Parts for Mercury Marine 110 Ignition Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 339-5209A 3 | STATOR ASSEMBLY (1 required per assembly) |
  |
|
339-5209A 3 - Lamination [ More info ]
|
  |
|
339-5209A 9 - Lamination Assembly, NLA [ More info ] Unavailable |
| #2 | 10-66707 | SCREW, STATOR TO END CAP (7/8") (3 required per assembly) |
  |
|
10-66707 - Screw, NLA [ More info ] Unavailable |
| #3 | 10-35400 | SCREW, STATOR TO END CAP (3/8") (1 required per assembly) |
  |
|
10-35400 - Screw - Priced Individually, NLA [ More info ]
|
| #4 | 339-6119A 1 | COIL ASSEMBLY (5 1/2" AND 6 3/8" LEADS) (1 required per assembly) |
  |
|
339-6119A 1 - Stator Coil Assembly, NLA [ More info ] Unavailable |
| #4 | 339-6120A 1 | COIL ASSEMBLY (1 3/4" AND 3 1/2" LEADS) (1 required per assembly) |
  |
|
339-6120A 1 - Stator Coil Assembly, NLA [ More info ] Unavailable |
| #5 | 54-59538 | CLIP, COIL RETAINING (2 required per assembly) |
  |
|
54-59538 - Clip, NLA [ More info ]
|
| #6 | 54-65927 | CLIP, COIL RETAINING (2 required per assembly) |
  |
|
54-65927 - Clip, NLA [ More info ]
|
| #7 | 86-74474 | TERMINAL BLOCK, STATOR (1 required per assembly) |
  |
86-74474 - Terminal Block,NLA [ More info ] Unavailable |
|
  |
|
86-85365 - Terminal Block,NLA [ More info ]
|
| #8 | 10-20646 | SCREW, TERMINAL BLOCK TO STATOR (5/8") (1 required per assembly) |
  |
10-20646 - Screw - Priced Individually [ More info ] Unavailable |
|
  |
|
10-38055 - Screw - Priced Individually [ More info ]
|
| #9 | 11-46438 | NUT, TERMINAL BLOCK SCREW (1 required per assembly) |
  |
|
11-46438 - Nut (#10-32) [ More info ]
|
| #10 | 10-22654 | SCREW, LEADS TO TERMINAL BLOCK (3/8") (1 required per assembly) |
  |
|
10-22654 - Screw, NLA [ More info ] Unavailable |
| #11 | 338-5286A 6 | TRIGGER HOUSING ASSEMBLY (1 required per assembly) |
  |
338-5286A 6 - TRIGGER ASSY [ More info ] Unavailable |
|
  |
338-7283A 1 - TRIGGER PLATE [ More info ] Unavailable |
|
  |
338-7283A 2 - Trigger [ More info ] Unavailable |
|
  |
|
338-7283A 3 - Trigger Plate, NLA, $35 Refundable Core Charge will be Added [ More info ]
|
| #14 | 66371 | LINK, TRIGGER HOUSING TO THROTTLE LEVER (1 required per assembly) |
  |
66371 - LINK,NLA [ More info ] Unavailable |
|
  |
|
42501 - LINK,NLA [ More info ] Unavailable |
| #15 | 11-65110 | NUT, PUSH - LINK TO TRIGGER HOUSING (1 required per assembly) |
  |
|
|
| #16 | 339-5287A 4 | SWITCH BOX (1 required per assembly) |
  |
339-5287A 4 - Switch Box [ More info ] Unavailable |
|
  |
|
339-6222A10 - Switch Box [ More info ] Unavailable |
  |
|
18-99218 - Switch Box, 339-5787, 6222A10 114-6222 [ More info ]
|
  |
|
|
| #17 | 10-69022 | SCREW, SWITCH ATTACHING (1/2") (2 required per assembly) |
  |
|
10-69022 - Screw [ More info ]
|
| #18 | 12-56681 | WASHER, SWITCH BOX ATTACHING SCREW (2 required per assembly) |
  |
|
12-56681 - Washer, (.203 X .500 X .032) [ More info ]
|
  |
|
128M0204666 - WASHER Note: Priced Individually [ More info ]
|
| #19 | 61990 | STA-STRAP (5 required per assembly) |
  |
|
61990 - Tie Strap - Priced Individually [ More info ]
|
| #20 | 10-45218 | SCREW, GROUND LEAD TO CYLINDER BLOCK (1 required per assembly) |
  |
|
10-45218 - Screw, NLA [ More info ] Unavailable |
