Parts for Mercury Marine 100 HP (4 Cylinder) Gear Housing, Driveshaft

Revise Search: All Models > 100 HP (4 Cylinder) > 9523034 - 9793576 (Belgium) > Gear Housing, Driveshaft

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

LOOKING FOR A PROP?
• Try our prop finder.

COMPLETE GEARCASE?
• Aftermarket gearcase may be available for less than $900 USD. 70 HP+ only. Please call.

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	1667-9011A26	GEAR HOUSING ASSEMBLY, Long, Gray (1 required per assembly)
		1667-9011A26 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A63 - GR-LONG Gear Housing [ More info ] Unavailable
		1667-9011A83 - GEAR HOUSING-GRAY [ More info ] Unavailable
		1667-9011G41 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011G99 - GEAR HSG-L-GRAY [ More info ] Unavailable
#	1667-9011A25	GEAR HOUSING ASSEMBLY, Long, Black (1 required per assembly)
		1667-9011A25 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A62 - BL-LONG Gear Housing [ More info ] Unavailable
		1667-9011A81 - GEAR HOUSING-BLAC [ More info ] Unavailable
		1667-9011G39 -Gear Housing Assembly [ More info ] Unavailable
		1667-9011J 7 - Gearcase 100-125 Lg Black [ More info ] Unavailable
#	1667-9011A49	GEAR HOUSING ASSEMBLY, X-Long, Oyster (1 required per assembly)
		1667-9011A49 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A28 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A65 - GR-XL GEAR HSG [ More info ] Unavailable
		1667-9011A84 - GEAR HSG-X LONG [ More info ] Unavailable
		1667-9011G42 - Gear Housing Assembly [ More info ] $749.00 $634.40 1 In Stock.
#	1667-9011A28	GEAR HOUSING ASSEMBLY, X-Long, Gray (1 required per assembly)
#	1667-9011A27	GEAR HOUSING ASSEMBLY, X-Long, Black (1 required per assembly)
		1667-9011A27 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A64 - BL-XL GEAR HSG [ More info ] Unavailable
		1667-9011A82 - GEAR HOUSING-BLAC [ More info ] Unavailable
		1667-9011G40 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011J10 - Gearcase 100-125 Kl Black [ More info ] Unavailable
#	1667-9011A30	GEAR HOUSING ASSEMBLY, Long, Oyster (1 required per assembly)
		1667-9011A30 - Gear Housing Assembly [ More info ] Unavailable
#1	1667-9011A 6	GEAR HOUSING ASSEMBLY, Black (1 required per assembly)
		1667-9011A 6 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A73 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011T73 - Gear Housing -Basic-bl [ More info ] $1,925.49 Available to Order: Shipping delay up to 10 days.
#1	1667-9011A 8	GEAR HOUSING ASSEMBLY, Gray (1 required per assembly)
		1667-9011A 8 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A74 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011T74 - Ord 1667-9011T73, NLA [ More info ] Unavailable
#1	1667-9011A29	GEAR HOUSING ASSEMBLY, Oyster (1 required per assembly)
		1667-9011A29 - Gear Housing Assembly [ More info ] Unavailable
		1667-9011A 8 - Gear Housing Assembly [ More info ] Unavailable
#2	17-43043	PIN, Dowel - With Hole (.375 x .625) , Front, Quantity Of Two On X-Long (1 required per assembly)
		17-43043 - Pin, Dowel [ More info ] $1.87 10+ In Stock.
		178M0084244 - Pin - Dowel [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#3	10-28653	SCREW, (#10-32 x 0.25), New Design Used For Reference Number 6, 7 (1 required per assembly)
		10-28653 - Screw - Priced Individually [ More info ] $3.99 10+ In Stock.
#4	19643	SEAL (1 required per assembly)
		19643 - Seal - Priced Individually [ More info ] $1.50 10+ In Stock.
#5	10-79953	SCREW, (.375-16 x .250), Magnetic (1 required per assembly)
		10-79953 - Drain Screw ONLY, Priced Individually [ More info ] Unavailable
		10-79953A 2 - Drain Screw Kit [ More info ] Unavailable
		10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable
		10-79953Q04 - Screw Kit - Priced Individually [ More info ] $7.49 10+ In Stock.
		18-2244 - Plug Kit, 10-79953A2 [ More info ] $3.79 10+ In Stock.
