Find 7.9L (482 Cu In) V8 GM MerCruiser Engines - Gas Parts by Serial Number Range Distributor & Ignition Components (Mallory)

Revise Search: Sterndrive > MerCruiser Engines - Gas > 7.9L (482 Cu In) V8 GM > 1983-1986 4179554 - 6181046 > Distributor & Ignition Components (Mallory)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Distributor & Ignition Components (Mallory)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	47410A1	GASKET SET (370/400) (1 required per assembly)
		27-47410A 1 - Engine Gasket Set [ More info ] Unavailable
#-	99386A2	GASKET SET (440/460) (1 required per assembly)
		27-99386A 2 - Gasket Set, NLA [ More info ] Unavailable
#1	91823A6	DISTRIBUTOR (370/400) (1 required per assembly)
		91823A 6 - Distributor, NLA [ More info ] Unavailable
#1	91823A7	DISTRIBUTOR (440) (1 required per assembly)
		91823A 7 - Distributor, NLA [ More info ] Unavailable
#1	98106A2	DISTRIBUTOR (460) (1 required per assembly)
		98106A 2 - Distributor, NLA [ More info ] Unavailable
#2	5075Q1	CAP-DISTRIBUTOR DISTRIBUTOR (1 required per assembly) — Replaces: 5075, 5075T
		391-5075Q 1 - Distributor Cap [ More info ] In Stock
		18-5376 - Distributor Cap, 982209, 391-5075 [ More info ] $39.32 4 In Stock.
#3	5076	GASKET DISTRIBUTOR CAP (1 required per assembly)
		391-5076 - Distributor Cap Gasket [ More info ] $7.09 $5.68 10+ In Stock.
#4	898253029	ROTOR (1 required per assembly) — Replaces: 7057, 7057T
		391-898253029 - 8M6001224 [ More info ] Unavailable
		8M6001224 - Rotor [ More info ] $18.29 $17.52 1 In Stock.
		18-5404-1 - Rotor, Mallory Tall Cap [ More info ] $10.65 4 In Stock.
#5	8M6001217	CONDENSER (1 required per assembly) — Replaces: 5092, 898253001
		8M6001217 - Condenser [ More info ] $13.49 Available to Order: Shipping delay up to 10 days.
		18-5338 - Condenser 391-5092 [ More info ] $9.44 1 In Stock.
#6	898253001	CONDENSER CONDENSER ATTACHING (1 required per assembly) — Replaces: 5093, 5092
		391-898253001 - Condenser - 8M6001217 [ More info ] Unavailable
#7	5091	SCREW CONDENSER BRACKET ATTACHING (1 required per assembly)
		391-5091 - Screw, NLA [ More info ] $1.72 10+ In Stock.
#8	8M6001250	BREAKER POINTS (1 required per assembly) — Replaces: 5090, 898253004
		8M6001250 - Breaker Point [ More info ] $17.69 Available to Order: Shipping delay up to 10 days.
		18-5314 - Point Set, 382135, 391-5090 [ More info ] $15.99 In Stock
#9	5089	SCREW BREAKER ATTACHING (1 required per assembly)
		391-5089 - Screw, NLA [ More info ] $1.96 10+ In Stock.
#10	65773A6	LEAD ASSEMBLY PRIMARY TERMINAL (1 required per assembly)
		84-65773A 6 - Wire Assembly, NLA [ More info ] $7.78 $6.59 10+ In Stock.
#11	5085	CLAMP DISTRIBUTOR CAP ATTACHING (2 required per assembly)
		391-5085 - Distributor Cap Attaching Clamp [ More info ] $19.76 6 In Stock.
#12	5084	PIN CLAMP TO DISTRIBUTOR (2 required per assembly)
		391-5084 - Pin, Clamp To Distributor, NLA [ More info ] $3.87 3 In Stock.
#13	5087	SCREW DISTRIBUTOR CAP ATTACHING (2 required per assembly)
		391-5087 - Screw, NLA [ More info ] $3.87 10+ In Stock.
#14	5086	WASHER DISTRIBUTOR CAP SCREW (2 required per assembly)
		391-5086 - Washer, Distributor Cap Screw, NLA [ More info ] $5.34 10+ In Stock.
#15	5083	VENT SCREEN (2 required per assembly)
		391-5083 - Vent Screen, NLA [ More info ] $2.00 $1.69 1 In Stock.
#16	5080	OILER (1 required per assembly)
		391-5080 - Oiler, NLA [ More info ] $6.00 $5.08 1 In Stock.
#17	6390	GEAR DRIVE (1 required per assembly)
		391-6390 - Gear [ More info ] Unavailable
#18	6391	PIN DRIVE GEAR (1 required per assembly)
		391-6391 - Pin, Drive Gear, NLA [ More info ] $1.50 $1.28 4 In Stock.
#19	344863	GASKET DISTRIBUTOR (1 required per assembly) — Replaces: 52184, 344861
		0344863 - Cylinder Hd175Ffi 20 Inch (344863) [ More info ] $351.48 Available to Order: Shipping delay up to 10 days.
#20	88731	CLAMP DISTRIBUTOR TO INTAKE MANIFOLD (1 required per assembly) — Replaces: 52185
		54-88731 - Clamp [ More info ] $9.99 Available to Order: Shipping delay up to 10 days.
