Parts for Mercury Marine 650 (3 Cylinder) Cowling & Front Cover
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 2142-6228A 1 | COWL ASSEMBLY (STARBOARD) (1 required per assembly) |
  |
|
2142-6228A 1 - Cowl Assembly, NLA [ More info ] Unavailable |
| #2 | 26-60297 | SEAL, FUEL CONNECTOR-COWL (1 required per assembly) |
  |
|
26-60297 - Seal, NLA [ More info ]
|
| #3 | 2141-6227A 1 | COWL ASSEMBLY (PORT) (1 required per assembly) |
  |
|
2141-6227A 1 - Cowl Assembly, NLA [ More info ] Unavailable |
| #4 | 26-60298 | SEAL, CONTROL CABLES-COWL (1 required per assembly) |
  |
|
26-60298 - Seal, NLA [ More info ] Unavailable |
| #5 | 69566 | BRACKET, COWL SEALING-REAR (1 required per assembly) |
  |
69566 - 89717T, USED PART [ More info ] Unavailable |
|
  |
89717 - Bracket [ More info ] Unavailable |
|
  |
|
89717T - Bracket, NLA [ More info ] Unavailable |
| #6 | 69876 1 | SEAL, REAR BRACKET (2 required per assembly) |
  |
|
69876 1 - Seal, NLA [ More info ]
|
| #7 | 69568 | BRACKET, COWL HINGE (2 required per assembly) |
  |
69568 - Bracket [ More info ] Unavailable |
|
  |
|
90980 - Bracket [ More info ] Unavailable |
| #8 | 10-45561 | SCREW, HINGE BRACKET TO REAR BRACKET-LOWER (1 1/8") (2 required per assembly) |
  |
10-45561 - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-45561 1 - Screw [ More info ]
|
| #8 | 10-75794 | SCREW, HINGE BRACKET TO REAR BRACKET- UPPER (1 1/8') (2 required per assembly) |
  |
|
10-75794 - Screw, NLA [ More info ]
|
| #8A | 75805 | CAP, HINGE BRACKET SCREW (UPPER) (2 required per assembly) |
  |
|
75805 - Cap - Priced Individually [ More info ] Unavailable |
| #9 | 13-26992 | LOCKWASHER, HINGE BRACKET SCREW (4 required per assembly) |
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #10 | 12-37998 | WASHER, HINGE BRACKET SCREW (4 required per assembly) |
  |
|
12-37998 - Washer - Priced Individually [ More info ]
|
| #10 | 12-75806 | WASHER, HINGE BRACKET SCREW (UPPER) (2 required per assembly) |
  |
|
12-75806 - Washer, Hinge Bracket Screw (upper) [ More info ]
|
| #11 | 17-60301 | PIN, COWL HINGE (4 required per assembly) |
  |
17-60301 - Hinge Pin [ More info ] Unavailable |
|
  |
|
90979 - Pin, Cowl Hinge, NLA [ More info ]
|
| #12 | 10-28782 | SCREW, PIN TO COWL (7/8") (4 required per assembly) |
  |
|
10-28782 - Screw - Priced Individually [ More info ]
|
| #13 | 13-26993 | LOCKWASHER, PIN ATTACHING SCREW (4 required per assembly) |
  |
|
13-26993 - LockWasher - Priced Individually [ More info ]
|
  |
|
138M0204647 - LOCKWASHER, Priced Individually [ More info ]
|
| #14 | 46785A 2 | COWL LATCH ASSEMBLY (2 required per assembly) |
  |
|
46785A 2 - Latch Assembly [ More info ]
|
  |
|
46785A 5 - Latch Assembly, NLA [ More info ] Unavailable |
| #15 | 62628 | BARREL, COWL LATCH (2 required per assembly) |
  |
|
62628 - Cowl Latch Barrel [ More info ] Unavailable |
| #16 | 10-31312 | SCREW, LATCH ASSEMBLY TO BARREL (7/8") (2 required per assembly) |
  |
|
10-31312 - Screw, NLA [ More info ]
|
| #17 | 62627 | BAR, ADJUSTMENT-COWL LATCH (2 required per assembly) |
  |
62627 - Adjusting Bar [ More info ] Unavailable |
|
  |
|
15222 - Cowl Latch Adjusting Bar, NLA [ More info ]
|
| #18 | 62629 | BARREL, COWL LATCH (2 required per assembly) |
  |
|
62629 - Cowl Latch Barrel [ More info ]
|
| #19 | 24-62624 | SPRING, TENSION-COWL LATCH (2 required per assembly) |
  |
|
24-62624 - Spring, Cowl Latch,NLA [ More info ]
|
| #20 | 12-30164 | WASHER, ADJUSTMENT BAR TO BARREL (2 required per assembly) |
  |
|
12-30164 - Washer, (.192 X .375 X .0312) [ More info ]
|
| #21 | 11-45812 | NUT, ADJUSTMENT BAR TO BARREL (2 required per assembly) |
  |
|
11-45812 - Nut, (#10-32) [ More info ]
|
  |
|
11-859124 - Nut, (#10-32) Stainless Steel, Nylon Insert [ More info ]
|
| #22 | 2143-5689A 3 | COWL FRONT COVER ASSEMBLY (1 required per assembly) |
  |
2143-5689A 3 - COWL FRONT COVER [ More info ] Unavailable |
|
  |
2143-5689A 5 - COWL FRONT COVER [ More info ] Unavailable |
|
  |
|
2143-7254A 3 - COWL FRONT Cover, NLA [ More info ] Unavailable |
| #23 | 75165 | BLANKET, SOUND ABSORBING-FRONT COVER (1 required per assembly) |
  |
75165 - Seal [ More info ] Unavailable |
|
  |
79551 - Seal [ More info ] Unavailable |
|
  |
|
79551 1 - SEAL,NLA [ More info ] Unavailable |
| #24 | 61158 | HOOK, COWL FRONT COVER FASTENING (2 required per assembly) |
  |
|
|
  |
|
61158T - Hook, NLA [ More info ]
|
| #25 | 10-69570 | SCREW, FASTENING HOOK TO COWL FRONT COVER (3/4") (1 required per assembly) |
  |
|
10-69570 - Screw [ More info ]
|
| #26 | 47341A 1 | STARTER ROPE ASSEMBLY (FOR MANUAL STARTING ONLY) (1 required per assembly) |
  |
47341A 1 - Rope And Handle [ More info ] Unavailable |
|
  |
|
47341A11 - Manual Start Rope And Handle [ More info ]
|
