Parts for 260 MerCruiser Outdrive Units Gimbal Ring Assembly & Steering Lever

Revise Search: Sterndrive > MerCruiser Outdrive Units > 260 > 1978-1982 4898730 - 6225576 > Gimbal Ring Assembly & Steering Lever

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Gimbal Ring Assembly & Steering Lever

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	805320A03	SENDR KT-ALPH/BRV (SINGLE STATION) (1 required per assembly) — Replaces: 88678A4, 805320A1
		805320A03 - Sender Kit - Alpha/Bravo [ More info ] $176.99 1 In Stock.
		18-7633 - Sender, Alpha and Bravo, 805320A03 [ More info ] $137.99 $136.66 10+ In Stock.
		TS001 - TILT TRIM SENDER [ More info ] $117.95 $103.82 In Stock
#-	17693A5	TRIM SENDER ASSY (DUAL STATION) (1 required per assembly) — Replaces: 88678A6, 96863A8
		17693A 5 - TRIM SENDER ASSY [ More info ] Unavailable
		805130A 6 - Sender Assembly - Dual [ More info ] $120.73 $115.92 5 In Stock.
#1	88302A1	GIMBAL RING KIT (SPLINED LEVER) (1 required per assembly) — Replaces: 77124A2
		88302A 1 - Gimbal Ring Kit [ More info ] Unavailable
		94993A 7 - Gimbal Ring Assembly [ More info ] $1,053.49 Available to Order: Shipping delay up to 10 days.
#1	94993A7	GIMBAL RING ASSY (SQUARE LEVER) (1 required per assembly) — Replaces: 88343A2, 94993A4
#2	32538	BEARING ROLLER - GIMBAL RING (1 required per assembly)
		31-32538 - Bearing - Roller - Gimbal Ring [ More info ] $9.98 Available to Order: Shipping delay up to 10 days.
#3	32541	SEAL OIL GIMBAL RING (2 required per assembly)
		26-32541 - Seal [ More info ] $18.99 $12.72 10+ In Stock.
#4	39273	SPACER GIMBAL RING (1 required per assembly)
		23-39273 - Sleeve [ More info ] $18.99 10+ In Stock.
#5	69059	FITTING GREASE - GIMBAL RING (1/8-27) (1 required per assembly)
		22-69059 - Fitting, Grease - Priced Individually [ More info ] $7.02 10+ In Stock.
#6	77633Q	LUBRICAP GIMBAL RING GREASE FITTING (3 required per assembly) — Replaces: 29359, 77633
		19-77633Q - Cap - Pack of 5 as shown [ More info ] $6.99 9 In Stock.
#7	77123	PIN HINGE THREADED (WITH GREASE GROOVE) (2 required per assembly)
		77123 - Hinge Pin [ More info ] $32.39 In Stock
		18-1705 - Hinge Pin 77123 [ More info ] $29.48 2 In Stock.
#8	64947	SENDER DUMMY STARBOARD (1 required per assembly)
		64947 - Dummy Sender [ More info ] $22.99 $22.00 10+ In Stock.
#8	805320A03	POWER TRIM SENDER TRIM LIMIT PORT (1 required per assembly) — Replaces: 88678A5, 805320A1
#9	19280	HARNESS DUMMY SENDER STARBOARD (1 required per assembly) — Replaces: 70967
		84-19280 - Harness, NLA [ More info ] $9.99 $8.45 5 In Stock.
#9	19292	HARNESS TRIM LIMIT SWITCH PORT (1 required per assembly) — Replaces: 70968
		84-19292 - Harness, NLA [ More info ] $44.92 8 In Stock.
#10	46942	SCREW (#6-20 X .3125) HARNESS ATTACHING STARBOARD (2 required per assembly)
		10-46942 - Screw [ More info ] $1.10 $0.22 10+ In Stock.
#10	63400	SCREW (#6-32 X .125) HARNESS ATTACHING PORT (2 required per assembly)
		10-63400 - Screw, NLA [ More info ] $1.63 $1.39 10+ In Stock.
#11	63990	INSULATOR SWITCH AND SENDER (2 required per assembly)
		85-63990 - Insulator [ More info ] $8.19 10+ In Stock.
#12	37978	SCREW (#10-32 X .750) STAINLESS STEEL AND SENDER TO GIMBAL RING (4 required per assembly)
		10-37978 - Screw - Priced Individually [ More info ] $3.39 8 In Stock.
#13	26996	LOCKWASHER (#10) STAINLESS STEEL SWITCH AND SENDER SCREW (4 required per assembly)
		13-26996 - LockWasher - Priced Individually [ More info ] $1.20 10+ In Stock.
#14	57008	RETAINER SWITCH AND SENDER SCREW (4 required per assembly)
		57008 - Retainer [ More info ] $3.99 2 In Stock.
#15	88771A1	LEVER ASSY (IN-LINE ENGINES)(SQUARE) (1 required per assembly) — Replaces: 66546A1, 88771
		88771A 1 - Lever Assembly [ More info ] Unavailable
#15	88433	LEVER (V-8 ENGINES)(SQUARE) (1 required per assembly) — Replaces: 66545
		88433 - Steering Lever [ More info ] $70.00 $59.29 7 In Stock.
#16	88302A1	GIMBAL RING KIT WITH UPPER SWIVEL SHAFT UPPER SWIVEL (SPLINED) (1 required per assembly) — Replaces: 65537
#16	88302A2	SHAFT UPPER SWIVEL (SQUARE) (1 required per assembly)
		88302A 2 - Shaft Assembly [ More info ] $139.99 $118.56 7 In Stock.
