Parts for Mercury Marine Model 200, 20 HP Starter Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 75349A 2 | HOUSING ASSEMBLY, STARTER (MANUAL) (1 required per assembly) |
  |
|
75349A 2 - HSG ASY,NLA [ More info ] Unavailable |
| #2 | 10-37562 | SCREW (1 required per assembly) STARTER HOUSING TO CYLINDER BLOCK (1") (MANUAL) |
  |
|
10-37562 - Screw - Priced Individually [ More info ] Unavailable |
| #3 | 13-26993 | LOCKWASHER (1 required per assembly) HOUSING TO CYLNDER BLOCK SCREW (MANUAL) |
  |
|
13-26993 - LockWasher - Priced Individually [ More info ]
|
  |
|
138M0204647 - LOCKWASHER, Priced Individually [ More info ]
|
| #4 | 10-56500 | SCREW (1 required per assembly) STARTER HOUSING TO CRANKCASE (1 1/4") (MANUAL) |
  |
|
10-56500 - Screw, NLA [ More info ]
|
| #4 | 10-69029 | SCREW (1 required per assembly) STARTER HOUSING TO CRANKCASE (1 3/4") (MANUAL) |
  |
|
10-69029 - Screw, NLA [ More info ]
|
| #5 | 11-35888 | NUT (2 required per assembly) STARTER HOUSING TO CRANKCASE SCREW (MANUAL) |
  |
|
11-35888 - Nut (1/4-28) [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #6 | 55860 | PULLEY, STARTER CABLE (MANUAL) (1 required per assembly) |
  |
|
55860 - Starter Pulley [ More info ]
|
| #7 | 10-37892 | SCREW, PULLEY TO STARTER (1")(MANUAL) (1 required per assembly) |
  |
|
10-37892 - Screw, NLA [ More info ]
|
| #8 | 53111 | RETAINER, PULLEY SCRWE (MANUAL) (1 required per assembly) |
  |
|
53111 - Retainer [ More info ]
|
  |
|
94121 - Retainer, NLA [ More info ]
|
| #9 | 23-30977 | SPACER, PULLEY SCRW (MANUAL) (1 required per assembly) |
  |
23-30977 - Spacer [ More info ] Unavailable |
|
  |
23-30977 1 - SPACER [ More info ] Unavailable |
|
  |
|
23-30977 2 - Spacer [ More info ]
|
| #10 | 11-20110 | NUT, PULLEY SCREW (MANUAL) (1 required per assembly) |
  |
|
11-20110 - Nut (M10X32) [ More info ]
|
| #11 | 11-20166 | NUT, SHEAVE SHAFT (LEFT HAND THREAD) (1 required per assembly) (MANUAL) |
  |
|
11-20166 - Nut, Sheave Shaft ( Left Hand Thread) [ More info ]
|
| #12 | 14-61004 | TAB WASHER, SHEAVE SHAFT NUT (MANUAL) (1 required per assembly) |
  |
|
14-61004 - Tab Washer - Priced Individually [ More info ]
|
| #13 | 65890 | RETAINER, STARTER SPRING (MANUAL) (1 required per assembly) |
  |
|
65890 -Starter Spring Retainer [ More info ] Unavailable |
| #14 | 23-28912 | SPACER, SHEAVE SHAFT (MANUAL) (1 required per assembly) |
  |
|
23-28912 - Bushing, NLA [ More info ]
|
| #15 | 24-29340A 1 | SPRING, STARTER REWIND (MANUAL) (1 required per assembly) |
  |
24-29340A 1 - Spring, Starter Rewind [ More info ] Unavailable |
|
  |
24-29340T 1 - Recoil Spring [ More info ] Unavailable |
|
  |
|
24-29340T02 - Recoil Spring, NLA [ More info ] Unavailable |
  |
|
18-6506 - Rewind Spring 24-29340A1 [ More info ]
|