#21	98261	SCREW (.375-16 X .750) DISTRIBUTOR CLAMP ATTACHING (1 required per assembly) — Replaces: 27165
		10-98261 - Screw [ More info ] $1.20 5 In Stock.
#22	815297A47	CABLE ASSY DISTRIBUTOR TO COIL (1 required per assembly) — Replaces: 42841A47, 813705A47
		84-815297A47 - Cable Assembly, NLA [ More info ] $6.00 $5.08 2 In Stock.
#23	898253T24	COIL IGNITION (1 required per assembly) — Replaces: 32193A2, 806529A1
		898253T24 - Coil [ More info ] $75.99 In Stock
		18-5433 - Coil, 392-806529A1 [ More info ] $59.24 1 In Stock.
		300-02805 - Coil 392-806529A 1, 3853548 [ More info ] $46.99 $40.53 In Stock
#24	77294T	BRACKET IGNITION COIL MOUNTING (1 required per assembly) — Replaces: 77294
		77294T - Bracket, NLA [ More info ] Unavailable
#25	41408	SCREW (#10-32 X 1.50) BRACKET TO IGNITION COIL (1 required per assembly)
		10-41408 - Screw [ More info ] $3.39 $2.72 1 In Stock.
#26	30164	WASHER (.192 X .375 X .0312) STAINLESS STEEL IGNITION COIL TERMINAL (2 required per assembly)
		12-30164 - Washer, (.192 X .375 X .0312) [ More info ] $2.49 10+ In Stock.
#27	26996	LOCKWASHER (#10) STAINLESS STEEL IGNITION COIL TERMINAL (2 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 Available to Order: Shipping delay up to 10 days.
#28	45076	NUT (#10-32) BRASS IGNITION COIL TERMINAL (2 required per assembly)
		11-45076 - Nut (#10-32) (brass) [ More info ] $1.80 10+ In Stock.
#29	25299	SCREW (.312-18 X .75) IGNITION COIL ATTACHING (2 required per assembly)
		10-25299 - Screw - Priced Individually [ More info ] $0.46 10+ In Stock.
#30	20084	WASHER (.328 X .562 X .062) IGNITION COIL ATTACHING SCREW (2 required per assembly)
		12-20084 - Washer, (.328 X .562 X .062) [ More info ] $3.05 10+ In Stock.
#31	8M0204647	LOCKWASHER @5 IGNITION COIL ATTACHING SCREW (2 required per assembly) — Replaces: 26993
		138M0204647 - LOCKWASHER, Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#32	816761A9	WIRE KIT-IGNITION HIGH TENSION (1 required per assembly) — Replaces: 43376A9, 813720A9
		84-816761A 9 - Ignition Wire Kit [ More info ] Unavailable
		84-816761Q 9 - Ignition Wire Kit [ More info ] $123.73 1 In Stock.
		18-8803-2 - Plug Wire Set [ More info ] $72.99 $70.62 4 In Stock.
		84-28000 - Ignition Wire Set, 84-816761Q9 [ More info ] $75.99 $58.11 2 In Stock.
#33	898264001	SPARK PLUG (AC-MR43T) (AC-MR43T) (370/400) (8 required per assembly) — Replaces: 59571, 898264
		33-898264001 - AC Spark Plug - BR6FS - Priced Individually [ More info ] Unavailable
		BR6FS - NGK Spark Plug, 4323 [ More info ] $5.56 10+ In Stock.
		RV9YC - Champion Spark Plug ( #400) [ More info ] $4.99 $4.35 10+ In Stock.
		33-8M0204752 - AC SPRK PLUG @8 [ More info ] Unavailable
#33	8134214	SPARK PLUG (AC-MR41T) (440/460) (8 required per assembly) — Replaces: 59660, 813421
		33-813421 4 - NGK Spark Plug R5673-8 - Priced Individually [ More info ] $6.09 Available to Order: Shipping delay up to 10 days.
#34	54676	RETAINER TWO WIRE HIGH TENSION LEADS (2 required per assembly)
		54676 - Retainer [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#34	32783	RETAINER THREE WIRE HIGH TENSION LEADS (2 required per assembly)
		32783 - Retainer [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#34	32784	RETAINER FOUR WIRE HIGH TENSION LEADS (2 required per assembly)
		32784 - Retainer [ More info ] Unavailable
#35	38930	GROMMET RETAINER BRACKET (2 required per assembly)
		25-38930 - Grommet, High Tension Lead,NLA [ More info ] $4.35 $3.68 10 In Stock.
#36	47763	BRACKET RETAINER - HIGH TENSION LEADS (2 required per assembly)
		47763 - Bracket, NLA [ More info ] $1.50 $1.28 5 In Stock.
#37	20553	WASHER (.406 X .734 X .063) RETAINER BRACKET SCREW (2 required per assembly)
		12-20553 - Washer - Priced Individually [ More info ] $1.50 8 In Stock.
#38	35048	LOCKWASHER (.375) RETAINER BRACKET SCREW (2 required per assembly)
		13-35048 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#39	98261	SCREW (.375-16 X .750) RETAINER BRACKET (2 required per assembly) — Replaces: 27165
#40	35048	LOCKWASHER (.375) DISTRIBUTOR SCREW (1 required per assembly)
#41	20553	WASHER (.406 X .734 X .063) DISTRIBUTOR SCREW (1 required per assembly)
#42	56334	GROMMET (460) (1 required per assembly)
		25-56334 - Grommet, NLA [ More info ] Unavailable