		10-79953K04 - Drain Screw - Priced Individually [ More info ] $8.19 6 In Stock.
#6	12-19183	WASHER, Fiber (3 required per assembly)
		12-19183 - Washer (3/8 Inch Screw) [ More info ] Unavailable
		12-19183 2 - Washer - Priced Individually [ More info ] Unavailable
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 10+ In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 6 In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#7	22-67892	SCREW, Magnetic (2 required per assembly)
		22-67892 - Plug - Priced Individually [ More info ] $5.45 1 In Stock.
		22-67892A 1 - Drain Plug [ More info ] Unavailable
		22-67892A05 - Drain Plug Kit [ More info ] Unavailable
		22-67892A06 - Drain Plug Kit [ More info ] Unavailable
		22-8M0058389 - Screw Kit - Priced Individually [ More info ] $11.69 10+ In Stock.
		18-23751-9 - Drain Screw , Package of 50 [ More info ] $346.09 In Stock
		18-2375 - Plug, 22-67892A1 [ More info ] $7.16 10+ In Stock.
		10-02683 - Drain Screw [ More info ] $6.39 $6.03 2 In Stock.
#8	17-43044	PIN, Dowel - Without Hole (.375 x .625), Rear, Quantity Of Two On X-Long (1 required per assembly)
		17-43044 - Pin -Dowel-solid [ More info ] $2.49 1 In Stock.
#9	31640 3	TRIM TAB (1 required per assembly)
		31640 3 - 31640 3 - TRIM TAB [ More info ] Unavailable Replaced by -31640 4
		31640 4 - Anode/Trim Tab [ More info ] Unavailable
		97-31640Q4 - Anode/Trim Tab [ More info ] $18.69 9 In Stock.
		18-6241 - Trim Tab Anode, Magnesium, 31640 [ More info ] $24.39 $24.18 In Stock
		18-6011A - Trim Tab Anode, Aluminum [ More info ] $16.90 1 In Stock.
		18-6011 - Trim Tab, Zinc, 31640A1 [ More info ] $21.77 9 In Stock.
		97-31640T 4 - Trim Tab Anode [ More info ] $20.49 8 In Stock.
#10	10-15942	SCREW, (.437-14 x 1.250) (1 required per assembly)
		10-15942 - Screw [ More info ] Unavailable
		10-825427 - Screw [ More info ] $6.99 3 In Stock.
#11	12-45176	WASHER, (.453 x .812 x .105) Stainless Steel (1 required per assembly)
		12-45176 - Washer, (.453 X .812 X .105) [ More info ] $1.50 6 In Stock.
#12	43040A 1	CARRIER ASSEMBLY (1 required per assembly)
		43040A 1 - Carrier Assembly [ More info ] Unavailable
		43040T 1 - Carrier Assembly [ More info ] $78.99 Available to Order: Shipping delay up to 10 days.
#12A	43046	TUBE, Oiler (1 required per assembly)
		43046 - Oiler Tube [ More info ] $28.99 Available to Order: Shipping delay up to 10 days.
#13	43-19672A 1	GEAR ASSEMBLY, Pinion (1 required per assembly)
		43-19672A 1 - Pinion Gear [ More info ] Unavailable
		43-881259A 1 - Gear Set [ More info ] $1,025.99 Available to Order: Shipping delay up to 10 days.
#14	11-35921	NUT, (.625-18) (1 required per assembly)
		11-35921 - Nut, (.625-18) [ More info ] $7.99 10+ In Stock.
		18-3719 - Nut, 11-35921, 314730 [ More info ] $5.19 1 In Stock.
		18-2359 - Nut Kit [ More info ] $5.19 $3.51 Available to Order: Shipping delay up to 10 days.
#15	76039	CAM, Shift Control (1 required per assembly)
		76039 - Shift Cam, Priced Individually [ More info ] Unavailable
		76039 4 - Shift Cam - Priced Individually [ More info ] $39.08 6 In Stock.
#16	31-42677A 1	BEARING ASSEMBLY, Tapered Roller (1 required per assembly)
		31-42677A 1 - Tapered Roller Bearing [ More info ] $56.49 Available to Order: Shipping delay up to 10 days.
#17	15-44492A 1	SHIM SET (1 required per assembly)
		15-44492A 1 - Shim Set [ More info ] $20.72 10+ In Stock.
