Parts for Mercury Marine 3.5 HP Steering Handle
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 84370M | STEERING ARM (1 required per assembly) SERIAL 00023741-09999999 |
  |
|
84370M - ARM,NLA [ More info ] Unavailable |
| #2 | 84371M | PORT STEERING ARM (1 required per assembly) SERIAL 00023741-09999999 |
  |
|
84371M - ARM,NLA [ More info ] Unavailable |
| #1 | NLA | STEERING ARM (1 required per assembly) SERIAL 00000000-00023740 |
  |
|
NLA - No Longer Availab [ More info ] Unavailable |
| #2 | 80312M | PORT STEERIN ARM (1 required per assembly) SERIAL 00000000-00023740 |
  |
|
80312M - Steering Arm,NLA [ More info ] Unavailable |
| #3 | 10-82532M | SCREW (1 required per assembly) SERIAL 00016021-09999999 |
  |
|
10-82532M - Screw - Priced Individually [ More info ]
|
| #3 | 10-82751M | SCREW (1 required per assembly) SERIAL 00000000-00016020 |
  |
|
10-82751M - SCREW,NLA [ More info ] Unavailable |
| #4 | 10-82528M | SCREW (1 required per assembly) |
  |
|
10-82528M - Screw, NLA [ More info ]
|
| #5 | 10-84438M | SCREW (1 required per assembly) |
  |
|
10-84438M - Screw, NLA [ More info ] Unavailable |
| #6 | 80155M | CAP (1 required per assembly) |
  |
|
80155M - Cap, NLA [ More info ] Unavailable |
| #7 | 80152M | GRIP (1 required per assembly) |
  |
|
80152M - GRIP [ More info ] Unavailable |
| #8 | 11-82388M | NUT (1 required per assembly) |
  |
|
11-82388M - Nut, (M5) [ More info ]
|
| #9 | 37-80156M | INDICATOR (1 required per assembly) |
  |
|
37-80156M - DECAL,NLA [ More info ] Unavailable |
| #10 | 80153M | GUIDE (1 required per assembly) |
  |
|
80153M - Slider,NLA [ More info ] Unavailable |
| #11 | 80151M | FRONT BRACKET (1 required per assembly) |
  |
|
80151M - HANDLE,NLA [ More info ] Unavailable |
| #12 | 10-84372M | BOLT (1 required per assembly) SERIAL 00023741-09999999 |
  |
|
10-84372M - Screw, NLA [ More info ]
|
| #12 | 10-81716M | BOLT (1 required per assembly) SERIAL 00000000-00023740 |
  |
10-81716M - BOLT [ More info ] Unavailable |
|
| #12A | 12-81802M | WASHER (2 required per assembly) SERIAL 00000000-00016020 |
  |
|
12-81802M - Washer, NLA [ More info ]
|
| #13 | 12-81810M | WASHER (2 required per assembly) |
  |
|
12-81810M - Washer, NLA [ More info ]
|
| #14 | 12-81850M | WASHER (2 required per assembly) |
  |
|
12-81850M - WASHER,NLA [ More info ]
|
| #15 | 12-81849M | WASHER (2 required per assembly) |
  |
|
12-81849M - Washer, NLA [ More info ]
|
| #16 | 24-82075M | SPRING (1 required per assembly) |
  |
|
24-82075M - Spring, NLA [ More info ] Unavailable |
| #17 | 13-82215M | LOCKWASHER (1 required per assembly) |
  |
|
13-82215M - LockWasher - Priced Individually [ More info ]
|
| #18 | 11-82393M | NUT (1 required per assembly) |
  |
11-82393M - Nut , Priced Individually [ More info ] Unavailable |
|
  |
|
11-82383M - Nut, NLA [ More info ]
|
| #19 | 94784M | REAR BRACKET (1 required per assembly) SERIAL 00004281-09999999 |
  |
|
94784M - Bracket, NLA [ More info ] Unavailable |
| #19 | 80158M | REAR BRACKET (1 required per assembly) SERIAL 00010621-00004280 |
  |
|
80158M - Bracket, NLA [ More info ] Unavailable |
| #20 | 17-82157M | ROLL PIN (4 required per assembly) |
  |
|
17-82157M - Pin -roll, NLA [ More info ]
|
| #21 | 10-82457M | BOLT (4 required per assembly) SERIAL 00004281-09999999 |
  |
10-82457M - BOLT Note: Priced Individually [ More info ] Unavailable |
|
  |
10-82428M - SCREW Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-827043M - Bolt, NLA [ More info ]
|
| #21 | 10-83285M | BOLT (4 required per assembly) SERIAL 00016021-0-004280 |
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #22 | 13-82212M | LOCKWASHER (4 required per assembly) |
  |
|
13-82212M - LockWasher - Priced Individually [ More info ]
|
| #23 | 80094M | HOLDER (1 required per assembly) |
  |
|
80094M - HOLDER,NLA [ More info ] Unavailable |
| #24 | 87-80184M | STOP SWITCH (1 required per assembly) |
  |
|
87-80184M - Switch [ More info ]
|
| #26 | 80185M | STOPPER (1 required per assembly) |
  |
|
80185M - STOP,NLA [ More info ] Unavailable |
| #27 | 80143M | THROTTLE WIRE (1 required per assembly) |
  |
|
80143M - THROTTLE Wire, NLA [ More info ] Unavailable |
| #28 | 23-82029M | SLEEVE (1 required per assembly) |
  |
|
23-82029M - Sleeve, NLA [ More info ] Unavailable |
| #29 | 80024M | BAND (1 required per assembly) |
  |
|
80024M - BAND,NLA [ More info ] Unavailable |
| #30 | 23-80157M | BUSHING (1 required per assembly) |
  |
|
23-80157M - Bushing, NLA [ More info ] Unavailable |
| #31 | 23-82851M | BUSHING (4 required per assembly) |
  |
23-82851M - Bushing [ More info ] Unavailable |
|
  |
|
23-804344003 - Collar [ More info ]
|
| #33 | 94785M | COVER (2 required per assembly) SERIAL 00023741-09999999 |
  |
|
94785M - Cover, NLA [ More info ] Unavailable |
| #35 | 82585M | RETAINER (2 required per assembly) |
  |
|
82585M - Cover, NLA [ More info ] Unavailable |
| #36 | 23-81968M | COLLAR (4 required per assembly) SERIAL 00016021-00019075 |
  |
|
23-81968M - COLLAR,NLA [ More info ] Unavailable |
