Parts for Mercury Marine 6 HP (4-Stroke) Oil Pan

Revise Search: All Models > 6 HP (4-Stroke) > 0R000001 - 0R067089 (USA) > Oil Pan

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	27-803508A05	GASKET SET, Powerhead (1 required per assembly) SN# 0R057259 & Up
		27-803508A05 - Powerhead Gasket Set [ More info ] $103.49 Available to Order: Shipping delay up to 10 days.
#	27-803508A99	GASKET SET, Powerhead (1 required per assembly) SN# 0R057258 & Below
		27-803508A99 - Powerhead Gasket Set [ More info ] Unavailable
#1	10-823031 10	SCREW, (M5 x 16) (1 required per assembly)
		10-823031 10 - Screw, NLA [ More info ] $1.50 $0.30 10+ In Stock.
#2	54-803543	STOPPER (1 required per assembly)
		54-803543 - Clamp [ More info ] $2.79 $2.24 1 In Stock.
#3	32-95223 7	TUBING (1 required per assembly)
		32-95223 7 - Tubing, NLA [ More info ] $8.69 Available to Order: Shipping delay up to 10 days.
#4	26-803520 2	SEAL (2 required per assembly)
		26-803520 2 - Seal [ More info ] $7.79 $6.24 10+ In Stock.
#5	10-855558	SCREW, (M5 x 16) (2 required per assembly)
		10-855558 - Bolt [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#6	12-16072 1	WASHER (2 required per assembly)
		12-16072 1 - Washer [ More info ] $1.30 Available to Order: Shipping delay up to 10 days.
#7	803540	HOUSING, Strainer (1 required per assembly)
		803540 - Strainer Housing [ More info ] $6.69 $5.36 3 In Stock.
#8	803542	STRAINER (1 required per assembly)
		803542 - Strainer, NLA [ More info ] $4.59 $3.68 10+ In Stock.
#9	803541	CUP (1 required per assembly)
		803541 - Cup, NLA [ More info ] $7.09 $5.68 10+ In Stock.
#10	17-16119	PIN, Dowel (2 required per assembly)
		17-16119 - Dowel Pin [ More info ] $8.19 $6.56 3 In Stock.
#11	84-803539	LEAD WIRE (1 required per assembly)
		84-803539 - Lead Wire [ More info ] $16.39 Available to Order: Shipping delay up to 10 days.
#12	87-803538	SWITCH (1 required per assembly)
		87-803538 - Switch [ More info ] Unavailable
		87-8M0163139 - Switch OIL [ More info ] $45.49 Available to Order: Shipping delay up to 10 days.
#13	25-803513 5	GROMMET (1 required per assembly)
		25-803513 5 - Grommet, NLA [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#14	10-16830 5	BOLT, (M6 x 20) (3 required per assembly)
		10-16830 5 - Bolt, NLA [ More info ] Unavailable
		10-810755007 - Bolt [ More info ] $3.60 Available to Order: Shipping delay up to 10 days.
#15	803532	PLATE, Exhaust (1 required per assembly)
		803532 - Ord 803532001, NLA [ More info ] Unavailable
		803532001 - Exhaust Plate [ More info ] $28.39 Available to Order: Shipping delay up to 10 days.
#16	27-803508 8	GASKET (1 required per assembly)
		27-803508 8 - Gasket [ More info ] Unavailable
		27-803508015 - Exhaust Plate Gasket [ More info ] $10.09 Available to Order: Shipping delay up to 10 days.
#17	803531T	PAN, Oil (1 required per assembly) SN# 0R057258 & Below
		803531T - Oil Pan [ More info ] Unavailable
		8M0227775 - 8M0227775 - OIL PAN [ More info ] Unavailable Replaced by -8M0227936
		8M0227936 - OIL PAN [ More info ] Unavailable
#17	803531T01	PAN, Oil (1 required per assembly) SN# 0R057259 & Up
		803531T01 - PAN-OIL [ More info ] Unavailable
#18	10-16830 6	BOLT, (M6 x 40) (3 required per assembly)
		10-16830 6 - Bolt, NLA [ More info ] $1.70 $0.34 10+ In Stock.
#19	803533 1	ROTOR, Outer (1 required per assembly)
		803533 1 - Rotor [ More info ] $15.49 $12.40 10 In Stock.
#20	17-16256 3	PIN (1 required per assembly)
		17-16256 3 - Carburetor Float Pin [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#21	803533	ROTOR, Inner (1 required per assembly)
		803533 - Rotor [ More info ] $13.49 $10.80 10 In Stock.
#22	25-803513 4	O-RING (1 required per assembly) SN# 0R057258 & Below
		25-803513 4 - O-Ring [ More info ] $4.69 Available to Order: Shipping delay up to 10 days.
#22	25-803513010	O-RING (1 required per assembly) SN# 0R057259 & Up
		25-803513010 - O-Ring [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#23	803534	COVER (1 required per assembly)
		803534 - Cover [ More info ] $6.79 1 In Stock.
#25	10-16705 1	BOLT, (M6 x 20) (2 required per assembly)
		10-16705 1 - Bolt [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#26	815016 2	HOUSING (1 required per assembly)
		815016 2 - Housing [ More info ] $63.49 Available to Order: Shipping delay up to 10 days.
#27	26-16703	SEAL, Oil (2 required per assembly)
		26-16703 - Seal [ More info ] Unavailable
		26-8M0101649 - Seal [ More info ] $12.49 1 In Stock.
#28	23-815018	SPACER (1 required per assembly)
		23-815018 - Spacer [ More info ] $3.99 Available to Order: Shipping delay up to 10 days.
#29	27-16704	GASKET (1 required per assembly)
		27-16704 - Housing Gasket [ More info ] Unavailable
		27-8M0152378 - Gasket Crankcase [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#30	26-853707 7	SEAL, Oil (1 required per assembly)
		26-853707 7 - Seal [ More info ] Unavailable
#31	10-803509 6	BOLT (1 required per assembly)
		10-803509 6 - BOLT-DRAIN [ More info ] Unavailable
		10-803509021 - Bolt - Drain [ More info ] $11.29 Available to Order: Shipping delay up to 10 days.
#32	12-803516 1	WASHER (1 required per assembly)
		12-803516 1 - Washer [ More info ] $3.79 5 In Stock.
#33	10-815068 5	BOLT, (M8 x 40) (6 required per assembly)
		10-815068 5 - Bolt, NLA [ More info ] $2.29 $0.46 10+ In Stock.
#34	27-803508 7	GASKET (1 required per assembly)
		27-803508 7 - Gasket [ More info ] Unavailable
		27-803508014 - Oil Pan Gasket [ More info ] $30.69 Available to Order: Shipping delay up to 10 days.
#35	803535	CONTROL PLUNGER (1 required per assembly)
		803535 - Plunger [ More info ] $4.29 Available to Order: Shipping delay up to 10 days.
#36	24-803554 1	SPRING (1 required per assembly)
		24-803554 1 - Spring [ More info ] $3.69 $2.96 4 In Stock.
#37	25-16823 1	O-RING (1 required per assembly)
		25-16823 1 - O-Ring [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#38	803536	SEAT (1 required per assembly)
		803536 - Seat [ More info ] $5.89 $4.72 3 In Stock.
#39	803537	COVER (1 required per assembly)
		803537 - Cover [ More info ] $1.70 $1.36 9 In Stock.
#40	10-16828 7	BOLT, (M6 x 16) (1 required per assembly)
		10-16828 7 - Bolt, NLA [ More info ] $3.29 $0.66 10+ In Stock.
