Parts for Mercury Marine Model 40 4 HP (1 Cylinder) Throttle Control Linkage
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 43-60856 | GEAR, HORIZONTAL - THROTTLE CONTROL (1 required per assembly) |
  |
|
43-60856 - Throttle Control Gear [ More info ] Unavailable |
| #2 | 60885 | HOUSING, HORIZONTAL GEAR (1 required per assembly) |
  |
|
|
  |
|
60885T - Housing, NLA [ More info ] Unavailable |
| #3 | 10-47910 | SCREW, THROTTLE CONTROL HOUSING TO BOTTOM COWL (5/8") (2 required per assembly) |
  |
10-47910 - Screw [ More info ] Unavailable |
|
  |
|
10-96138 - Screw [ More info ]
|
| #4 | 15-64653A 1 | SHIM, PINION GEAR TO BOTTOM COWL (1 required per assembly) |
  |
|
15-64653A 1 - Shim Set, NLA [ More info ]
|
| #5 | 62638A 2 | GEAR AND SHAFT ASS'Y, THROTTLE CONTROL (1 required per assembly) UNITED STATES 3529445 AND BELOW AUSTRALIA 8005739 AND BELOW BELGIUM 9012108 AND BELOW CANADA 7011057 AND BELOW |
  |
62638A 2 - SHAFT ASSY [ More info ] Unavailable |
|
  |
63854A 1 - SHAFT ASSY [ More info ] Unavailable |
|
  |
|
42666A 3 - Lever Assembly [ More info ] Unavailable |
| #5&9 | 63854A 1 | GEAR AND SHAFT ASS'Y, THROTTLE CONTROL (1 required per assembly) UNITED STATES 3529445 AND BELOW AUSTRALIA 8005739 AND BELOW BELGIUM 9012108 AND BELOW CANADA 7011057 AND BELOW |
| #6 | 62099 | BRACKET, THROTTLE CONTROL LEVER (1 required per assembly) |
  |
62099 - Bracket [ More info ] Unavailable |
|
  |
|
62099T - Bracket, NLA [ More info ]
|
| #7 | 10-23015 | SCREW, ADJUSTING - THROTTLE (1") (2 required per assembly) |
  |
|
10-23015 - Screw [ More info ] Unavailable |
| #8 | 11-20645 | NUT, LOCK - THROTTLE ADJUSTING SCREWS (2 required per assembly) |
  |
|
11-20645 - Nut,(10X32) [ More info ]
|
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
| #9 | 61643 | LEVER, THROTTLE CONTROL (1 required per assembly) UNITED STATES 3529445 AND BELOW AUSTRALIA 8005739 AND BELOW BELGIUM 9012108 AND BELOW CANADA 7011057 AND BELOW |
  |
61643 - LEVER [ More info ] Unavailable |
|
|
63854A 1 - SHAFT ASSY [ More info ] Unavailable |
|
|
|
42666A 3 - Lever Assembly [ More info ] Unavailable |
| #10 | 17-27088 | PIN, ROLL - LEVER TO VERTICAL SHAFT (1 required per assembly) |
  |
|
17-27088 - Pin -roll, NLA [ More info ]
|
| #11 | 60920 | LINK, THROTTLE LEVER TO STATOR PLATE (1 required per assembly) |
  |
|
60920 - Link, NLA [ More info ]
|
| #12 | 10-34696 | SCREW, THROTTLE LINK TO TTHROTTLE LEVER (3/4") (1 required per assembly) |
  |
|
10-34696 - Screw [ More info ] Unavailable |
| #13 | 12-34392 | WASHER, THROTTLE LINK CREW (4 required per assembly) |
  |
|
12-34392 - Washer, NLA [ More info ]
|
| #14 | 13-29720 | WASHER, WAVE - THROTTLE LINK SCREW (1 required per assembly) |
  |
|
13-29720 - Wave Washer - Priced Individually [ More info ]
|
| #15 | 11-28656 | NUT, THROTTLE LINK SCREW (2 required per assembly) |
  |
|
11-28656 - Nut, NLA [ More info ]
|
| #16 | 10-56027 | SCREW, THROTTLE LINK TO STATOR PLATE (7/8") (1 required per assembly) |
  |
|
10-56027 - Screw, NLA [ More info ] Unavailable |
