Parts for Mercury Marine 60 HP EFI (4 Cylinder) (4-Stroke) Intake / Exhaust Valves

Revise Search: All Models > 60 HP EFI (4 Cylinder) (4-Stroke) > 0P515897 & Up (Belgium) > Intake / Exhaust Valves

« Previous

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	893505T05	CYLINDER HEAD ASSEMBLY (1 required per assembly)
		893505T05 - Cylinder Head Assembly [ More info ] Unavailable
#1	832991T 3	VALVE, Exhaust (4 required per assembly)
		832991T 3 - 8M0065029 [ More info ] Unavailable
		8M0065029 - Exhaust Valve [ More info ] $37.49 Available to Order: Shipping delay up to 10 days.
#2	832990T 3	VALVE, Intake (4 required per assembly)
		832990T 3 - Intake Valve [ More info ] $21.09 Available to Order: Shipping delay up to 10 days.
#3	26-858271	SEAL (8 required per assembly)
		26-858271 - Seal [ More info ] $17.89 Available to Order: Shipping delay up to 10 days.
#4	24-858268	SPRING, Valve - Outer (8 required per assembly)
		24-858268 - Valve Spring [ More info ] Unavailable
		24-893552 - Spring [ More info ] $36.99 Available to Order: Shipping delay up to 10 days.
#5	822650	RETAINER (8 required per assembly)
		822650 - Valve Spring Retainer [ More info ] Unavailable
		893553 - Retainer [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#6	28-822651	KEY (16 required per assembly)
		28-822651 - KEY [ More info ] Unavailable
		28-893554 - Key [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#7	825045A 2	ROCKER ARM (8 required per assembly)
		825045A 2 - Rocker Arm [ More info ] Unavailable
#8	10-825046	SCREW (8 required per assembly)
		10-825046 - Screw [ More info ] Unavailable
#9	11-826150	NUT (8 required per assembly)
		11-826150 - NUT,NLA [ More info ] Unavailable
#10	857085 1	SHAFT, Rocker (1 required per assembly)
		857085 1 - Shaft - Rocker [ More info ] $168.99 Available to Order: Shipping delay up to 10 days.
#11	NSS	NOT SOLD SEPARATE, Plug (2 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#12	859577	BRACKET (2 required per assembly)
		859577 - Bracket [ More info ] Unavailable
		893560 - Bracket [ More info ] $17.49 Available to Order: Shipping delay up to 10 days.
#13	858275	BRACKET (1 required per assembly)
		858275 - Bracket [ More info ] Unavailable
		893561 - Bracket [ More info ] $19.59 Available to Order: Shipping delay up to 10 days.
#14	24-825052 1	SPRING (2 required per assembly)
		24-825052 1 - SPRING [ More info ] Unavailable
		24-893562 - Spring [ More info ] $16.59 Available to Order: Shipping delay up to 10 days.
#15	10-875218	SCREW, (M8 x 23) (5 required per assembly)
		10-875218 - Screw - Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#16	27-859576	GASKET (1 required per assembly)
		27-859576 - Gasket [ More info ] Unavailable
		27-893645 - Gasket [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#17	17-859575	PIN (1 required per assembly)
		17-859575 - Pin, Cam Thrust [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#18	24-889775	SPRING, Overload (2 required per assembly)
		24-889775 - Spring, Overload [ More info ] Unavailable
		24-893563 - Spring, Overload [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
