Parts for Alpha One Ss MerCruiser Outdrive Units Gear Housing Assy (Driveshaft & Propshaft) (III)

Revise Search: Sterndrive > MerCruiser Outdrive Units > Alpha One Ss > 1986-1989 All & Up > Gear Housing Assy (Driveshaft & Propshaft) (III)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gear Housing Assy (Driveshaft & Propshaft) (III)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	4354A3	GEAR HOUSING ASSEMBLY (BASIC) (1 required per assembly)
		1636-4354A 3 - GEAR Housing, NLA [ More info ] Unavailable
#2	8M0041668	STUD (.437-14/.437-20 X 1.875) (1 required per assembly) — Replaces: 57982
		16-8M0041668 - Stud [ More info ] $15.49 1 In Stock.
#3	57985	STUD (2.810) (1 required per assembly) — Replaces: 57986
		16-57985 - Stud [ More info ] $34.12 1 In Stock.
#4	35246	BEARING ROLLER (1 required per assembly)
		31-35246 - Roller Bearing - Drive Shaft [ More info ] $86.99 $73.67 10+ In Stock.
		18-1120 - Bearing [ More info ] $126.76 In Stock
#5	57981	STUD (.375-16 X 3.00) (4 required per assembly)
		16-57981 - STUD,NLA [ More info ] Unavailable
#6	316404	ANODE/TRIM TAB (1 required per assembly) — Replaces: 31640A1, 316403
		0316404 - L/P 167.90 [ More info ] Unavailable
#7	41350	SCREW (1 required per assembly)
		10-41350 - Screw [ More info ] $27.49 Available to Order: Shipping delay up to 10 days.
#8	47295A1	SHIM SET (AR required per assembly)
		15-47295A 1 - Shim Set, NLA [ More info ] $10.00 $8.47 5 In Stock.
#9	47484A1	BEARING (1 required per assembly)
		31-47484A 1 - Tapered Roller Bearing [ More info ] Unavailable
#10	53572A2	GEAR ASSEMBLY (PINION AND DRIVE) (1 required per assembly)
		43-53572A 2 - Gear Set,NLA [ More info ] Unavailable
#11	48016	SPACER (1 required per assembly)
		23-48016 - SPACER,NLA [ More info ] Unavailable
#12	48015	SPACER (1 required per assembly)
		23-48015 - Spacer - Propeller Shaft [ More info ] $9.00 $7.62 1 In Stock.
#13	53516	ADAPTOR (1 required per assembly)
		53516 - Adaptor, NLA [ More info ] Unavailable
#14	48011	SLEEVE (1 required per assembly)
		23-48011 - Sleeve, NLA [ More info ] Unavailable
#15	53308	PIN DOWEL (1 required per assembly)
		17-53308 - Pin, Dowel, NLA [ More info ] $1.00 $0.85 10+ In Stock.
#16	47484A1	BEARING (1 required per assembly)
#17	47297A1	SHIM SET (AR required per assembly)
		15-47297A 1 - Shim Set, NLA [ More info ] $16.00 $13.55 1 In Stock.
#18	53185A1	PROPELLER SHAFT ASSEMBLY (1.250-12) (1 required per assembly)
		44-53185A 1 - Prop Shaft, NLA [ More info ] Unavailable
#19	47307	RING THRUST (1 required per assembly)
		47307 - RING-THRUST,NLA [ More info ] Unavailable
#20	47298	O RING (1 required per assembly)
		25-47298 - O-Ring [ More info ] Unavailable
#21	52623A2	CARRIER ASSEMBLY BEARING BEARING (1 required per assembly)
		52623A 2 - CARRIER ASSY,NLA [ More info ] Unavailable
#22	47946	BEARING ROLLER (1 required per assembly)
		31-47946 - Bearing - Roller [ More info ] $10.00 $8.47 2 In Stock.
#23	19473	SEAL OIL (2 required per assembly)
		26-19473 - Seal [ More info ] $56.07 Available to Order: Shipping delay up to 10 days.
#24	30281	KEY @5 (1 required per assembly)
		28-30281 - Key - Priced Individually [ More info ] $2.99 10 In Stock.
#25	52553	WASHER-TAB (1 required per assembly)
		14-52553 - WASHER-TAB,NLA [ More info ] Unavailable
#26	52622	COVER (1 required per assembly)
		52622 - Gear Housing Cover [ More info ] Unavailable
#27	79953Q2	SCREW KIT @2 (1 required per assembly) — Replaces: 79953, 79953A2
		10-79953Q 2 - Screw Kit - Priced Individually [ More info ] Unavailable
		10-79953Q04 - Screw Kit - Priced Individually [ More info ] $7.49 10+ In Stock.
