Parts for Mercury Marine Model 400 40 HP (2 Cylinder) Drive Shaft Housing Assembly

Revise Search: All Models > Model 400 40 HP (2 Cylinder) > 2874704 - 3336257 (USA) > Drive Shaft Housing Assembly

« Previous

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	1554-4004A 2	DRIVE SHAFT HOUSING ASSEMBLY (SHORT SHAFT) (1 required per assembly)
		1554-4004A 2 - Drive Shaft Housing [ More info ] Unavailable
		1554-4947A 1 - Drive Shaft, NLA [ More info ] Unavailable
#1	1564-4003A 2	DRIVE SHAFT HOUSING ASSEMBLY (LONG SHAFT) (1 required per assembly)
		1564-4003A 2 - Drive Shaft Housing [ More info ] Unavailable
		1564-4948A 1 - Drive Shaft, NLA [ More info ] Unavailable
#2	16-57932	STUD, DRIVE SHAFT HOUSING TO GEAR HOUSING (1 3/4") (1 required per assembly)
		16-57932 - STUD [ More info ] Unavailable
		16-8M0022145 - Stud [ More info ] $12.49 Available to Order: Shipping delay up to 10 days.
#3	16-57935	STUD, DRIVE SHAFT HOUSING TO GEAR HOUSING (3") (1 required per assembly)
		16-57935 - Stud, NLA [ More info ] $9.58 1 In Stock.
#4	19-32297	PLUG, PLASTIC - WATER PICK-UP HOLE (1 required per assembly)
		19-32297 - Plug - Priced Individually [ More info ] $2.50 10+ In Stock.
		19-824928 - Plug [ More info ] Unavailable
		19-824928001 - Plug [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
#5	12-45176	WASHER, DRIVE SHAFT HOUSING TO GEAR HOUSING STUDS (2 required per assembly)
		12-45176 - Washer, (.453 X .812 X .105) [ More info ] $1.50 6 In Stock.
#6	39608	COVER, TRIM - DRIVE SHAFT HOUSING (1 required per assembly)
		39608 - Trim Cover [ More info ] Unavailable
		60769 - Cover [ More info ] Unavailable
#7	10-37571	SCREW, TRIM COVER TO DRIVE SHAFT HOUSING (4 required per assembly)
		10-37571 - Screw - Priced Individually [ More info ] $2.33 $1.97 10+ In Stock.
#8	39558	SEAL, TRIM COVER TO DRIVE SHAFT HOUSING (2 required per assembly)
		39558 - SEAL,NLA [ More info ] Unavailable
#9	39557	STRIP, RETAINING - TRIM COVER SEAL (2 required per assembly)
		39557 - Strip, NLA [ More info ] $1.50 $1.28 1 In Stock.
#10	10-48408	SCREW, STRIP AND SEAL TO DRIVE SHAFT HOUSING (1/2") (4 required per assembly)
		10-48408 - Screw - Priced Individually [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#11	12-30164	WASHER, RETAINING STRIP SCREW (4 required per assembly)
		12-30164 - Washer, (.192 X .375 X .0312) [ More info ] $2.49 10+ In Stock.
#12	32-37727	TUBE, WATER OUTLET (SHORT SHAFT) (1 required per assembly)
		32-37727 - Water Tube - Short, NLA [ More info ] $51.92 $43.98 2 In Stock.
#12	32-45679	TUBE, WATER OUTLET (LONG SHAFT) (1 required per assembly)
		32-45679 - Water Tube - Long [ More info ] Unavailable
#13	23-23651	SLEEVE, RUBBER - WATER OUTLET TUBE (1 required per assembly)
		23-23651 - Sleeve [ More info ] $4.74 Available to Order: Shipping delay up to 10 days.
#14	39526	TUBE, EXHAUST (SHORT SHAFT) (1 required per assembly)
		39526 - Exhaust Tube [ More info ] Unavailable
		69543 - Exhaust Tube [ More info ] $22.84 1 In Stock.
		69543 1 - Exhaust Tube, NLA [ More info ] $53.33 $45.17 4 In Stock.
#14	45786	TUBE, EXHAUST (LONG SHAFT) (1 required per assembly)
		45786 - Exhaust Tube [ More info ] Unavailable
		69544 - Exhaust Tube [ More info ] Unavailable
		69544 1 - Exhaust Tube, NLA [ More info ] $48.30 $40.92 1 In Stock.
#15	11-25594	NUT, POWERHEAD STUDS (8 required per assembly)
		11-25594 - Nut (5/16-24) [ More info ] Unavailable
		11-862902 - Nut, (.312-24) [ More info ] $2.39 4 In Stock.
#16	46933A 2	GROUND STRAP, BOTTOM COWL TO DRIVE SHAFT HOUSING (2 required per assembly)
		46933A 2 - Strap , NLA [ More info ] $4.00 $3.39 6 In Stock.