| #16 | 76321A 1 | STARTER SJAVE ASSEMBLY (MANUAL) (1 required per assembly) |
  |
|
76321A 1 - Sheave Assembly, NLA [ More info ] Unavailable |
| #17 | 13-36206 | WASHER, WAVE - STARTER PAWL (MANUAL) (3 required per assembly) |
  |
|
13-36206 - Wave Washer - Priced Individually [ More info ] Unavailable |
| #18 | 30596 | PAWL, STARTER (MANUAL) (3 required per assembly) |
  |
|
30596 - Starter Pawl, NLA [ More info ]
|
| #19 | 23-28919 | BUSHING, NYLON - SHEAVE SHAFT SPACER (MANUAL) (1 required per assembly) |
  |
|
23-28919 - Bushing , NLA [ More info ]
|
| #20 | 23-61005 | SPACER, SHEAVE SHAFT (MANUAL) (1 required per assembly) |
  |
|
23-61005 - Spacer - Sheave Shaft [ More info ]
|
| #21 | 26179 | RETAINER (1 required per assembly) STARTER SHEAVR TO PLATE (MANUAL) |
  |
|
26179 - Retainer, NLA [ More info ]
|
| #22 | 12-35559 | WASHER (1 required per assembly) STARTER SHEAVE RETAINER (MANUAL) |
  |
|
12-35559 - Washer - Priced Individually [ More info ]
|
| #23 | 13-20160 | WASHER (1 required per assembly) WAVE - STARTER SHEAVE TENSION (MANUAL) |
  |
|
13-20160 - Wave Washer - Priced Individually [ More info ]
|
| #24 | 30595 | PLATE (1 required per assembly) RETAINER - STARTER PAWLER (MANUAL) |
  |
|
30595 - Retainer Starter Pawl Plate [ More info ]
|
| #25 | 12-57860 | WASHER (1 required per assembly) WEAR - SHEAVE SHAFT (MANUAL) |
  |
|
12-57860 - Washer, Nylon - Bracket, NLA [ More info ]
|
| #27 | 61003 | SHAFT, SHEAVE (MANUAL) (1 required per assembly) |
  |
|
61003 - Sheave Shaft, NLA [ More info ]
|
| #28 | 76300 | BRACKET, MOUNTING - TOP COWL (REAR) (1 required per assembly) |
  |
|
76300 - Bracket, NLA [ More info ] Unavailable |
| #30 | 57927 | MOUNT, RUBBER - SUPPORT BRACKET (3 required per assembly) |
  |
|
57927 - Rubber Mount, NLA [ More info ]
|
| #31 | 11-20361 | NUT (6 required per assembly) RUBBER MOUNT TO SUPPORT BRACKET |
  |
|
|
  |
|
11-826708 9 - Nut - Priced Individually [ More info ]
|
| #32 | 46934A 1 | GROUND WIRE ASS'Y, REAR BRACKET (1 required per assembly) |
  |
|
46934A 1 - Cable - GROUND,NLA [ More info ] Unavailable |
| #32 | 57-76181 | GROUND WIRE ASS'Y, REAR BRACKET (1 required per assembly) |
  |
|
84-76181 - Wire, NLA [ More info ]
|
| #33 | 10-62568 | SCREW (1 required per assembly) GROUND WIRE TO CYLINDER BLOCK (3/8") |
  |
|
10-62568 - Screw - Priced Individually [ More info ]
|
| #34 | 10-69052 | SCREW (1 required per assembly) GROUND WIRE TO CYLINDER BLOCK |
  |
10-69052 - Screw [ More info ] Unavailable |
|
  |
|
10-98256 - Screw [ More info ]
|
| #35 | 60299 | RETAINER, HIGH TENSION WIRES (2 required per assembly) |
  |
|
60299 - Retainer, NLA [ More info ] Unavailable |
| #36 | 10-69079 | SCREW (2 required per assembly) RETAINER TO REAR SUPPORT BRACKET |
  |
|
10-69079 - Screw [ More info ]
|
| #37 | 76097 | BRACKET, MOUNTING - TOP COWL (FRONT) (1 required per assembly) |