#17	72413	RING RETAINING UPPER SWIVEL SHAFT USE WITH SPLINED UPPER SHAFT (1 required per assembly)
		53-72413 - Ring, NLA [ More info ] $9.17 $7.76 10+ In Stock.
#18	8M2014641	NUT (.750-16) UPPER SWIVEL SHAFT (1 required per assembly) — Replaces: 25599, 82671323
		11-8M2014641 - Nut - Priced Individually [ More info ] $17.89 10+ In Stock.
#19	8M0204652	PLUG @2 UPPER SWIVEL SHAFT USE WITH SPLINED UPPER SHAFT (1 required per assembly) — Replaces: 32561
		22-8M0204652 - PLUG @2 [ More info ] Unavailable
#20	85344	WASHER (.750 INSIDE DIAMETER) UPPER SWIVEL SHAFT (1 required per assembly)
		12-85344 - Washer, (.750 Inside Diameter) [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#20	32997	WASHER UPPER SWIVEL SHAFT (.063) (1 required per assembly)
		12-32997 - Washer, Upper Swivel Shaft (.063) NLA [ More info ] $9.97 $8.44 10+ In Stock.
#21	807204	SCREW (.437-20 X 2.00) STEERING LEVER TO UPPER SWIVEL SHAFT (1 required per assembly) — Replaces: 32995
		10-807204 - Screw [ More info ] $4.49 Available to Order: Shipping delay up to 10 days.
#22	8M2008293	NUT (.437-20) STEERING LEVER TO UPPER SWIVEL SHAFT SCREW (1 required per assembly) — Replaces: 79857, 98533
		11-8M2008293 - Nut, (.437-20) [ More info ] $1.20 1 In Stock.
#23	68291A2	LINK ROD ASSY (IN-LINE ENGINES) (1 required per assembly)
		68291A 2 - Link Rod Assembly, NLA [ More info ] $28.00 1 In Stock.
#24	52698	SLEEVE STEERING LINK ROD (IN-LINE ENGINES) (1 required per assembly)
		23-52698 - Sleeve - Priced Individually [ More info ] $2.22 $1.88 10+ In Stock.
#25	20086	WASHER (.390 X .620 X .060) STEERING LINK ROD (IN-LINE ENGINES) (1 required per assembly)
		12-20086 - Washer, (.390 X .620 X .060) [ More info ] $1.70 10+ In Stock.
#26	46132	WASHER STEERING LINK ROD (1/8&QUOT; THICK) (IN-LINE ENGINES) (1 required per assembly)
		12-46132 - Washer [ More info ] $3.19 6 In Stock.
#27	55438	NUT (.375-24) STEERING LINK ROD (IN-LINE ENGINES) (2 required per assembly)
		11-55438 - Nut, Castle (3/8 - 24) [ More info ] $2.19 $1.76 10+ In Stock.
#28	45882	COTTER PIN STEERING LINK ROD (IN-LINE ENGINES) (2 required per assembly)
		18-45882 - Cotter Pin - Priced Individually [ More info ] $3.03 10+ In Stock.
#29	78790A6	LINK ROD ASSY V-8 ENGINES (1 required per assembly) — Replaces: 78790A4
		78790A 6 - Link Rod Assembly, NLA [ More info ] $79.99 $67.74 10 In Stock.
#30	87738A1	SCREW ASSEMBLY LEVER TO LINK ROD V-8 ENGINES (1 required per assembly)
		10-87738A 1 - Bolt Assembly, NLA [ More info ] $20.00 $16.94 10+ In Stock.
#33	20086	WASHER (.390 X .620 X .060) STEERING LINK ROD V-8 ENGINES (1 required per assembly)
#34	82671013	NUT (.375-24) STAINLESS STEEL LINK ROD SCREW V-8 ENGINES (1 required per assembly) — Replaces: 34932
		11-826710 13 - Nut, (.375-24) Stainless Steel [ More info ] $4.69 10+ In Stock.
		18-3720-9 - Lock Nut, 11-34932, 5PK [ More info ] $16.40 Available to Order: Shipping delay up to 10 days.
#35	45882	COTTER PIN LINK ROD AND SCREW V-8 ENGINES (2 required per assembly)
#36	79146	RETAINER CONNECTOR, TRIM LIMITS LEADS (2 required per assembly)
		79146 - Retainer [ More info ] $5.59 2 In Stock.
#37	88432	SCREW (.375-24 X 4.00) GIMBAL RING USE WITH SQUARE UPPER SHAFT (2 required per assembly)
		10-88432 - Screw [ More info ] $99.99 $23.90 10+ In Stock.
#38	34931	WASHER (.406 X .734 X .063) STAINLESS STEEL GIMBAL RING SCREW USE WITH SQUARE UPPER SHAFT (4 required per assembly)
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#39	82671013	NUT (.375-24) STAINLESS STEEL GIMBAL RING SCREW USE WITH SQUARE UPPER SHAFT (2 required per assembly) — Replaces: 34932
#15A	52698	SLEEVE STEERING LEVER IN-LINE ENGINES (SPLINED) (1 required per assembly)
#34A	55438	NUT (.375-24) STEERING LINK ROD V-8 ENGINES (1 required per assembly)
#35A	87739	SPRING LINK ROD SCREW V-8 ENGINES (1 required per assembly)
		24-87739 - Spring, Link Rod Screw [ More info ] $14.00 $11.86 4 In Stock.
#5A	8M0169589	FITTING GREASE GIMBAL RING (1/4-28) (2 required per assembly) — Replaces: 74036
		228M0169589 - Fitting Note: Priced Individually [ More info ] $4.79 1 In Stock.