		18-2244 - Plug Kit, 10-79953A2 [ More info ] $3.79 10+ In Stock.
		10-79953K04 - Drain Screw - Priced Individually [ More info ] $8.19 10+ In Stock.
#28	191833	SEAL-BLUE @15 (1 required per assembly) — Replaces: 19183, 191832
		12-19183 3 - Seal -Blue - Priced Individually [ More info ] Unavailable
		18-2945-9 - Gasket 12-19183 2-Pack [ More info ] $2.41 10+ In Stock.
		12-19183Q02 - Seals, Pack of 4 (yes this is actually a pack of 4) [ More info ] $6.69 10 In Stock.
		12-19183K02 - Seal, Pack of 4 [ More info ] $7.29 10 In Stock.
		12-8M0187157 - SEAL-BLUE, Sold Individually [ More info ] $1.49 10+ In Stock.
		12-02108-1 - Drain Gasket (1 piece) [ More info ] $1.20 $0.85 10+ In Stock.
#29	32073	WASHER (1 required per assembly)
		12-32073 - WASHER,NLA [ More info ] Unavailable
#30	858869	NUT @5 (1 required per assembly) — Replaces: 56041, 30499
		11-858869 - Nut, (.875-14) [ More info ] $4.99 4 In Stock.
#31	47323	DRIVESHAFT (1 required per assembly)
		45-47323 - Drive Shaft, NLA [ More info ] $165.00 $139.76 1 In Stock.
#32	39808A1	SHIM SET (AR required per assembly)
		15-39808A 1 - Shim Set, NLA [ More info ] $6.00 $5.08 8 In Stock.
#33	47669A2	BEARING (1 required per assembly)
		31-47669A 2 - Tapered Roller Bearing [ More info ] Unavailable
#34	47603	ELBOW (1 required per assembly)
		23-47603 - SPACER,NLA [ More info ] Unavailable
#35	39808A1	SHIM SET (AR required per assembly)
#36	56042	WASHER (1 required per assembly)
		12-56042 - Washer, Tapered Roller Bearing To Drive Shaft [ More info ] Unavailable
#37	34826	NUT (1.250-16) (1 required per assembly)
		11-34826 - Nut (1.250-16)NLA [ More info ] Unavailable
#38	20081	O-RING (LARGE) (1 required per assembly)
		25-20081 - O-Ring - Priced Individually [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#39	47315	RETAINER (1 required per assembly)
		47315 - Retainer, NLA [ More info ] Unavailable
#40	45711	O-RING (.612 X .103) (SMALL) (1 required per assembly)
		25-45711 - Valve Cover O-Ring, Priced Individually [ More info ] $1.80 8 In Stock.
#41	82671013	NUT @5 (4 required per assembly) — Replaces: 34932
		11-826710 13 - Nut, (.375-24) Stainless Steel [ More info ] $4.69 10+ In Stock.
		18-3720-9 - Lock Nut, 11-34932, 5PK [ More info ] $16.40 Available to Order: Shipping delay up to 10 days.
#42	47317	GASKET (1 required per assembly)
		27-47317 - Gear Housing To Drive Shaft Housing Gasket [ More info ] Unavailable
#43	47302	NUT (6 required per assembly)
		11-47302 - Nut, (.562-18) Stainless Steel [ More info ] $14.55 3 In Stock.
#44	47557	SCREW (1 required per assembly)
		10-47557 - Screw, NLA [ More info ] $3.59 10+ In Stock.
#45	48018A1	THRUST HUB ASSY (1 required per assembly)
		48018A 1 - Thrust Hub Assembly [ More info ] $10.99 $9.30 6 In Stock.
#46	37763	WASHER THRUST (1 required per assembly)
		12-37763 - Washer - Thrust - Bearing Carrier [ More info ] $3.00 $2.54 10+ In Stock.
#47	48014	WASHER (1 required per assembly)
		12-48014 - Washer, Splined - Propeller Shaft, NLA [ More info ] Unavailable
#48	48012	WASHER-TAB (1 required per assembly)
		14-48012 - Tab Washer, NLA [ More info ] $3.00 $2.54 10+ In Stock.
#49	17844	NUT (1.250-12) (1 required per assembly)
		11-17844 - Nut (1.250-12) NLA [ More info ] $20.00 $16.94 8 In Stock.
