Parts for Mercury Marine 45 HP (4 Cylinder) Starter Rewind
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 11-20166 | NUT, SHEAVE SHAFT (LEFT HAND THREAD) (1 required per assembly) |
  |
|
11-20166 - Nut, Sheave Shaft ( Left Hand Thread) [ More info ]
|
| #2 | 14-61004 | TAB WASHER, SHEAVE SHAFT NUT (1 required per assembly) |
  |
|
14-61004 - Tab Washer - Priced Individually [ More info ]
|
| #3 | 89930 | STARTER HOUSING (1 required per assembly) THE ENCLOSED PARTS MUST BE ORDERED IF THE STARTER SHEAVE (REF. #4) IS NOTCHED ON BOTH SIDES. |
  |
89930 - Starter Housing [ More info ] Unavailable |
|
  |
|
89016A 3 - Starter,NLA [ More info ] Unavailable |
| #4 | 50-94338A 1 | STARTER SHEAVE (1 required per assembly) THE ENCLOSED PARTS MUST BE ORDERED IF THE STARTER SHEAVE (REF. #4) ISNOTCHED ON BOTH SIDES. |
  |
|
50-94338A 1 - SEE OB-SB 85-3, SEE NOTE [ More info ] Unavailable |
  |
|
76079A 8 - Starter Assembly, NLA [ More info ]
|
| #5 | 91936 | STARTER PAWL (1 required per assembly) THE ENCLOSED PARTS MUST BE ORDERED IF THE STARTER SHEAVE (REF. #4) ISNOTCHED ON BOTH SIDES. |
  |
|
91936 - Starter Pawl, See notes on Drawing [ More info ]
|
| #3 | 89016 1 | STARTER HOUSING - SEE NOTE #2 BELOW (1 required per assembly) THE ENCLOSED PARTS MUST BE ORDERED IF THE STARTER SHEAVE (REF.#4) IS NOTCHED ON THE TOP SIDE ONLY. |
  |
89016 1 - Housing [ More info ] Unavailable |
|
  |
|
89016 2 - Housing, NLA [ More info ]
|
| #4 | 50-44255A 1 | STARTER SHEAVE (1 required per assembly) THE ENCLOSED PARTS MUST BE ORDERED IF THE STARTER SHEAVE (REF.#4) IS NOTCHED ON THE TOP SIDE ONLY. |
  |
|
50-44255A 1 - Sheave Assembly [ More info ] Unavailable |
| #5 | 44508 | STARTER PAWL (1 required per assembly) THE ENCLOSED PARTS MUST BE ORDERED IF THE STARTER SHEAVE (REF.#4) IS NOTCHED ON THE TOP SIDE ONLY. |
  |
|
44508 - Starter Pawl, NLA [ More info ]
|
| #6 | 10-54523 | SCREW, STARTER HOUSING (3 required per assembly) |
  |
|
10-54523 - Screw - Priced Individually [ More info ]
|
| #7 | 13-20202 | LOCKWASHER, STARTER HOUSING SCREW (3 required per assembly) |
  |
|
13-20202 - LockWasher, NLA [ More info ]
|
| #8 | 37691 | PLATE, CABLE GUIDE (1 required per assembly) |
  |
|
|
| #9 | 10-35881 | SCREW, DRIVE - CABLE GUIDE PLATE (3 required per assembly) |
  |
10-35881 - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-35881 1 - Screw - Priced Individually [ More info ]
|
| #10 | 61002 | PLATE, STARTER REWIND (1 required per assembly) |
  |
|
61002 - Starter Rewind Retainer, NLA [ More info ]
|
| #11 | 24-39502A 1 | SPRING, STARTER REWIND (1 required per assembly) |
  |
|
24-39502A 1 - Spring, Starter Rewind [ More info ]
|
  |
|
24-39502T02 - Recoil Spring, NLA [ More info ] Unavailable |
| #12 | 23-97649 | BUSHING, SPRING GUIDE (1 required per assembly) |
  |
|
90-97649 - Owners Guide [ More info ] Unavailable |