#18	27-38501	GASKET, EXHAUST PLATE TO DRIVE SHAFT HOUSING (1 required per assembly)
		27-38501 - Adaptor Plate To Drive Shaft Housing Gasket [ More info ] Unavailable
		27-38501 1 - Gasket [ More info ] $11.49 4 In Stock.
		18-0879 - Gasket, 27-38501 1 [ More info ] $10.12 Available to Order: Shipping delay up to 10 days.
#19	25305	CAP, RUBBER - UPPER MOUNT BOLT NUT (2 required per assembly)
		25305 - Upper Mount Rubber Cap, NLA [ More info ] $8.25 $6.99 10+ In Stock.
#20	11-23161	NUT, UPPER MOUNT BOLT (2 required per assembly)
		11-23161 - Nut (3/8X24) [ More info ] $2.89 10+ In Stock.
#21	12-30519	WASHER, UPPER MOUNT BOLT (3/8 ID) (2 required per assembly)
		12-30519 - Washer, Upper Mount Bolt (3/8 Id) NLA [ More info ] $8.63 $7.32 10+ In Stock.
#22	12-30521	WASHER, RUBBER - UPPER MOUNT BOLT (2 required per assembly)
		12-30521 - Washer, (.97 X .56 X .19) (neoprene) [ More info ] $3.11 10+ In Stock.
#23	12-30520	WASHER, UPPER MOUNT BOLT (37/64 ID) (2 required per assembly)
		12-30520 - Washer, Upper Mount Bolt (37/64 Id) NLA [ More info ] $2.20 $1.86 10+ In Stock.
#24	24935	COVER, UPPER MOUNT - OUTSIDE HALF (2 required per assembly)
		24935 - Upper Mount Cover, Outside Half - Priced Individually [ More info ] $5.40 3 In Stock.
		79680A 1 - Cover Assembly, NLA [ More info ] $43.12 3 In Stock.
#25	31120	COVER, UPPER MOUNT - INSIDE HALF (2 required per assembly)
		31120 - Upper Mount Cover, Inside Half - Priced Individually [ More info ] $9.99 6 In Stock.
#26	37392	MOUNT, RUBBER - UPPER (2 required per assembly)
		37392 - Upper Rubber Mount [ More info ] Unavailable
		75301 - Upper Rubber Mount, NLA [ More info ] $25.86 3 In Stock.
#27	24929	PACKING, "U" CUP - UPPER MOUNT COVERS (2 required per assembly)
		24929 - U Cup Packing, NLA [ More info ] $16.15 10+ In Stock.
#28	10-49988	SCREW, UPPER MOUNT COVER - REAR (1 3/4") (4 required per assembly)
		10-49988 - Screw [ More info ] Unavailable
		10-37941 - Screw - Priced Individually [ More info ] $3.50 $3.36 10+ In Stock.
#29	10-49987	SCREW, UPPER MOUNT COVER - FRONT (1 1/2") (4 required per assembly)
		10-49987 - Screw, NLA [ More info ] $1.49 $1.26 10+ In Stock.
#30	11-46886	NUT, UPPER MOUNT COVER FASTENING SCREW (8 required per assembly)
		11-46886 - Nut - Priced Individually [ More info ] Unavailable
		11-35888 - Nut (1/4-28) [ More info ] $6.89 $3.04 10+ In Stock.
		18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ] $11.99 $8.16 Available to Order: Shipping delay up to 10 days.
#31	25067	BUMPER, RUBBER - LOWER MOUNT SCREW (2 required per assembly)
		25067 - Bumper, NLA [ More info ] $11.97 10+ In Stock.
#32	10-49318	SCREW, LOWER MOUNT (5 1/2") (2 required per assembly)
		10-49318 - Screw [ More info ] Unavailable
		10-75284 - Screw [ More info ] $15.69 Available to Order: Shipping delay up to 10 days.
#33	12-28051	WASHER, LOWER MOUNT SCREW (2 required per assembly)
		12-28051 - Washer [ More info ] $19.29 Available to Order: Shipping delay up to 10 days.
#34	12-28053	WASHER, RUBBER - LOWER MOUNT SCREW (2 required per assembly)
		12-28053 - Washer [ More info ] $3.99 5 In Stock.
#35	37393	MOUNT, RUBBER - LOWER (2 required per assembly)
		37393 - Lower Rubber Mount [ More info ] Unavailable
		75302 - Mount [ More info ] Unavailable
		75302 1 - MOUNT [ More info ] Unavailable
		75302T 1 - Mount, NLA [ More info ] $92.21 $78.11 10+ In Stock.
#36	12-30119	WASHER, LOWER MOUNT SCREW (2 required per assembly)
		12-30119 - Washer (7/8 X .1196) [ More info ] $2.69 1 In Stock.
#37	11-25096	NUT, LOWER MOUNT SCREW (2 required per assembly)
		11-25096 - Nut, Mount Screw [ More info ] $22.62 10+ In Stock.
