Parts for NXT6 SSM MerCruiser Outdrive Units Steering Cylinder Assembly (Wet & Dry Sump)

Revise Search: Sterndrive > MerCruiser Outdrive Units > NXT6 SSM > All & Up - USA > Steering Cylinder Assembly (Wet & Dry Sump)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Steering Cylinder Assembly (Wet & Dry Sump)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0050240	CYL ASSY-STEERING STEERING - Starboard (1 required per assembly) — Replaces: 846472A3
		8M0050240 - Steering Cylinder Assembly [ More info ] Unavailable
#1	8M0050242	CYL ASSY-STEERING STEERING - Port (1 required per assembly) — Replaces: 846473A3
		8M0050242 - Steering Cylinder Assembly [ More info ] Unavailable
#2	846472A4	REBUILD KIT STEERING CYLINDER (1 required per assembly)
		846472A 4 - Rebuild Kit [ More info ] $285.90 Available to Order: Shipping delay up to 10 days.
#3	846371	BEARING (2 required per assembly)
		23-846371 - Bearing [ More info ] $46.57 Available to Order: Shipping delay up to 10 days.
#4	846856	BEARING (1 required per assembly)
		23-846856 - Bearing [ More info ] $96.59 Available to Order: Shipping delay up to 10 days.
#5	33145	O-RING (1.984 X .139) (1 required per assembly)
		25-33145 - O-ring, (1.984 X .139) [ More info ] Unavailable
		18-7162-9 - (PK5) O-Ring 25-33145 [ More info ] $17.00 Available to Order: Shipping delay up to 10 days.
		25-8M0214923 - O RING, sold individually [ More info ] $3.79 Available to Order: Shipping delay up to 10 days.
#6	843311	SCRAPER (1 required per assembly)
		843311 - Scraper [ More info ] $72.34 Available to Order: Shipping delay up to 10 days.
#7	65936	O-RING (1 required per assembly)
		25-65936 - O-ring, Upper Mount [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
		18-7143-9 - O-Ring 25-65936 (5-Pack) [ More info ] $9.24 Available to Order: Shipping delay up to 10 days.
#8	23145	O-RING (.984 X .139) (2 required per assembly)
		25-23145 - O-ring, (.984 X .139) [ More info ] $1.99 1 In Stock.
		18-7114 - O-Ring 25-23145, 302540 [ More info ] $2.02 $1.59 7 In Stock.
#9	846364	O-RING (1.600 X .190) (1 required per assembly)
		25-846364 - O-ring, (1.600 X .190) [ More info ] $0.80 Available to Order: Shipping delay up to 10 days.
#10	846443	PISTON STANDARD (1 required per assembly)
		846443 - Hydraulic Piston [ More info ] $171.91 Available to Order: Shipping delay up to 10 days.
#11	846941	WASHER (.530 X 1.06 X .095) (1 required per assembly)
		12-846941 - Washer, (.530 X 1.06 X .095) [ More info ] $0.83 Available to Order: Shipping delay up to 10 days.
#12	840115	SCREW (.500-20 X 1.00) (1 required per assembly)
		10-840115 - Screw [ More info ] $1.59 Available to Order: Shipping delay up to 10 days.
#13	NSS	NOT SOLD SEPARATE PISTON ROD - NOTE: Order Complete Cylinder Assembly (1 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#14	846939	PLATE RETAINING (1 required per assembly)
		846939 - Plate - Retaining [ More info ] $45.94 Available to Order: Shipping delay up to 10 days.
#15	68513	SCREW (#10-32 X .375) STAINLESS STEEL (4 required per assembly)
		10-68513 - Screw [ More info ] $1.40 10 In Stock.
#16	846442	CAP END (1 required per assembly)
		846442 - Cap - End - Hydraulic [ More info ] Unavailable
#17	846441	BUSHING GUIDE (1 required per assembly)
		846441 - Bushing [ More info ] $133.65 Available to Order: Shipping delay up to 10 days.