#18	45-43031A 1	DRIVESHAFT ASSEMBLY, Long (1 required per assembly)
		45-43031A 1 - Drive Shaft Assembly -l [ More info ] $787.49 Available to Order: Shipping delay up to 10 days.
		92-205-04-20A - Drive Shaft replaces 45-43031A 1 [ More info ] $382.83 $382.83 Available to Order
#18	45-43032A 4	DRIVESHAFT ASSEMBLY, X-Long (1 required per assembly)
		45-43032A 4 - Drive Shaft Assembly -xl [ More info ] $729.99 Available to Order: Shipping delay up to 10 days.
		92-205-04-25A - Drive Shaft replaces 45-43032A 4 [ More info ] $344.97 $344.97 Available to Order
#19	42461A 1	SLEEVE/RING KIT (1 required per assembly)
		42461A 1 - Sleeve/Ring Kit [ More info ] $27.31 1 In Stock.
#20	43055A 4	COVER ASSEMBLY, Water Pump, Aluminum Cover (1 required per assembly)
		43055A 4 - NLA, New part # 46-8M0113262 [ More info ] Unavailable
		46-8M0113262 - Water Pump Cover Assembly [ More info ] $148.99 In Stock
#21	27-43047 2	GASKET, Aluminum Cover (1 required per assembly)
		27-43047 2 - Gasket [ More info ] Unavailable
#22	26-43036	SEAL, Oil, Lower, Aluminum Cover (1 required per assembly)
		26-43036 - Seal [ More info ] $19.89 In Stock
		18-0522 - Seal, 26-43036 [ More info ] $12.03 4 In Stock.
#23	26-43035	SEAL, Oil, Upper, Aluminum Cover (1 required per assembly)
		26-43035 - Seal [ More info ] $19.89 In Stock
		26-8M0245495 - OIL SEAL [ More info ] Unavailable
		18-0583 - Seal, 26-43035 [ More info ] $14.01 4 In Stock.
#24	27-43033 1	GASKET, Aluminum Cover (1 required per assembly)
		27-43033 1 - Face Plate To Cover Gasket [ More info ] $11.09 10+ In Stock.
#25	27-43034 1	GASKET, Aluminum Cover (1 required per assembly) (Use With Reference Number 30 And 31)
		27-43034 1 - Gasket [ More info ] $4.79 2 In Stock.
#25	27-817277	GASKET (1 required per assembly) (Use Without Reference Number 30 And 31)
		27-817277 - Impeller Housing Gasket [ More info ] Unavailable
		27-817277 1 - Gasket -Sold each [ More info ] $5.69 4 In Stock.
		18-2566-9 - Gasket 27-817277 2-Pack [ More info ] $8.67 10+ In Stock.
#20	19282A 1	COVER ASSEMBLY, Plastic Cover (1 required per assembly)
		19282A 1 - 19282A 1 - COVER ASSEMBLY [ More info ] Unavailable Replaced by -19282A 2
		19282A 2 - Cover Assembly [ More info ] Unavailable
#20	19282A 2	COVER ASSEMBLY, Aluminum Cover (1 required per assembly)
#26	46-43024A 3	PUMP ASSEMBLY, Water, Use With Reference Number 30 And 31 (1 required per assembly)
		46-43024A 3 - Water Pump Housing Upper [ More info ] Unavailable
		817275A 2 - Water Pump Housing Upper [ More info ] $104.99 In Stock
		18-3572 - Water Pump Housing Kit 817275A2 [ More info ] $89.99 $85.72 8 In Stock.
#27	NLA	No Longer Available, Order 817275A2 (1 required per assembly) (Use With Reference Number 30 And 31)
		NLA - No Longer Availab [ More info ] Unavailable
#28	10-40003 32	SCREW, (M6 x 35), Use With Reference Number 30 And 31 (4 required per assembly)
		10-40003 32 - Screw [ More info ] $2.29 Available to Order: Shipping delay up to 10 days.
#29	43023	SEAL, Use With Reference Number 30 And 31 (1 required per assembly)
		43023 - Seal [ More info ] Unavailable
		8M0204658 - SEAL [ More info ] $14.89 7 In Stock.
