Find 8.7L (533 Cu In) V8 MerCruiser Engines - Gas Parts by Serial Number Range Closed Cooling System Components
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 8M0065441 | COOLANT ASSY (1 required per assembly) |
  |
|
8M0065441 - Coolant Assembly [ More info ]
|
| #1 | 862863 | CAP COOLANT RESERVOIR (1 required per assembly) |
  |
|
862863 - Reservoir Cap [ More info ]
|
| #2 | 8M0066002 | RESERVOIR TOP COOLANT TANK (1 required per assembly) |
  |
|
8M0066002 - RESERVOIR TOP Coo [ More info ] Unavailable |
| #3 | 8M0064710 | RESERVOIR TUBE ACRYLIC (1 required per assembly) |
  |
|
258M0064710 - Tube -ACRYLIC [ More info ]
|
| #4 | 8M0045371 | O-RING (3.53 X 133.35) (2 required per assembly) |
  |
|
258M0045371 - O-Ring - Viton [ More info ]
|
| #5 | 8M0047275 | DISK COOLANT (1 required per assembly) |
  |
|
8M0047275 - Coolant DISK [ More info ]
|
| #6 | 8M0066000 | RESERVOIR BOTTOM COOLANT TANK (1 required per assembly) |
  |
|
8M0066000 - RESERVOIR BOTTOM [ More info ] Unavailable |
| #7 | 860346 | FITTING ELBOW (90 DEGREE) (.750) (1 required per assembly) |
  |
|
22-860346 - Elbow [ More info ]
|
| #8 | 629101 | FITTING ELBOW - 90 DEGREE (.125-27) (1 required per assembly) |
  |
|
22-62910 1 - Elbow [ More info ]
|
| #9 | 8M0061294 | SCREW RESERVOIR ASSEMBLY (2 required per assembly) |
  |
|
108M0061294 - Screw-Reservoir [ More info ]
|
| #10 | 53155 | SCREW (.250-20 X 2.50) (2 required per assembly) |
  |
|
10-53155 - Screw [ More info ]
|
| #11 | 8M0061290 | SPACER (2 required per assembly) |
  |
|
238M0061290 - Spacer [ More info ]
|
| #12 | 8M0047522 | WASHER PRESSURE SEALING (2 required per assembly) |
  |
|
128M0047522 - Washer [ More info ]
|
| #13 | 8M0006044 | DECAL WARNING - DO NOT OPEN HOT (1 required per assembly) |
  |
|
37-8M0006044 - Decal [ More info ]
|
| #14 | 843133 | DECAL COOLANT LEVEL (1 required per assembly) |
  |
|
37-843133 - Decal [ More info ]
|
| #15 | 815504210 | CLAMP @5 (1 required per assembly) |
  |
|
54-815504210 - Clamp [ More info ]
|
| #16 | 8M0061341 | HOSE MOLDED RESERVOIR TO CIRCULAR PUMP (1 required per assembly) |
  |
|
328M0061341 - Hose [ More info ]
|
| #17 | 180763 | CLAMP (1 required per assembly) |
  |
|
54-18076 3 - Clamp [ More info ]
|
| #18 | 815504406 | CLAMP (2 required per assembly) |
  |
|
54-815504406 - Clamp [ More info ]
|
| #19 | 8M0061341 | HOSE MOLDED HEAT EXCHANGER TO RESERVOIR (1 required per assembly) |
| #20 | 629101 | ELBOW (1 required per assembly) |
| #21 | 8M0064704 | EXCHANGER ASSY - NOTE: For Non Standard Paint Color - See Paint Color Chart For PPG Number (1 required per assembly) |
  |
|
8M0064704 - Exchanger Assembly [ More info ]
|
| #22 | 8M0036987 | GASKET (2 required per assembly) |
  |
|
27-8M0036987 - Heat Exchanger End Gasket [ More info ]
|
| #23 | 8M0039163 | O-RING (3/8 X 1/8) (2 required per assembly) |
  |
|
25-8M0039163 - O-ring, (3/8 X 1/8) [ More info ]
|
| #24 | 8M0036623 | END CAP (4 INCH) (2 required per assembly) |
  |
|
8M0036623 - Cap -end [ More info ]
|
| #25 | 94247 | SCREW (.375-16 X .750) STAINLESS STEEL (2 required per assembly) |
  |
|
10-94247 - Screw - Priced Individually [ More info ]
|
| #26 | 841222 | SCREW (2 required per assembly) |
  |
|
10-841222 - Screw [ More info ]
|
| #27 | 8M0042642 | WASHER @5 (4 required per assembly) — Replaces: 70132 |
  |
|
12-8M0042642 - Washer - Priced Individually [ More info ]
|
| #28 | 842450 | PLATE CLAMP (2 required per assembly) |
  |
842450 - Plate Clamp [ More info ] Unavailable |
|
  |
|
8M0192212 - PLATE CLAMP [ More info ] Unavailable |
| #29 | 20295 | QUAD RING 1.725 X .210 (1.725 X .210) (2 required per assembly) |
  |
|
25-20295 - Quad Ring [ More info ]
|
| #30 | 842448 | PLATE (1 required per assembly) |
  |
842448 - Plate [ More info ] Unavailable |
|
  |
|
8M0192211 - PLATE [ More info ] Unavailable |
| #31 | 8071341 | SEAL THERMOSTAT (1 required per assembly) |
  |
|
25-807134 1 - Thermostat Seal [ More info ]
|
| #32 | 8M0076464 | THERMOSTAT-160DEG (1 required per assembly) — Replaces: 863358T |
  |
|
8M0076464 - Thermostat, 160 Degrees [ More info ]
|
  |
|
18-43017 - Thermostat, 160 Degrees, S985009, 863358, 863358T [ More info ]
|
| #33 | 30529 | O RING @5 (2 required per assembly) |
  |
|
25-30529 - O-ring, (1.925 X .103) [ More info ]
|
| #34 | 45176 | WASHER @5 (6 required per assembly) |
  |
|
12-45176 - Washer, (.453 X .812 X .105) [ More info ]
|
| #35 | 825427 | SCREW (4 required per assembly) |
  |
|
10-825427 - Screw [ More info ]
|
| #36 | 841118 | SCREW (1 required per assembly) |
  |
|
10-841118 - Screw [ More info ]
|
| #37 | 841058T01 | CROSSOVER (1 required per assembly) |
  |
|
841058T01 - Crossover [ More info ]
|
| #38 | 841114 | SCREW (1 required per assembly) |
  |
|
10-841114 - Screw [ More info ]
|
| #39 | 8M0204657 | PLUG (2 required per assembly) — Replaces: 36373 |
  |
|
228M0204657 - PLUG [ More info ]
|
| #40 | 843155001 | FOAM STRIP (6.500 INCHES) (2 required per assembly) |
  |
843155001 - Foam STRIP-6.5 In [ More info ] Unavailable |
|
  |
|
8M0192214 - FOAM STRIP-6.5 IN [ More info ] Unavailable |
| #41 | 8M0148668 | SENSOR ASSEMBLY WATER TEMPERATURE (1 required per assembly) — Replaces: 885342002 |
  |
|
8M0148668 - Temperature Sensor [ More info ]
|
| #42 | 896699 | O-RING (1.78 MM X .08 MM) (1 required per assembly) |
  |
|
25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ]
|
| #43 | 841221 | SCREW (2 required per assembly) |
  |
|
10-841221 - Screw [ More info ]
|
