Parts for Mercury Marine 200 Bottom Cowl Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 58978A 2 | PLATE ASSEMBLY, MOUNTING (1 required per assembly) |
  |
|
58978A 2 - Plate Assembly [ More info ] Unavailable |
| #2 | 12-36555 | WASHER, NYLON - WATER INLET TUBE (1 required per assembly) |
  |
12-36555 - Washer, Nylon - Tube Seal [ More info ] Unavailable |
|
  |
|
23-86215 - Spacer - Water Tube [ More info ]
|
| #3 | 26-25329 | SEAL, RUBBER - WATER INLET TUBE (1 required per assembly) |
  |
|
26-25329 - Seal - Priced Individually [ More info ]
|
| #4 | 33513 | RETAINER, WATER INLET TUBE SEAL (1 required per assembly) |
  |
|
33513 - Retainer, NLA [ More info ]
|
| #5 | 10-20540 | SCREW, TETAINER TO MOUNTING PLATE (5/8") (1 required per assembly) |
  |
|
10-20540 - Screw, NLA [ More info ] Unavailable |
| #6 | 27-39401 | GASKET, POWERHEAD TO MOUNTING PLATE (1 required per assembly) |
  |
|
27-39401 - Powerhead To Mounting Plate Gasket [ More info ]
|
| #7 | 39622 | SEAL, MOUNTING PLATE TO BOTTOM COWL (1 required per assembly) |
  |
|
39622 - Seal, NLA [ More info ] Unavailable |
| #8 | 27-39402 | GASKET, MOUNTING PLATE TO DRIVE SHAFT HOUSING (1 required per assembly) |
  |
|
27-39402 - Mounting Plate To Drive Shaft Housing Gasket [ More info ]
|
| #9 | 2129-4636A 2 | BOTTOM COWL ASSEMBLY (1 required per assembly) |
  |
2129-4636A 2 - BOTTOM COWL [ More info ] Unavailable |
|
  |
2129-5029A 2 - BOTTOM COWL [ More info ] Unavailable |
|
  |
2129-6182A 3 - BOTTOM COWL [ More info ] Unavailable |
|
  |
|
2129-6416A 2 - BOTTOM COWL,NLA [ More info ] Unavailable |
| #10 | 48472 | COVER, HARNESS HOLE (1 required per assembly) |
  |
|
|
| #11 | 10-61802 | SCREW, COVER TO BOTTOM COWL (7/8") (2 required per assembly) |
  |
|
10-61802 - Screw, NLA [ More info ]
|
| #12 | 46266A 2 | COVER PLATE ASSEMBLY, BOTTOM COWL (1 required per assembly) |
  |
|
46266A 2 - Plate Assembly, NLA [ More info ]
|
| #13 | 39591 | PAD, SOUND - COVER PLATE (1 required per assembly) |
  |
|
39591 - PAD,NLA [ More info ] Unavailable |
| #14 | 10-30663 | SCREW, COVER PLATE TO BOTTOM COWL (3/8") (3 required per assembly) |
  |
10-30663 - Screw Note: Priced Individually [ More info ] Unavailable |
|
  |
|
10-62568 - Screw - Priced Individually [ More info ]
|
| #15 | 39630 | CUSHION, RUBBER - BOTTOM COWL (1 required per assembly) |
  |
|
39630 - CUSHION,NLA [ More info ] Unavailable |
| #16 | 60886 | BOOT, THROTTLE CABLE - BOTTOM COWL (1 required per assembly) |
  |
|
60886 - Boot, NLA [ More info ]
|
| #17 | 39778 | BOOT, FUEL ADAPTOR - BOTTOM COWL (1 required per assembly) |
  |
|
39778 - Boot, NLA [ More info ] Unavailable |
| #18 | 39780 | BOOT, SHIFT CABLE - BOTTOM COWL (1 required per assembly) |
  |
|
39780 - BOOT,NLA [ More info ] Unavailable |
| #19 | 39058 | SEAL, SHIFT HANDLE - BOTTOM COWL (1 required per assembly) |
  |
|
39058 - Shift Handle Seal , NLA [ More info ] Unavailable |
| #20 | 32-34395A 1 | HOSE, TELL TALE - COWL TO CYLINDER BLOCK (11") (1 required per assembly) |
  |
32-34395A 1 - Hose [ More info ] Unavailable |
|
  |
32-99127109 - TUBING-57 INCH [ More info ] Unavailable |
|
  |
32-830756109 - Hose, 57 Inch [ More info ] Unavailable |
|
  |
32-8M0047428 - Hose -57 Inch [ More info ] Unavailable |
|
  |
|
32-8M0108355 - Hose, 57 Inch [ More info ]
|
| #21 | 39180 | ELBOW, TELL TALE HOSE TO CYLINDER BLOCK C-22-25885 IS PART O (1 required per assembly) C-22-25885 IS PART OF CYLINDER BLOCK AND CRANKCASE ASSEMBLY |
  |
|
39180 - Jumper Wire, NLA [ More info ] Unavailable |
| #22 | 52889 | NOZZLE, TELL TALE HOSE TO BOTTOM COWL S (1 required per assembly) PART OF BOTTOM COWL ASSEMBLY |
  |
|
52889 - Nozzle, NLA [ More info ]
|
| #23 | 10-35519 | SCREW, TELL TALE NOZZLE TO BOTTOM COWL (1/2") (1 required per assembly) PART OF BOTTOM COWL ASSEMBLY |
  |
|
10-35519 - Screw, NLA [ More info ]
|
| #24 | 59065A 1 | STOP SWITCH ASSEMBLY (1 required per assembly) |
  |
|
59065A 1 - Switch Assembly, NLA [ More info ]
|
| #25 | 12-59061 | WASHER, STATOR LEAD TO STOP SWITCH (1 required per assembly) |
  |
|
12-59061 - Washer, Stop Switch, NLA [ More info ] Unavailable |
| #26 | 13-21972 | LOCKWASHER, STOP SWITCH CONNECTOR (1 required per assembly) |
  |
|
13-21972 - LockWasher, NLA [ More info ]
|
| #27 | 22-21971 | NUT, STOP SWITCH TO BOTTOM COWL (1 required per assembly) |
  |
|
11-21971 - Nut, NLA [ More info ]
|
| #28 | 38950A 1 | COVER ASSEMBLY, STOP SWITCH (1 required per assembly) |
  |
|
38950A 1 - Cover Assembly [ More info ]
|
| #29 | 13-26996 | LOCKWASHER, STATOR LEAD NUT (1 required per assembly) |
  |
|
13-26996 - LockWasher - Priced Individually [ More info ]
|
| #30 | 11-20645 | NUT, STATOR LEAD TO STOP SWITCH (1 required per assembly) |
  |
|
11-20645 - Nut,(10X32) [ More info ]
|
  |
|
11-68219 - Nut (#10-32) [ More info ]
|
