Parts for Mercury Marine 60 Shift Control Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 30747 | HANDLE, SHIFT CONTROL (1,1,1,1,1 required per assembly) |
  |
|
30747 - Handle, NLA [ More info ]
|
| #2 | 23-30678 | BUSHING, NYLON-SHIFT CONTROL HANDLE (1,1,1,1,1 required per assembly) |
  |
|
23-30678 - Bushing, NLA [ More info ]
|
| #3 | 24-30817 | SPRING, TENSION-SHIFT CONTROL HANDLE (1,1,1,1,1 required per assembly) |
  |
|
24-30817 - Spring, Tension - Shift Control Shaft,NLA [ More info ]
|
| #4 | 12-20086 | WASHER, TENSION SPRING TO HANDLE (1,,,, required per assembly) |
  |
|
12-20086 - Washer, (.390 X .620 X .060) [ More info ]
|
| #5 | 17-25905 | PINE, ROLL-SPRING AND WASHER TO HANDLE (1,,,, required per assembly) |
  |
|
17-25905 - Pin, Roll, NLA [ More info ]
|
| #5 | 17-32124 | PIN, DOWEL-TENSION SPRING TO HANDLE (,1,1,1,1 required per assembly) |
  |
10-32124 - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-28668 - Screw - Priced Individually [ More info ]
|
| #7 | 43-30802 | GEAR, HORIZONTAL-SHIFT CONTROL HANDLE (1,1,1,1,1 required per assembly) |
  |
|
43-30802 - Sector Gear [ More info ]
|
| #8 | 12-29245 | WASHER, SHIFT CONTROL HANDLE (1,1,1,1,1 required per assembly) |
  |
|
12-29245 - Washer [ More info ]
|
  |
|
12-8M0204649 - WASHER Note: Priced Individually [ More info ]
|
| #9 | 11-20361 | NUT, HORIZONTAL GEAR TO SHIFT CONTROL HANDLE (1,1,1,1,1 required per assembly) |
  |
|
|
  |
|
11-826708 9 - Nut - Priced Individually [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #10 | 24-30816 | SPRING, DETENT-SECTOR GEAR (1,1,1,1,1 required per assembly) |
  |
|
24-30816 - Spring,Detent,NLA [ More info ]
|
| #12 | 10-30818 | SCREW, DETENT SPRING TO BOTTOM COWL (1,1,1,, required per assembly) SERIAL 00000000-01552144 |
  |
10-30818 - SCREW [ More info ] Unavailable |
|
  |
|
10-55336 - SCREW,NLA [ More info ] Unavailable |
| #11 | 13-21272 | LOCKWASHER, DETENT SPRING SCREW (,,1,1,1 required per assembly) SERIAL 01582403-09999999 |
  |
|
13-21272 - LockWasher - Priced Individually [ More info ]
|
| #12 | 10-28639 | SCREW, DETENT SPRING TO BOTTOM COWL (,,1,1,1 required per assembly) SERIAL 01582403-09999999 |
  |
|
10-28639 - Screw - Priced Individually [ More info ]
|
| #13 | 23-30677 | BUSHING, NYLON-SHIFT CONTROL SHAFT (1,1,1,1,1 required per assembly) |
  |
|
23-30677 - Bushing, NLA [ More info ]
|
| #14 | 30836A 2 | SHIFT CONTROL SHAFT ASSEMBLY (SEE NOTE BELOW) (1,,,, required per assembly) |
  |
30836A 2 - CONTROL ASSY [ More info ] Unavailable |
|
  |
31335A 3 - SHAFT ASSY [ More info ] Unavailable |
|
  |
|
31335A 4 - Shaft Assembly, NLA [ More info ]
|
  |
|
54640A 1 - Shaft Assembly, NLA [ More info ]
|
| #15 | 43-30838 | GEAR, SECTOR-SHIFT CONTROL SHAFT(BRONZE) (1,,,, required per assembly) |
  |
43-30838 - SECTOR GEAR [ More info ] Unavailable |
|
  |
|
43-32453 - Sector Gear [ More info ]
|
| #14 | 31335A 2 | SHIFT CONTROL SHAFT ASSEMBLY (,1,1,, required per assembly) SERIAL 00000(3)-01526318 |
  |
31335A 2 - SHAFT ASSEMBLY [ More info ] Unavailable |
|
| #15 | 43-31337 | GEAR, SECTOR-SHIFT CONTROL SHAFT (ALUMINUM) (,1,1,, required per assembly) SERIAL 00000(3)-01526318 |
  |
43-31337 - SECTOR GEAR [ More info ] Unavailable |
|
| #14 | 31335A 4 | SHIFT CONTROL SHAFT ASSEMBLY (,,1,1,1 required per assembly) SERIAL )1526319-01877455 |
| #15 | 43-32453 | GEAR, SECTOR-SHIFT CONTROL SHAFT(ALUMINUM) (,,1,1,1 required per assembly) SERIAL )1526319-01877455 |
| #16 | 25-26630 | RING, RUBBER-LOWER SHIFT CONTROL SHAFT (1,1,1,1,1 required per assembly) SERIAL 00000000-01877455 |
  |
|
25-26630 - O-Ring [ More info ]
|
| #14 | 31335A 7 | SHIFT CONTROL ASSEMBLY (,,,,1 required per assembly) SERIAL 01877456-09999999 |
  |
31335A 7 - SHAFT ASSY [ More info ] Unavailable |
|
  |
|
45251A 2 - Shaft Assembly, NLA [ More info ] Unavailable |
| #16A | 25-38933 | "O" RING, LOWER SHIFT CONTROL SHAFT (,,,,1 required per assembly) SERIAL 01877456-09999999 |
  |
|
25-38933 - O-Ring, Lower Shift Control Shaft [ More info ]
|
  |
|
18-7120 - O-Ring 322598 [ More info ]
|
