Parts for SSM Vi MerCruiser Outdrive Units Inner Transom Plate Wet-Sump SSM VI & VII (Pre-1998)

Revise Search: Sterndrive > MerCruiser Outdrive Units > SSM Vi > All & Up - USA > Inner Transom Plate Wet-Sump SSM VI & VII (Pre-1998)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Inner Transom Plate Wet-Sump SSM VI & VII (Pre-1998)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	849353	CAP HOSE FITTING (2 required per assembly)
		849353 - Cap - Oil Level [ More info ] Unavailable
#-	849352	FITTING HOSE - BRASS (2 required per assembly)
		22-849352 - Fitting [ More info ] Unavailable
#-	849354	TUBE (.190 X .250 X 5.750) PLASTIC (1 required per assembly)
		70-849354 - TUBE-OIL LEVEL,NLA [ More info ] Unavailable
#1	849182A1	PLATE ASSEMBLY INNER TRANSOM - Design I (1 required per assembly) — Replaces: 846611A1
		849182A 1 - PLATE ASY-TRANSO,NLA [ More info ] Unavailable
#2	847333	EMBLEM MERCRUISER (1 required per assembly)
		847333 - Emblem [ More info ] $47.87 Available to Order: Shipping delay up to 10 days.
#3	47902	FITTING (.125-27) BREATHER (1 required per assembly)
		22-47902 - Fitting [ More info ] $18.29 1 In Stock.
#4	320181	PLUG (1.00-12) OIL FILL (1.00-12) OIL FILL (1 required per assembly) — Replaces: 32018
		22-32018 1 - Plug [ More info ] $68.05 10+ In Stock.
		22-8M0192193 - PLUG [ More info ] Unavailable
#5	35126	O-RING (.859 X .139) (1 required per assembly)
		25-35126 - O-ring, (.859 X .139) [ More info ] $2.99 10+ In Stock.
#6	846590A1	GAUGE ASSEMBLY VIEW (1 required per assembly)
		846590A 1 - GAUGE ASSY-VIEW,NLA [ More info ] Unavailable
#7	8M0092943	O-RING ORANGE (1 required per assembly) — Replaces: 846594
		258M0092943 - O-Ring [ More info ] $3.59 1 In Stock.
#8	846329	PLUG (1.50) EXPANSION - BRASS (3 required per assembly)
		19-846329 - PLUG-EXPANSION [ More info ] Unavailable
#9	848655	FITTING (.375-18) 90 DEGREE (1 required per assembly)
		22-848655 - Fitting [ More info ] Unavailable
#10	847189	HOSE-4.750 INCH (1 required per assembly)
		32-847189 - Hose -4.750 Inch [ More info ] $17.17 Available to Order: Shipping delay up to 10 days.
#11	180761	CLAMP (2 required per assembly)
		54-18076 1 - Clamp [ More info ] $9.77 8 In Stock.
#12	849182A1	PLATE ASSEMBLY INNER TRANSOM - Design II (1 required per assembly)
#13	840359	DECAL MERCURY RACING [0M965835] & Below (1 required per assembly)
		37-840359 - Decal [ More info ] $26.91 Available to Order: Shipping delay up to 10 days.
#13	8M0048257	DECAL MERCURY RACING [8M965836] & Up (1 required per assembly)
		378M0048257 - Decal [ More info ] $62.08 Available to Order: Shipping delay up to 10 days.
#14	47902	FITTING (.125-27) BREATHER (1 required per assembly)
#15	848655	FITTING (.375-18) 90 DEGREE (1 required per assembly)
#16	8115691	CAP OIL FILL (1 required per assembly)
		36-811569 1 - Oil Fill Cap [ More info ] $48.90 Available to Order: Shipping delay up to 10 days.
#17	840165	DECAL OIL FILLING INSTRUCTIONS (1 required per assembly)
		37-840165 - DECAL,NLA [ More info ] Unavailable
#18	849347	DECAL DRIVE OIL LEVEL (1 required per assembly)
		37-849347 - DECAL,NLA [ More info ] Unavailable
#19	847189	HOSE-4.750 INCH (1 required per assembly)
#20	180761	CLAMP (2 required per assembly)
