Parts for Mercury Marine 200 Steering Handle Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 33405A 2 | STEERING HANDLE ASSEMBLY, COMPLETE (1,1,1 required per assembly) |
  |
|
33405A 2 - ARM ASSY ,NLA [ More info ] Unavailable |
| #1 | 27763 | GRIP, RUBBER - STEERING HANDLE BODY (1,1,1 required per assembly) |
  |
|
27763 - Rubber Steering Handle Grip, NLA [ More info ]
|
| #2 | 33404 | BODY AND SHAFT, STEERING HANDLE (1,1,1 required per assembly) |
  |
|
33404 - Body, NLA [ More info ] Unavailable |
| #3 | 31001 | INDICATOR, SPEED/SHIFT - STEERING HANDLE (1,1,1 required per assembly) |
  |
|
31001 - Steering Handle Indicator, Speed and Limit, NLA [ More info ]
|
| #4 | 10-31002 | SCREW, SET - SPEED AND SHIFT INDICATOR (1,1,1 required per assembly) |
  |
|
10-31002 - Screw, NLA [ More info ]
|
| #5 | 10-22290 | SCREW, INDICATOR TO STEERING HANDLE BODY (1,1,1 required per assembly) |
  |
|
10-22290 - SCREW,NLA [ More info ] Unavailable |
| #6 | 23-30677 | BUSHING, NYLON - STEERING HANDLE TO BODY (1,1,1 required per assembly) |
  |
|
23-30677 - Bushing, NLA [ More info ]
|
| #7 | 33405A 1 | STEERING HANDLE ASSEMBLY (1,1,1 required per assembly) |
  |
33405A 1 - ARM ASSY [ More info ] Unavailable |
|
  |
|
49557A 3 - Arm Assembly, NLA [ More info ]
|
| #8 | 23-28100 | BUSHING, NYLON - STEERING HANDLE (1,1,1 required per assembly) |
  |
|
23-28100 - Bushing , NLA [ More info ]
|
| #9 | 12-20084 | WASHER, STEERING HANDLE SHAFT (1,1,1 required per assembly) |
  |
|
12-20084 - Washer, (.328 X .562 X .062) [ More info ]
|
| #10 | 24-26703 | SPRING, STEERING HANDLE SHAFT (1,1,1 required per assembly) |
  |
|
24-26703 - Spring, Steering Handle Shaft,NLA [ More info ] Unavailable |
| #11 | 14-26706 | TAB WASHER, YOKE PIN HOLDING (1,1,1 required per assembly) |
  |
|
14-26706 - Tab Washer, NLA [ More info ]
|
| #12 | 30235 | YOKE, STEERING HANDLE SHAFT (1,1,1 required per assembly) |
  |
|
30235 - Yoke, NLA [ More info ]
|
| #13 | 17-26862 | PIN, YOKE TO STEERING HANDLE SHAFT (1,1,1 required per assembly) |
  |
|
17-26862 - Pin -roll, NLA [ More info ]
|
| #14 | 26711 | PIVOT, STEERING HANDLE TO BRACKET (2,2,2 required per assembly) |
  |
|
26711 - Pivot, NLA [ More info ]
|
| #15 | 15-26707 | SHIM, STEERING HANDLE PIVOT TO BRACKET (2,2,2 required per assembly) |
  |
|
15-26707 - Shim, NLA [ More info ]
|
| #16 | 15-28485 | SHIM, STEERING HANDLE TO ARM BRACKET (2,2,2 required per assembly) |
  |
|
15-28485 - Shim, NLA [ More info ] Unavailable |
| #17 | 10-28592 | SCREW, STEERING HANDLE TO ARM BRACKET (2,2,2 required per assembly) |
  |
|
10-28592 - Screw, NLA [ More info ]
|
| #18 | 33535A 1 | THROTTLE CONTROL SHAFT ASSEMBLY (1,1,1 required per assembly) |
  |
|
33535A 1 - Shaft Assembly, NLA [ More info ]
|
| #19 | 10-26774 | SCREW, THROTTLE CONTROL SHAFT TO BRACKET (1,1,1 required per assembly) |
  |
10-26774 - Screw , Priced Individually [ More info ] Unavailable |
|
  |
10-46923 - Screw , Priced Individually [ More info ] Unavailable |
|
  |
10-28663 - Screw [ More info ] Unavailable |
|
  |
|
10-96138 - Screw [ More info ]
|
| #20 | 33435 | BRACKET, STEERING ARM (1,1,1 required per assembly) |
  |
|
33435 - Bracket, NLA [ More info ]
|
| #21 | 30970 | BOOT, RUBBER - THROTTLE CONTROL SHAFT (1,1,1 required per assembly) |
  |
|
30970 - Boot, NLA [ More info ]
|
| #22 | 10-33473 | SCREW, STEERING ARM BRACKET TO SADDLE (3,3,3 required per assembly) |
  |
10-33473 - Screw [ More info ] Unavailable |
|
  |
|
10-53460 - Screw, NLA [ More info ]
|
| #23 | 11-29250 | NUT, STEERING ARM BRACKET FASTENING SCREW (3,3,3 required per assembly) |
  |
|
11-29250 - Nut (5/16-24) [ More info ]
|
