Parts for NXT1 Drive MerCruiser Outdrive Units Steering Cylinder Components

Revise Search: Sterndrive > MerCruiser Outdrive Units > NXT1 Drive > 0M954569 & Up - USA > Steering Cylinder Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Steering Cylinder Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	841983A05	REBUILD KIT (1 required per assembly)
		841983A05 - Rebuild Kit [ More info ] $138.54 Available to Order: Shipping delay up to 10 days.
#1	8M0073272	CYLINDER ASY-STBD [0M969067] & Below (1 required per assembly) — Replaces: 841983A01, 8M0070039
		8M0073272 - Cylinder Assembly - Stbd [ More info ] Unavailable
		8M0192246 - CYLINDER ASY-STBD [ More info ] Unavailable
#1	8M0192246	CYLINDER ASY-STBD [0M969068] & Up (1 required per assembly) — Replaces: 8M0073272
#1	8M0073354	CYLINDER ASY-PORT [0M969067] & Below (1 required per assembly) — Replaces: 841983A02, 8M0070040
		8M0073354 - Cylinder Assembly - Port [ More info ] Unavailable
		8M0192248 - CYLINDER ASY-PORT [ More info ] $2,430.00 Available to Order: Shipping delay up to 10 days.
#1	8M0192248	CYLINDER ASY-PORT [0M969068] & Up (1 required per assembly) — Replaces: 8M0073354
#2	846371	BEARING (2 required per assembly)
		23-846371 - Bearing [ More info ] $46.57 Available to Order: Shipping delay up to 10 days.
#3	88238A13	CABLE ASSEMBLY GROUND (2 required per assembly)
		88238A13 - Cable Assembly, Priced Individually [ More info ] $13.60 3 In Stock.
		8M0207768 - CABLE ASSY @5 [ More info ] Unavailable
#4	68513	SCREW (#10-32 X .375) STAINLESS STEEL (1 required per assembly)
		10-68513 - Screw [ More info ] $1.40 10 In Stock.
#5	840115	SCREW (.500-20 X 1.00) (1 required per assembly)
		10-840115 - Screw [ More info ] $1.59 Available to Order: Shipping delay up to 10 days.
#6	846941	WASHER (.530 X 1.06 X .095) (1 required per assembly)
		12-846941 - Washer, (.530 X 1.06 X .095) [ More info ] $0.83 Available to Order: Shipping delay up to 10 days.
#7	844312	PISTON (1 required per assembly)
		844312 - Piston [ More info ] $47.98 Available to Order: Shipping delay up to 10 days.
#8	846364	O-RING (1.600 X .190) (1 required per assembly)
		25-846364 - O-ring, (1.600 X .190) [ More info ] $0.80 Available to Order: Shipping delay up to 10 days.
#9	23145	O-RING (.984 X .139) [0M969067] & Below (3 required per assembly)
		25-23145 - O-ring, (.984 X .139) [ More info ] $1.99 1 In Stock.
		18-7114 - O-Ring 25-23145, 302540 [ More info ] $2.02 $1.59 7 In Stock.
#9	8M0063091	SEAL [0M969068] & Up (1 required per assembly)
		258M0063091 - Seal [ More info ] $15.35 Available to Order: Shipping delay up to 10 days.
#10	8M0007455	O-RING (1.984 X .139) (1 required per assembly)
		25-8M0007455 - O-ring, (1.984 X .139) [ More info ] $3.64 Available to Order: Shipping delay up to 10 days.
#11	8M0079618	END CAP ASY [0M969068] & Up (1 required per assembly) — Replaces: 844307, 8M0072264
		11008M0079618 - End Cap ASY [ More info ] $112.99 Available to Order: Shipping delay up to 10 days.
#12	843311	SCRAPER (1 required per assembly)
		843311 - Scraper [ More info ] $72.34 Available to Order: Shipping delay up to 10 days.
#13	844309	RETAINER SCRAPER (1 required per assembly)
		844309 - Retainer -scraper [ More info ] $5.07 Available to Order: Shipping delay up to 10 days.
#14	69028	SCREW (.250-28 X .750) STAINLESS STEEL (2 required per assembly)
		10-69028 - Screw [ More info ] $2.89 $1.63 10+ In Stock.
#15	8M0080800	ROD-TRIM PISTON (1 required per assembly) — Replaces: 8M0007368
		8M0080800 - Trim Piston Rod [ More info ] $614.98 Available to Order: Shipping delay up to 10 days.
#16	846856	BEARING (1 required per assembly)
		23-846856 - Bearing [ More info ] $96.59 Available to Order: Shipping delay up to 10 days.