  |
|
76097 - Bracket, NLA [ More info ] Unavailable |
| #39 | 60577 | MOUNT, RUBBER - SUPPORT BRACKET (4 required per assembly) |
  |
|
60577 - Mount, NLA [ More info ]
|
| #40 | 12-21631 | WASHER, RUBBER MOUNT (AR required per assembly) |
  |
|
12-21631 - Washer, (.255 X .625 X .0312) [ More info ]
|
  |
|
12-69056 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ]
|
| #41 | 13-26992 | LOCKWASHER, RUBBER MOUNT (4 required per assembly) |
  |
|
13-26992 - LockWasher - Priced Individually [ More info ]
|
| #42 | 11-29598 | NUT (4 required per assembly) RUBBER MOUNT TO SUPPORT BRACKETS |
  |
|
11-29598 - Nut (1/4-28) [ More info ]
|
| #43 | 50-28985A 1 | STARTER CABLE ASSEMBLY (MANUAL) (1 required per assembly) |
  |
50-28985A 1 - ROPE Note: Priced Individually [ More info ] Unavailable |
|
  |
50-28985A 2 - Starter Rope Assembly [ More info ] Unavailable |
|
  |
50-12066A 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
50-12066Q 9 - Starter Rope , Priced Individually [ More info ] Unavailable |
|
  |
|
50-12066Q10 - Starter Rope - Priced Individually [ More info ]
|
  |
|
18-4915 - Pull Rope, 50-12066Q9 [ More info ]
|
  |
|
50-12066K10 - Starter Rope - Priced Individually [ More info ]
|
| #44 | 30782 | HANDLE, STARTER CABLE (MANUAL) (1 required per assembly) UNITED STATES 4709593 THRU 4819248 AUSTRALIA 8045199 THRU 8049299 BELGIUM 9157230 THRU 9171005 CANADA 7098523 THRU 7108947 |
  |
|
30782 - Starter Cable Handle [ More info ]
|
  |
|
79470A 1 - Rope Start Handle and Retainer [ More info ]
|
| #45 | 28748 | RETAINER (1 required per assembly) STARTER CABLE AND HANDLE (MANUAL) UNITED STATES 4709593 THRU 4819248 AUSTRALIA 8045199 THRU 8049299 BELGIUM 9157230 THRU 9171005 CANADA 7098523 THRU 7108947 |
  |
|
28748 - Starter Cable Handle Retainer - Priced Individually [ More info ]
|
  |
77997A 1 - Retainer - Priced Individually [ More info ] Unavailable |
|
| #44 | 77998 | HANDLE, START CABLE (MANUAL) (1 required per assembly) UNITED STATES 4819249 THRU 5183392 AUSTRALIA 8049300 THRU 8057144 BELGIUM 9171006 THRU 9214455 CANADA 7108948 THRU 7124212 |
  |
|
77998 - Starter Cable Handle [ More info ] Unavailable |
| #45 | 77997A 1 | RETAINER (1 required per assembly) STARTER CABLE AND HANDLE (MANUAL) UNITED STATES 4819249 THRU 5183392 AUSTRALIA 8049300 THRU 8057144 BELGIUM 9171006 THRU 9214455 CANADA 7108948 THRU 7124212 |
|
77997A 1 - Retainer - Priced Individually [ More info ] Unavailable |
|
| #44 45 | 79470A 1 | HANDLE AND RETAINER ASSEMBLY (1 required per assembly) (MANUAL) UNITED STATES 5183393 AND UP AUSTRALIA 8057145 AND UP BELGIUM 9214456 AND UP CANADA 7124213 AND UP |
| #46 | 15-20219 | SHIM, SHEAVE SHAFT - MANUAL (AR required per assembly) |
  |
|
15-20219 - Shim, NLA [ More info ] Unavailable |
