unavailable |
| #24 | 10-69560 | SCREW, WIRING HARNESS TO FRONT SUPPORT BRACKET (1 1/4") (2 required per assembly) |
  |
|
10-69560 - Screw [ More info ]
|
| #25 | 11-46438 | NUT, WIRING HARNESS SCREW (2 required per assembly) |
  |
|
11-46438 - Nut (#10-32) [ More info ]
|
| #26 | 60114A 1 | BRACKET ASSEMBLY, WIRING HARNESS (1 required per assembly) |
  |
|
60114A 1 - Bracket Assembly, NLA [ More info ] Unavailable |
| #27 | 26-60925 | SEAL, WIRING HARNESS BRACKET (1 required per assembly) |
  |
|
26-60925 - Seal, NLA [ More info ] Unavailable |
| #28 | 10-55903 | SCREW, WIRING HARNESS BRACKET MOUNTING (2 1/4") (2 required per assembly) |
  |
10-55903 - Screw [ More info ] Unavailable |
|
  |
|
10-89778 - Screw, NLA [ More info ] Unavailable |