#38	35473	CLAMP, LOWER MOUNT TO DRIVE SHAFT HOUSING (2 required per assembly)
		35473 - Mount Clamp [ More info ] Unavailable
		69592 - Clamp [ More info ] Unavailable
		69592T - Clamp [ More info ] Unavailable
		69592F 1 - Clamp [ More info ] $11.99 $10.15 9 In Stock.
#39	10-29256	SCREW, LOWER MOUNT CLAMP TO DRIVE SHAFT HOUSING (7/8") (4 required per assembly)
		10-29256 - Screw - Priced Individually [ More info ] $2.71 10+ In Stock.
#40	24-35522	SPRING, TENSION - LOWER MOUNT CLAMP (4 required per assembly)
		24-35522 - Spring Tension - Lower Mount Clamp,NLA [ More info ] $8.61 10+ In Stock.
#41	35474	COVER, LOWER MOUNT CLAMP (2 required per assembly)
		35474 - Cover [ More info ] $38.99 4 In Stock.
		35474T - Cover [ More info ] Unavailable
#42	10-29722	SCREW, COVER TO LOWER CLAMP (5/8") (2 required per assembly)
		10-29722 - Screw, NLA [ More info ] $1.99 $1.68 10+ In Stock.
#43	11-35521	NUT, LOWER MOUNT CLAMP COVER (2 required per assembly)
		11-35521 - Nut - Priced Individually [ More info ] $2.79 $1.57 10+ In Stock.
#44	11-34933	NUT, GEAR HOUSING TO DRIVE SHAFT HOUSING STUDS (2 required per assembly)
		11-34933 - Nut (7/16-20) [ More info ] $3.99 2 In Stock.
		11-8M0204653 - Prop Lock Nut 7/16-20 , Priced Individually [ More info ] $5.29 9 In Stock.
		11-00118 - Nut, Sold Individually [ More info ] $3.59 $2.95 7 In Stock.
#45	22-52644	PLUG, GREASE - REVERSE LOCK HOLE (1 required per assembly) SERIAL 00000000-02979678
		22-52644 - Plug [ More info ] Unavailable
		22-35268 - Plug [ More info ] Unavailable
		22-39072 - Plug [ More info ] $2.22 4 In Stock.
		22-39072 1 - Plug - Priced Individually [ More info ] $9.29 1 In Stock.
#46	52920	LEVER, REVERSE LOCK (1 required per assembly) SERIAL 00000000-02979678
		52920 - Lever [ More info ] $9.00 $7.62 10+ In Stock.
#47	17-24887	PIN, REVERSE LOCK LEVER (1 required per assembly) SERIAL 00000000-02979678
		17-24887 - Lock Pin, NLA [ More info ] Unavailable
#48	24-25122	SPRING, TENSION - PUSH ROD (1 required per assembly) SERIAL 00000000-02979678
		24-25122 - Spring, Tension - Push Rod,NLA [ More info ] $25.00 $21.18 10+ In Stock.
#49	32102	ROD, PUSH - REVERSE LOCK (SHORT SHAFT) (1 required per assembly) SERIAL 00000000-02979678
		32102 - Push Rod [ More info ] $6.00 $5.08 5 In Stock.
#49	45788	ROD, PUSH - REVERSE LOCK (LONG SHAFT) (1 required per assembly) SERIAL 00000000-02979678
		45788 - Push Rod, NLA [ More info ] Unavailable
#50	18-25191	COTTER PIN, PUSH ROD TO REVERSE LOCK (1 required per assembly) SERIAL 00000000-02979678
		18-25191 - Cotter Pin - Priced Individually [ More info ] $3.79 10+ In Stock.
#51	52917	GUIDE, PUSH ROD SERIAL #3043031 AND UP (1 required per assembly) SERIAL 03043031-09999999
		52917 - Guide, NLA [ More info ] $19.32 $16.37 10+ In Stock.
#52	59721	ROD, PUSH - REVERSE LOCK (SHORT SHAFT) (1 required per assembly) SERIAL 03043031-09999999
		59721 - Rod, NLA [ More info ] Unavailable
#52	59720	ROD, PUSH - REVERSE LOCK (LONG SHAFT) (1 required per assembly) SERIAL 03043031-09999999
		59720 - Push Rod [ More info ] $16.00 $13.55 2 In Stock.
#53	11-60049	NUT, JAM - PUSH ROD (1 required per assembly) SERIAL 03043031-09999999
		11-60049 - NUT,NLA [ More info ] $1.36 $1.16 10+ In Stock.
#54	59722	ROD END, PUSH ROD (1 required per assembly) SERIAL 03043031-09999999
		59722 - Push Rod, NLA [ More info ] $9.99 $8.45 10 In Stock.
#55	17-59719	PIN, REVERSE LOCK LEVER (1 required per assembly) SERIAL 03043031-09999999
		17-59719 - Clevis Pin - Priced Individually [ More info ] Unavailable
		17-72524 - Clevis Pin, NLA [ More info ] $3.75 $3.17 10 In Stock.
