Parts for Mercury Marine Model 402 40 HP Shift Control Linkage

Revise Search: All Models > Model 402 40 HP > 3339688 - 9076838 (Belgium) > Shift Control Linkage

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	55334	BRACKET, SHIFT ANCHOR - UPPER (1 required per assembly)
		55334 - Bracket [ More info ] Unavailable
		87876A 1 - Bracket Assembly, NLA [ More info ] Unavailable
#2	10-37558	SCREW, ANCHOR BRACKET TO CYLINDER BLOCK (1 1/4") (2 required per assembly)
		10-37558 - Screw - Priced Individually [ More info ] $0.40 1 In Stock.
		10-74824 - Screw - Priced Individually [ More info ] $1.80 3 In Stock.
#2	10-25503	SCREW, ANCHOR BRACKET TO CYLINDER BLOCK (2") (1 required per assembly)
		10-25503 - Screw [ More info ] Unavailable
		10-815549 - Screw [ More info ] $5.39 $4.32 3 In Stock.
#3	10-21489	SCREW, UPPER ANCHOR BRACKET TO CRANKCASE (1 3/4") (1 required per assembly)
		10-21489 - SCREW [ More info ] Unavailable
		10-69096 - Screw, NLA [ More info ] $1.50 $1.28 1 In Stock.
#4	11-46793	NUT, UPPER ANCHOR BRACKET SCREW (1 required per assembly)
		11-46793 - Nut, (5/16-24) [ More info ] Unavailable
		11-29250 - Nut (5/16-24) [ More info ] $2.89 $1.63 10+ In Stock.
#5	39472	SLIDE, SHIFT ACTUATING (1 required per assembly)
		39472 - Slide [ More info ] Unavailable
		87874 - Slide, NLA [ More info ] $21.56 4 In Stock.
#6	56193	LATCH, SHIFT ACTUATING SLIDE (SHIFT CABLE) (1 required per assembly)
		56193 - Shift Cable Latch, NLA [ More info ] Unavailable
#7	10-39620	SCREW, LATCH TO SHIFT ACTUATING SLIDE (1 required per assembly)
		10-39620 - Screw, NLA [ More info ] $5.30 $4.50 10+ In Stock.
#8	24-27087	SPRING, COMPRESSION - LATCH SCREW (1 required per assembly)
		24-27087 - Spring, Compression,NLA [ More info ] $7.17 $6.07 10+ In Stock.
#9	39516	SLIDE, NYLON - ANCHOR BRACKET (SHIFT ACUTATING SLIDE) (1 required per assembly)
		39516 - Slide, NLA [ More info ] $8.00 $6.78 2 In Stock.
#10	39515	END CAP, NYLON - ANCHOR BRACKET SLIDE (2 required per assembly)
		39515 - End Cap, NLA [ More info ] $7.48 $6.33 10+ In Stock.
#11	39448	BRACKET, SHIFT ANCHOR - LOWER (1 required per assembly)
		39448 - Bracket [ More info ] Unavailable
#12	10-20012	SCREW, UPPER ANCHOR BRACKET TO LOWER ANCHOR BRACKET (1 5/8") (2 required per assembly)
		10-20012 - Screw - Priced Individually [ More info ] $1.71 10+ In Stock.
#13	11-20586	NUT, UPPER ANCHOR BRACKET SCREW (2 required per assembly)
		11-20586 - Nut, (.250-28) [ More info ] $0.46 1 In Stock.
		11-35045 - Nut (1/4-28) [ More info ] Unavailable
		11-826709109 - Nut, (.250-28) Stainless Steel [ More info ] $3.59 4 In Stock.
#14	59110A 2	SHIFT SHAFT ASSEMBLY, UPPER (SHORT SHAFT) (1 required per assembly)
		59110A 2 - Shaft Assembly, NLA [ More info ] $75.00 $63.52 1 In Stock.
#14	59110A 1	SHIFT SHAFT ASSEMBLY, UPPER (LONG SHAFT) (1 required per assembly)
		59110A 1 - Shaft Assembly, NLA [ More info ] Unavailable
#15	55692	COUPLING, UPPER SHIFT SHAFT (1 required per assembly)
		55692 - Coupling , Priced Individually [ More info ] $20.00 2 In Stock.
		93960A 1 - Coupling Assembly [ More info ] $97.25 $65.36 7 In Stock.
#16	12-37998	WASHER, UPPER SHIFT SHAFT- MANUAL ONLY (1 required per assembly)
		12-37998 - Washer - Priced Individually [ More info ] $0.70 4 In Stock.
#17	18-26953	COTTER PIN, UPPER SHIFT SHAFT- MANUAL ONLY (1 required per assembly)
		18-26953 - Cotter Pin - Priced Individually [ More info ] $4.19 8 In Stock.
#18	39519	CUP, RETAINER - ANCHOR BRACKET (SHIFT CABLE BARREL) (1 required per assembly)
		39519 - Cup [ More info ] $5.39 8 In Stock.
#19	39618	LEVER, NYLON - SHIFT CABLE LOCKING (UPPER ANCHOR BRACKET) (1 required per assembly)
		39618 - Shift Cable Locking Lever, Nylon [ More info ] $35.99 1 In Stock.
		87609A 1 - Lever Kit [ More info ] $92.38 5 In Stock.
		65799T - Locking Lever to Cover Link, Old Style [ More info ] $15.28 10+ In Stock.
#20	17-47175	PIN,LOCKING LEVER AND COVER FASTENING (3 required per assembly)
		17-47175 - Pin - Priced Individually [ More info ] $3.22 10+ In Stock.
#21	39667	COVER, NYLON - SHIFT CABLE (1 required per assembly)
		39667 - Shift cable Cover, Nylon, NLA [ More info ] Unavailable
#22	65799	LINK, LOCKING LEVER TO COVER (1 required per assembly)
		65799 - Lever to Cover Link [ More info ] $16.66 10+ In Stock.
