Parts for SSM II / III / IV / V MerCruiser Outdrive Units Driveshaft Housing Assembly (Alpha One-Ss)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 32511A1 | SEAL KIT (1 required per assembly) |
  |
|
26-32511A 1 - Seal Kit [ More info ]
|
  |
|
18-2648 - Seal Kit, 26-32511A1 [ More info ]
|
  |
|
26-03809 - Seal Kit 26-32511A 1 [ More info ]
|
| #1 | 9552A5 | D SHAFT HSG ASSY (1 required per assembly) |
  |
|
3500-9552A 5 - D SHAFT HSG ASSY,NLA [ More info ] Unavailable |
| #2 | 42724A4 | COVER ASSY (1 required per assembly) |
  |
|
42724A 4 - Cover, NLA [ More info ] Unavailable |
| #3 | 36557 | SEAL WATER INLET TUBE (1 required per assembly) |
  |
|
26-36557 - Seal - Priced Individually [ More info ]
|
  |
|
18-0521 - Gasket, 26-36557 [ More info ]
|
| #4 | 558101 | GASKET (2 required per assembly) — Replaces: 55810 |
  |
|
27-55810 1 - Gasket [ More info ]
|
| #5 | 759146 | TUBE WATER (1 required per assembly) |
  |
|
32-75914 6 - Water Tube [ More info ] Unavailable |
| #6 | 28668 | SCREW @5 (4 required per assembly) |
  |
|
10-28668 - Screw - Priced Individually [ More info ]
|
| #7 | 12774 | PLATE WATER RESTRICTOR (1 required per assembly) |
  |
|
12774 - Plate [ More info ] Unavailable |
| #8 | 13682A90 | DECAL SET (1 required per assembly) |
  |
|
37-13682A90 - Decal Set [ More info ]
|
| #9 | 13722A10 | DECAL SET (454 MAGNUM) (ALPHA ONE) (1 required per assembly) |
  |
|
37-13722A10 - Decal Set [ More info ] Unavailable |
| #9 | 16416A87 | DECAL SET (320) (ALPHA ONE) (1 required per assembly) |
  |
|
37-16416A87 - Decal Set,NLA [ More info ] Unavailable |
| #10 | 965031 | SEAL @3 (1 required per assembly) — Replaces: 96503 |
  |
|
26-96503 1 - Seal - Priced Individually [ More info ]
|
  |
|
18-2056 - Seal, 26-96503 1 [ More info ]
|
  |
|
26-00167 - Seal, 26-96503 1 [ More info ]
|
| #11 | 32511 | SEAL @3 (1 required per assembly) |
  |
|
26-32511 - Seal - Priced Individually [ More info ]
|
  |
|
18-2049 - Seal, 26-32511 [ More info ]
|
| #12 | 36178A02 | SHIM SET (AR required per assembly) — Replaces: 36178A1 |
  |
|
15-36178A02 - Shim Set [ More info ]
|
| #13 | 55796 | DRIVESHAFT (1 required per assembly) |
  |
|
45-55796 - Drive Shaft [ More info ]
|
| #14 | 55801 | O RING @3 (1 required per assembly) |
  |
|
25-55801 - O-ring, Upper Drive Shaft [ More info ]
|
| #15 | 94998A4 | COVER ASSEMBLY TOP (1 required per assembly) — Replaces: 94998A2 |
  |
|
94998A 4 - Cover Assembly [ More info ]
|
| #16 | 61100A1 | BEARING ASSEMBLY ROLLER (1 required per assembly) |
  |
|
31-61100A 1 - Bearing - Driveshaft [ More info ]
|
  |
|
18-1165 - Bearing, 31-61100A1 [ More info ]
|
| #17 | 45691A1 | SHIM (AR required per assembly) |
  |
|
15-45691A 1 - Shim Set [ More info ]
|
| #18 | 32546 | O RING @5 (1 required per assembly) |
  |
|
25-32546 - O-Ring - Priced Individually [ More info ]
|
  |
|
18-7161-9 - (PK5) O-Ring 25-32546 [ More info ]
|
| #19 | 8M0113180 | SCREW @2 (4 required per assembly) — Replaces: 98794 |
  |
|
10-8M0113180 - Mouting Screw AL/BRAV TOP Cover, priced individually [ More info ]
|
| #20 | 14860 | WEAR PAD (PORT) (1 required per assembly) |
  |
|
14860 - WEAR PAD-PORT,NLA [ More info ] Unavailable |
| #20 | 14861 | WEAR PAD (STARBOARD) (1 required per assembly) |
  |
|
14861 - WEAR PAD - Starboard,NLA [ More info ] Unavailable |
| #21 | 14862 | SCREW (4 required per assembly) |
  |
|
10-14862 - SCREW,NLA [ More info ] Unavailable |
