Parts for Mercury Marine 3.5 HP Crankshaft & Piston
Tap to zoom. Scroll down to order.
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 463-6706M | CRANKSHAFT (1 required per assembly) |
  |
|
463-6706M - Crankshaft,NLA [ More info ] Unavailable |
| #2 | 30-82292M | BEARING (2 required per assembly) |
  |
|
30-82292M - Ball Bearing,NLA [ More info ] Unavailable |
| #3 | NLA | PISTON (STANDARD) (1 required per assembly) |
  |
|
NLA - No Longer Availab [ More info ] Unavailable |
| #3 | 761-8228M | PISTON (45.25 MM O.S.) (AR required per assembly) |
  |
|
761-8228M - Piston, NLA [ More info ] Unavailable |
| #3 | 761-8229M | PISTON (45.50 MM O.S.) (AR required per assembly) |
  |
|
761-8229M - Piston, NLA [ More info ] Unavailable |
| #4 | 31-82835M | BEARING (1 required per assembly) |
  |
|
31-82835M - Bearing, NLA [ More info ]
|
| #5 | 41-80029M | PISTON PIN (1 required per assembly) |
  |
|
41-80029M - PIN-Piston, NLA [ More info ] Unavailable |
| #6 | 53-82342M | CLIP (2 required per assembly) |
  |
|
53-82342M - Snap Ring, NLA [ More info ]
|
| #7 | 39-80109M | PISTON RING SET (STANDARD) (1 required per assembly) |
  |
39-80109M - Piston Ring Set [ More info ] Unavailable |
|
  |
|
39-80109T - Rings, NLA [ More info ] Unavailable |
| #7 | 39-80110M | PISTON RING SET (45.25 MM O.S.) (AR required per assembly) |
  |
|
39-80110M - Piston Ring,NLA [ More info ] Unavailable |
| #8 | 26-82239M | UPPER OIL SEAL (1 required per assembly) |
  |
|
26-82239M - Seal, NLA [ More info ] Unavailable |
| #9 | 26-82241M | LOWER OIL SEAL (1 required per assembly) |
  |
|
26-82241M - Seal, NLA [ More info ] Unavailable |
| #10 | 80108M | SEAL LOCK (1 required per assembly) |
  |
|
80108M - LOCK,NLA [ More info ] Unavailable |
| #11 | 28-81911M | KEY (1 required per assembly) |
  |
|
28-81911M - Key, NLA [ More info ]
|
