Parts for Mercury Marine 100 HP EFI (4-Stroke) Cylinder Block
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 61-897148A09 | LONG BLOCK ASSEMBLY, 75/80/90/100 (1 required per assembly) |
  |
61-897148A09 - Powerhead L4NA 4S [ More info ] Unavailable |
|
  |
|
8M8033014 - PH L4NA 4S [ More info ] Unavailable |
| # | 61-897148A08 | LONG BLOCK ASSEMBLY, 115 (1 required per assembly) |
  |
|
61-897148A08 - Powerhead L4NA 4S [ More info ] Unavailable |
| # | 27-897534A07 | GASKET SET, Powerhead (1 required per assembly) |
  |
|
27-897534A07 - Powerhead Gasket Set [ More info ]
|
| #1 | 800-880504A12 | CYLINDER BLOCK ASSEMBLY (1 required per assembly) |
  |
|
800-880504A12 - Cylinder Block [ More info ] Unavailable |
| #2 | 8M0007889 | BRACKET (2 required per assembly) SN# 1B759587 & Below |
  |
|
8M0007889 - Bracket [ More info ]
|
| #3 | 10-885526 40 | SCREW, (M8 x 40), NOTE:No Longer included with Longblock (4 required per assembly) SN# 1B759587 & Below |
  |
|
10-885526 40 - Screw - Priced Individually [ More info ] Unavailable |
| #4 | 17-43044 | PIN, Dowel - Without Hole (.375 x .625) (2 required per assembly) |
  |
|
17-43044 - Pin -Dowel-solid [ More info ]
|
| #5 | 23-893392001 | DAMPER (10 required per assembly) |
  |
|
23-893392001 - Bushing [ More info ]
|
| #6 | 19-889767 | PLUG, (12 mm) (5 required per assembly) |
  |
|
19-889767 - Plug - Priced Individually [ More info ]
|
| #7 | 19-896951 | PLUG, (24 mm) (2 required per assembly) |
  |
|
19-896951 - Plug [ More info ]
|
| #8 | 19-8M0010474 | PLUG, (14 mm) (1 required per assembly) |
  |
19-8M0010474 - Plug [ More info ] Unavailable |
|
  |
198M0048160 - Plug [ More info ] Unavailable |
|
  |
|
198M0087449 - PLUG [ More info ]
|
| #9 | 12-892573001 | WASHER (10 required per assembly) |
  |
|
12-892573001 - Washer - Priced Individually [ More info ]
|
| #10 | 10-896923 | SCREW, (M10 x 342) (10 required per assembly) |
  |
10-896923 - SCREW [ More info ] Unavailable |
|
  |
10-8M0021876 - Screw [ More info ] Unavailable |
|
  |
|
108M4501000 - Screw [ More info ]
|
| #11 | 16-897599 | STUD, (M8 x 55) (2 required per assembly) |
  |
16-897599 - STUD [ More info ] Unavailable |
|
  |
|
16-8M0000275 - Stud [ More info ]
|
| #12 | 11-826365 | NUT, (M8) (2 required per assembly) |
  |
|
11-826365 - Nut (M8) [ More info ]
|
| #13 | 16-897677 | STUD, (M10 x 1.5) (6 required per assembly) |
  |
16-897677 - STUD Note: Priced Individually [ More info ] Unavailable |
|
  |
|
16-8M0010471 - Stud - Priced Individually [ More info ]
|
| #14 | 12-856774 | WASHER, (.406 x .750 x .105) Stainless Steel (6 required per assembly) |
  |
12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable |
|
  |
|
128M0214963 - WASHER Note: Priced Individually [ More info ]
|
| #15 | 11-884412 | NUT (6 required per assembly) |
  |
|
11-884412 - Nut - Priced Individually [ More info ]
|
| #16 | 10-892086120 | SCREW, (M10 x 120) (2 required per assembly) |
  |
10-892086120 - Screw [ More info ] Unavailable |
|
  |
|
108M0103829 - Screw [ More info ]
|
| #17 | 10-895810050 | SCREW, (M8 x 50) (2 required per assembly) |
  |
10-895810050 - Screw [ More info ] Unavailable |
|
  |
|
10-8M0193659 - SCREW [ More info ] Unavailable |
| #18 | 828358 2 | SENSOR (1 required per assembly) |
  |
828358 2 - Sensor Assembly [ More info ] Unavailable |
|
  |
8M0030022 - Sensor Assembly [ More info ] Unavailable |
|
  |
|
8M0082988 - Sensor Assembly [ More info ]
|
| #19 | 10-40011106 | SCREW, (M5 x 13) Stainless Steel (2 required per assembly) |
  |
|
10-40011106 - Screw [ More info ]
|
| #20 | 885342002 | SENSOR ASSEMBLY (1 required per assembly) |
  |
885342002 - Sensor Assembly [ More info ] Unavailable |
|
  |
|
8M0148668 - Temperature Sensor [ More info ]
|
| #21 | 25-896699 | O-RING, (1.78 mm x .08 mm) (1 required per assembly) |
  |
|
25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ]
|
| #22 | 27-896277006 | GASKET, Head (1 required per assembly) SN# 1B494359 & Below |
  |
27-896277006 - Cylinder Head To Block Gasket [ More info ] Unavailable |
|
  |
|
27-8M0024565 - Cylinder Head To Block Gasket [ More info ]
|
| #22 | 27-8M0024565 | GASKET (1 required per assembly) SN# 1B494360 & Up |
| #23 | 880559 | GUIDE, Fixed (1 required per assembly) |
  |
|
880559 - Guide -fixed [ More info ]
|
| #24 | 880557 | GUIDE, Moveable (1 required per assembly) |
  |
|
880557 - Guide -moveable [ More info ]
|
| #25 | 10-892456045 | SCREW (2 required per assembly) |
  |
|
10-892456045 - Screw - Priced Individually [ More info ]
|
| #26 | 27-897534 | GASKET, Block to Adaptor (1 required per assembly) SN# 1B500083 & Below |
  |
27-897534 - Block To Adaptor Gasket [ More info ] Unavailable |
|
  |
|
27-8M0024563 - Block To Adaptor Gasket [ More info ]
|
| #26 | 27-8M0024563 | GASKET, Block to Adaptor (1 required per assembly) SN# 1B500084 & Up |
| #27 | 19-891953 | PLUG, (18 mm) (1 required per assembly) |
  |
|
19-891953 - Plug [ More info ]
|
| #28 | 10-895810070 | SCREW, (M8 x 70) (2 required per assembly) |
  |
|
10-895810070 - Screw - Priced Individually [ More info ]
|
| #29 | 10-895810090 | SCREW, (M8 x 90) (8 required per assembly) |
  |
|
10-895810090 - Screw - Priced Individually [ More info ]
|