| #13 | 24-87651 | SPRING, STARTER PAWL (1 required per assembly) |
  |
|
24-87651 - Spring, Starter Pawl [ More info ]
|
| #14 | 53-87706 | "E" RING, STARTER PAWL (1 required per assembly) |
  |
|
53-87706 - E-Ring, NLA [ More info ]
|
| #15 | 23-63061 | SPACER, SHEAVE SHAFT (1 required per assembly) |
  |
|
23-63061 - Spacer - Sheave Shaft [ More info ]
|
| #17 | 94962 | LEVER (1 required per assembly) |
  |
|
|
| #18 | 13-20160 | WAVE WASHER (1 required per assembly) |
  |
|
13-20160 - Wave Washer - Priced Individually [ More info ]
|
| #19 | 87656 | SHEAVE SHAFT (1 required per assembly) |
  |
|
87656 - Sheave Shaft [ More info ] Unavailable |
| #20 | 50-28985A 2 | STARTER CABLE ASSEMBLY (1 required per assembly) |
  |
50-28985A 2 - Starter Rope Assembly [ More info ] Unavailable |
|
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #20 | 47341A 1 | STARTER CABLE (FOR MANUAL STARTING) (1 required per assembly) |
  |
47341A 1 - Rope And Handle [ More info ] Unavailable |
|
  |
|
47341A11 - Manual Start Rope And Handle [ More info ]
|
| #21 | 85174A 1 | HANDLE AND RETAINER ASSEMBLY (1 required per assembly) |
  |
|
85174A 1 - Handle Assembly -start [ More info ]
|
| #22 | 76568 | CABLE, INTERLOCK (1 required per assembly) ALSO USED ON ELECTRIC TILLER HANDLE MODELS |
  |
|
76568 - Cable, NLA [ More info ] Unavailable |
| #23 | 10-69022 | SCREW, INTERLOCK CBLE ATTACHING (1/2") (2 required per assembly) ALSO USED ON ELECTRIC TILLER HANDLE MODELS |
  |
|
10-69022 - Screw [ More info ]
|
| #24 | 12-26013 | WASHER, INTERLOCK CABLE SCREW (2 required per assembly) ALSO USED ON ELECTRIC TILLER HANDLE MODELS |
  |
|
12-26013 - Washer, NLA [ More info ]
|
| #25 | 42820 | CAM, INTERLOCK (1 required per assembly) |
  |
42820 - Cam [ More info ] Unavailable |
|
  |
|
42820 1 - Cam, NLA [ More info ]
|
| #26 | 10-76138 | SCREW, INTERLOCK CAM (1-1/8") (1 required per assembly) |
  |
|
10-76138 - Screw, NLA [ More info ]
|
| #27 | 24-76140 | SPRING, INTERLOCK CAM SCREW (1 required per assembly) |
  |
24-76140 - Spring, Interlock Cam Screw [ More info ] Unavailable |
|
  |
|
24-76140 1 - Spring, NLA [ More info ]
|
| #28 | 79371 | ACTUATOR, INTERLOCK (1 required per assembly) |
  |
|
79371 - Actuator, NLA [ More info ]
|
| #29 | 10-76137 | SCREW, INTERLOCK ACTUATOR (1-5/8") (1 required per assembly) |
  |
|
10-76137 - Screw, NLA [ More info ]
|
| #30 | 24-76139 | SPRING, INTERLOCK ACTUATOR SCREW (1 required per assembly) |
  |
|
24-76139 - Spring, Interlock Actuator Screw - Manual,NLA [ More info ]
|
| #31 | 18-27769 | COTTER PIN, INTERLOCK CABLE TO ACTUATOR (1 required per assembly) |
  |
|
18-27769 - Cotter Pin [ More info ]
|
  |
|
18-26811 - Pigtail, GM HEI 2 Terminal [ More info ]
|
| #32 | 12-35559 | WASHER, STARTER REWIND (1 required per assembly) |
  |
|
12-35559 - Washer - Priced Individually [ More info ]
|
