Parts for SSM VII MerCruiser Outdrive Units Gimbal Housing Assy Driveline, (Wet & Dry Sump)

Revise Search: Sterndrive > MerCruiser Outdrive Units > SSM VII > All & Up - USA > Gimbal Housing Assy Driveline, (Wet & Dry Sump)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gimbal Housing Assy Driveline, (Wet & Dry Sump)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0050392	PLATE ASSY-OUTER (1 required per assembly) — Replaces: 846604A1
		8M0050392 - Outer Plate Assembly [ More info ] Unavailable
#2	847091	FITTING (1 required per assembly)
		22-847091 - Fitting [ More info ] Unavailable
#3	47841	FITTING (.375-18 X .500 ) STRAIGHT - NOTE: Qty 2 - Version I And Qty 1 - Version II (1/2 required per assembly)
		22-47841 - Connector [ More info ] Unavailable
		22-8M0214935 - CONNECTOR [ More info ] Unavailable
#3	38565	FITTING (.375-18) ELBOW - 45 DEGREE - NOTE: Version II (1 required per assembly)
		22-38565 - Fitting [ More info ] $51.99 Available to Order: Shipping delay up to 10 days.
#4	8M0034453	STUD (7/16 X 2.19) (4 required per assembly) — Replaces: 57933
		16-8M0034453 - Stud [ More info ] $19.59 Available to Order: Shipping delay up to 10 days.
#5	846384	STUD (.625-11/.625-18 X 5.750) (8 required per assembly)
		16-846384 - Stud [ More info ] $56.35 Available to Order: Shipping delay up to 10 days.
#6	846386	STUD (.250-28 X 1.120) (4 required per assembly)
		16-846386 - Stud [ More info ] $29.62 Available to Order: Shipping delay up to 10 days.
#7	846388	STUD (.250-28 X 1.750) (4 required per assembly)
		16-846388 - Stud [ More info ] $27.87 Available to Order: Shipping delay up to 10 days.
#8	847333	EMBLEM MERCRUISER Early Models (1 required per assembly)
		847333 - Emblem [ More info ] $47.87 Available to Order: Shipping delay up to 10 days.
#8	840359	DECAL MERCURY RACING [0M965835] & Below (1 required per assembly)
		37-840359 - Decal [ More info ] $26.91 Available to Order: Shipping delay up to 10 days.
#8	8M0048257	DECAL MERCURY RACING [0M965836] & Up (1 required per assembly)
		378M0048257 - Decal [ More info ] $62.08 Available to Order: Shipping delay up to 10 days.
#9	847213	O-RING SPECIAL (1 required per assembly)
		25-847213 - O-Ring [ More info ] $56.76 Available to Order: Shipping delay up to 10 days.
#10	846497	SEAL (1 required per assembly)
		26-846497 - Seal [ More info ] $89.80 Available to Order: Shipping delay up to 10 days.
#11	840164A1	SHIELD KIT TRANSOM SPLASH (1 required per assembly)
		840164A 1 - Shield Kit [ More info ] Unavailable
#12	861492	PLUG NON DIGITAL TRIM SENDER MODELS (1 required per assembly)
		19-861492 - Plug [ More info ] $8.99 Available to Order: Shipping delay up to 10 days.
#13	846430A1	SHIM SET (1 required per assembly)
		15-846430A 1 - Shim Set [ More info ] $27.37 Available to Order: Shipping delay up to 10 days.
#14	846477A1	BEARING SET (1 required per assembly)
		31-846477A 1 - Bearing Set - Cup And Cone [ More info ] $65.18 Available to Order: Shipping delay up to 10 days.
#15	8M0050789	SPACER (1 required per assembly) — Replaces: 847321
		8M0050789 - Spacer [ More info ] $178.96 Available to Order: Shipping delay up to 10 days.
#16	847395T1	BEARING SET (1 required per assembly)
		31-847395T 1 - Bearing Set - Cup And Cone [ More info ] $128.86 Available to Order: Shipping delay up to 10 days.
#17	846366	O RING (1 required per assembly)
		25-846366 - O-ring, (4.860 X .120) [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
#18	847322A1	COVER ASSY (1 required per assembly)
		847322A 1 - Cover Assembly [ More info ] $873.50 Available to Order: Shipping delay up to 10 days.
#19	846496	SEAL (1 required per assembly)
		26-846496 - Seal [ More info ] $101.29 Available to Order: Shipping delay up to 10 days.
#20	842922	WASHER (4 required per assembly)
		12-842922 - Washer, (.450 X .750 X .060) Stainless Steel [ More info ] $1.00 1 In Stock.
#21	8M0204653	NUT @10 (4 required per assembly) — Replaces: 34933
		11-8M0204653 - Prop Lock Nut 7/16-20 , Priced Individually [ More info ] $5.29 9 In Stock.