#30	12-40023 15	WASHER, Use With Reference Number 30 And 31 (4 required per assembly)
		12-40023 15 - Washer - Priced Individually [ More info ] $0.80 Available to Order: Shipping delay up to 10 days.
#31	23-43045	INSULATOR, Use With Reference Number 30 And 31 (4 required per assembly)
		23-43045 - Insulator - Priced Individually [ More info ] Unavailable
		238M0204659 - INSULATOR Note: Priced Individually [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#26	817275A 2	HOUSING KIT, Upper Water Pump (1 required per assembly) (Use Without Reference Number 30 And 31)
#27	817276	FACEPLATE, Use Without Reference Number 30 And 31 (1 required per assembly)
		817276 - Face Plate, Water Pump [ More info ] Unavailable
		817276 1 - Water Pump Face Plate [ More info ] Unavailable
		8M0204709 - Water Pump Faceplate, Outboard [ More info ] $14.59 Available to Order: Shipping delay up to 10 days.
#28	10-40011130	SCREW, (M6 x 30) Stainless Steel, Use Without Reference Number 30 And 31 (4 required per assembly)
		10-40011130 - Screw [ More info ] $3.19 Available to Order: Shipping delay up to 10 days.
#32	28-43037	KEY (1 required per assembly)
		28-43037 - Key [ More info ] Unavailable
		28-8M0032833 - Key [ More info ] Unavailable
		288M0204723 - KEY Note: Priced Individually [ More info ] $4.39 1 In Stock.
#33	47-43026 2	IMPELLER (1 required per assembly)
		47-43026 2 - Water Pump Impeller [ More info ] Unavailable
		47-43026T 2 - Water Pump Impeller [ More info ] $36.49 2 In Stock.
		18-3056 - Impeller 47-43026-2 [ More info ] $26.99 $26.12 10+ In Stock.
		47-43026Q02 - Water Pump Impeller [ More info ] $36.49 Available to Order: Shipping delay up to 10 days.
#34	10-40003 30	SCREW, (M6 x 25) (6 required per assembly)
		10-40003 30 - Screw - Priced Individually [ More info ] $2.77 10+ In Stock.
#35	12-29245	WASHER, (.281 x .500 x .060) Stainless Steel (6 required per assembly)
		12-29245 - Washer [ More info ] $0.89 10+ In Stock.
		12-8M0204649 - WASHER Note: Priced Individually [ More info ] $1.20 7 In Stock.
#36	43048A 1	SHIFT SHAFT ASSEMBLY, Shift, Long (1 required per assembly)
		43048A 1 - Shift Shaft Only [ More info ] Unavailable
#36	43049A 1	SHIFT SHAFT ASSEMBLY, X-Long (1 required per assembly)
		43049A 1 - Shaft Kit -xl [ More info ] Unavailable
#37	53-29641	E RING (1 required per assembly)
		53-29641 - E Ring - Priced Individually [ More info ] $1.80 8 In Stock.
#38	23-43052A 1	BUSHING ASSEMBLY (1 required per assembly)
		23-43052A 1 - Bushing [ More info ] Unavailable
		23-43052A 4 - Bushing Kit [ More info ] $47.01 2 In Stock.
#39	25-45710	O-RING, (1.424 x .103) (1 required per assembly)
		25-45710 - O-ring, (1.424 X .103), Reverse Lock Valve [ More info ] Unavailable
		25-45710 1 - O-Ring - Priced Individually [ More info ] Unavailable
		25-8M0204681 - O RING Note: Priced Individually [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#40	26-816464 1	SEAL, Oil (1 required per assembly)
		26-816464 1 - Seal [ More info ] Unavailable
		26-8M0204708 - Shift Shaft Oil Seal-O/B [ More info ] $16.99 Available to Order: Shipping delay up to 10 days.
		26-8M0246145 - SHIFT SHAFT OIL SEAL O/B [ More info ] $16.99 10 In Stock.
		18-2054 - Oil Seal Mercury [ More info ] $12.60 8 In Stock.
#41	10-40011128	SCREW, (M6 x 20) Stainless Steel (2 required per assembly)
		10-40011128 - Screw - Priced Individually [ More info ] Unavailable
		108M4503518 - Screw , Priced Individually [ More info ] Unavailable
		108M0204741 - SCREW Note: Priced Individually [ More info ] $4.59 Available to Order: Shipping delay up to 10 days.
