Find 7.9L (482 Cu In) V8 GM MerCruiser Engines - Gas Parts by Serial Number Range Transmission Assembly (S/N 5670317 & Up
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 47754A9 | TRANSMISSION (47754A3-M/C III ONLY) (1 required per assembly) |
  |
|
47754A 9 - Transmission, NLA [ More info ] Unavailable |
| #2 | 47629 | ELBOW 90 DEGREE TRANSMISSION TO OIL HOSE (1 required per assembly) |
  |
|
22-47629 - Elbow [ More info ]
|
| #4 | 88517 | FITTING REDUCING (1 required per assembly) |
  |
|
22-88517 - Fitting [ More info ]
|
| #5 | 47631 | ELBOW TRANSMISSION TO OIL HOSE (1 required per assembly) |
  |
|
22-47631 - Elbow, NLA [ More info ] Unavailable |
| #6 | 57758A2 | COUPLING ASSEMBLY (47339A4-M/C III ONLY ) (1 required per assembly) |
  |
|
57758A 2 - COUPLING ASSY,NLA [ More info ] Unavailable |
| #7 | 47463 | EXPANSION PLUG EXPANSION-ENGINE COUPLING (1 required per assembly) |
  |
|
|
| #8 | 47470 | BEARING BALL ENGINE COUPLING (1 required per assembly) |
  |
|
30-47470 - Ball Bearing [ More info ]
|
| #9 | 47469 | RING SNAP-BALL BEARING TO ENGINE COUPLING (1 required per assembly) |
  |
|
53-47469 - Ring -snap [ More info ] Unavailable |
| #10 | 98322A2 | TAILSTOCK ASSEMBLY (4733A1-M/C III ONLY) (1 required per assembly) |
  |
|
98322A 2 - Tailstock Assembly, NLA [ More info ] Unavailable |
| #11 | 35852 | MOUNT RUBBER-TAILSTOCK (2 required per assembly) |
  |
|
|
| #12 | 47465 | SEAL OIL TAILSTOCK (1 required per assembly) |
  |
|
|
| #13 | 57762T | BEARING -BALL TAILSTOCK (3-5/32" O.D.) (1 required per assembly) — Replaces: 57762 |
  |
|
30-57762T - Ball Bearing [ More info ]
|
| #14 | 32537T | BEARING-BALL TAILSTOCK (2-27/32" O.D.) (1 required per assembly) — Replaces: 32537 |
  |
|
30-32537T - Ball Bearing [ More info ]
|
| #15 | 54481 | RING SNAP-BALL BEARING TO TAILSTOCK (1 required per assembly) |
  |
|
53-54481 - Snap Ring, NLA [ More info ]
|
| #16 | 54067 | SEAL TAILSTOCK (1 required per assembly) |
  |
|
25-54067 - O-Ring, Transom To Gimbal Housing [ More info ]
|
| #17 | 47903 | GASKET TAILSTOCK (1 required per assembly) |
  |
|
27-47903 - Tailstock Gasket [ More info ]
|
| #18 | 29081 | SCREW (.437-14 X 1.250) TAILSTOCK TO TRANSMISSION (6 required per assembly) |
  |
|
10-29081 - Screw [ More info ]
|
| #19 | 99524 | SCREW (.437-14 X 2.00) TAILSTOCK TO TRANSMISSION (2 required per assembly) |
  |
|
10-99524 - SCREW,NLA [ More info ] Unavailable |
| #20 | 30381 | LOCKWASHER HI COLLAR (.437) TAILSTOCK SCREW (6 required per assembly) |
  |
|
13-30381 - LockWasher, NLA [ More info ]
|
| #21 | 32993 | LOCKWASHER (.437) TAILSTOCK SCREW (2 required per assembly) |
  |
|
13-32993 - LockWasher - Priced Individually [ More info ]
|
| #22 | 99801 | STUD CLUMP BLOCK (1 required per assembly) |
  |
|
16-99801 - STUD,NLA [ More info ] Unavailable |
| #23 | 41058 | CLAMP BLOCK SHIFT CABLE (2 required per assembly) |
  |
|
41058 - Shift Cable Block Clamp, NLA [ More info ]
|
| #24 | 69056 | WASHER (.255 X .620 X .030) STAINLESS STEEL CLAMP BLOCK STUD (2 required per assembly) |
  |
|
12-69056 - Washer, (.255 X .620 X .030) Stainless Steel [ More info ]
|
| #25 | 35888 | NUT (.250-28) STAINLESS STEEL CLAMP BLOCK STUD (1 required per assembly) |
  |
|
11-35888 - Nut (1/4-28) [ More info ]
|
  |
|
18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ]
|
| #26 | 4751612 | HOSE TRANSMISSION TO OIL COOLER (16-3/4") (1 required per assembly) — Replaces: 475162 |
  |
|
32-47516 12 - Hose Assembly-20 IN, NLA [ More info ] Unavailable |
| #27 | 475163 | HOSE TRANSMISSION TO OIL COOLER (7-7/8") (1 required per assembly) |
  |
|
32-47516 3 - Hose Assembly -7.88 In, NLA [ More info ]
|
| #28 | 47467 | SCREW (.625-18 X 5.500) TAILSTOCK TO INNER TRANSOM PLATE (2 required per assembly) |
  |
|
10-47467 - Screw [ More info ]
|
| #29 | 47475 | WASHER (2 required per assembly) |
  |
|
12-47475 - Washer, (1.120 X 2.250 X .19) [ More info ]
|
| #30 | 47466 | WASHER (4 required per assembly) |
  |
|
12-47466 - Washer, (1.125 X 1.750 X .16) [ More info ]
|
| #31 | 34846 | LOCKWASHER @2 (2 required per assembly) |
  |
|
13-34846 - LockWasher - Priced Individually [ More info ]
|
| #32 | 33171 | WASHER (2 required per assembly) |
  |
|
12-33171 - Washer, (.6406 X 1.750 X .125) [ More info ]
|
| #33 | 22339 | NUT @5 (2 required per assembly) |
  |
11-22339 - Nut (5/8x18) [ More info ] Unavailable |
|
  |
|
18-3713 - Nut, 11-22339 [ More info ]
|
  |
|
11-8M0214915 - NUT Note: Priced Individually [ More info ]
|
  |
|
11-01817 - Nut 11-22339 [ More info ]
|