		11-00118 - Nut, Sold Individually [ More info ] $3.59 $2.95 7 In Stock.
#22	847323	RING-RETAINING (1 required per assembly)
		53-847323 - Ring - Retaining [ More info ] $46.18 Available to Order: Shipping delay up to 10 days.
#23	8M0050761	SHAFT-INPUT INPUT - New Style (1 required per assembly) — Replaces: 847320
		8M0050761 - Shaft-INPUT [ More info ] $2,307.23 Available to Order: Shipping delay up to 10 days.
#24	47379	NUT (8 required per assembly)
		11-47379 - Nut, (.625-18) Stainless Steel [ More info ] $22.40 $6.27 10+ In Stock.
#25	844850	WASHER (8 required per assembly)
		12-844850 - Washer, (.660 X 1.310 X .09) Stainless Steel [ More info ] $1.24 Available to Order: Shipping delay up to 10 days.
#26	844322	PIN CYLINDER PIVOT PIVOT (2 required per assembly) — Replaces: 848726
		844322 - Cylinder Pivot Pin [ More info ] $141.24 Available to Order: Shipping delay up to 10 days.
#27	35888	NUT @5 (8 required per assembly)
		11-35888 - Nut (1/4-28) [ More info ] $6.89 $3.04 10+ In Stock.
		18-3722-9 - Lock Nut, 121731, 11-35888, Pack of 5 [ More info ] $11.99 $8.16 Available to Order: Shipping delay up to 10 days.
#28	846643	PLUG FLUSH (2 required per assembly)
		19-846643 - Plug [ More info ] $0.48 Available to Order: Shipping delay up to 10 days.
#29	843203A04	HARNESS ASSY - Driveline Models (1 required per assembly) — Replaces: 843203A03
		84-843203A04 - Harness Assembly [ More info ] $71.17 Available to Order: Shipping delay up to 10 days.
#30	8M0050240	CYL ASSY-STEERING STEERING - NOTE: Starboard - See Steering Cylinder Assembly Section For Parts Breakdown (1 required per assembly) — Replaces: 846472A3
		8M0050240 - Steering Cylinder Assembly [ More info ] Unavailable
#30	8M0050242	CYL ASSY-STEERING STEERING - NOTE: Port - See Steering Cylinder Assembly For Parts Breakdown (1 required per assembly) — Replaces: 846473A3
		8M0050242 - Steering Cylinder Assembly [ More info ] Unavailable
#31	28635	SCREW @5 - NOTE: With Trim Sender (1 required per assembly)
		10-28635 - Screw - Priced Individually [ More info ] $1.80 10+ In Stock.
#32	35950	WASHER @2 - NOTE: With Trim Sender (1 required per assembly)
		12-35950 - Washer, (.273 X .437 X .031) Stainless Steel [ More info ] $1.80 5 In Stock.
#33	12078	CLAMP - NOTE: With Trim Sender (1 required per assembly)
		54-12078 - Clamp [ More info ] $13.59 Available to Order: Shipping delay up to 10 days.
#34	180761	CLAMP (2 required per assembly)
		54-18076 1 - Clamp [ More info ] $9.77 8 In Stock.
#35	846616	HOSE-23 INCH (1 required per assembly)
		32-846616 - Hose -23 Inch [ More info ] Unavailable
		32-8M0192229 - HOSE-23 INCH [ More info ] Unavailable
#36	846865	FITTING (2 required per assembly)
		22-846865 - Fitting [ More info ] $39.12 Available to Order: Shipping delay up to 10 days.
#37	846471A1	BLOCK ASSEMBLY HYDRAULIC CONNECTOR (1 required per assembly)
		846471A 1 - Block Assembly - Hydraulic [ More info ] $807.63 Available to Order: Shipping delay up to 10 days.
#38	86391	O-RING (1 required per assembly)
		25-86391 - O-ring,Transfer Port Cover [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#39	846345	STUD (#10-32 X .750) (1 required per assembly)
		16-846345 - Stud [ More info ] $21.79 Available to Order: Shipping delay up to 10 days.
#40	846673	WASHER (2 required per assembly)
		12-846673 - Washer, (.265 X .500 X .060) Stainless Steel [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#41	847022	PLATE BONDING (1 required per assembly)
		847022 - Plate -bonding [ More info ] $7.46 Available to Order: Shipping delay up to 10 days.
#42	847062A1	CABLE BONDING KIT (1 required per assembly)
		847062A 1 - Cable Bonding Kit [ More info ] $60.99 Available to Order: Shipping delay up to 10 days.
#43	8267096	NUT (1 required per assembly) — Replaces: 34059
		11-826709 6 - Nut [ More info ] $3.69 1 In Stock.
