Parts for 228 MerCruiser Outdrive Units Driveshaft Housing Assembly & Driveshaft

Revise Search: Sterndrive > MerCruiser Outdrive Units > 228 > 1978-1982 4898730 - 6225576 > Driveshaft Housing Assembly & Driveshaft

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Driveshaft Housing Assembly & Driveshaft

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	32511A1	SEAL KIT (1 required per assembly)
		26-32511A 1 - Seal Kit [ More info ] $77.49 In Stock
		18-2648 - Seal Kit, 26-32511A1 [ More info ] $31.98 10+ In Stock.
		26-03809 - Seal Kit 26-32511A 1 [ More info ] $41.99 $27.20 4 In Stock.
#1	9106A3	DRIVE SHAFT HSG (1 required per assembly) — Replaces: 5523A18, 8265A13
		1547-9106A 3 - Drive Shaft Housing [ More info ] Unavailable
		1547-9412A18 - Drive Shaft Housing Only Alpha -Basic [ More info ] $161.68 9 In Stock.
#2	42724A3	COVER WATER POCKET COVER (1 required per assembly) — Replaces: 54235A2
		42724A 3 - Cover Assembly [ More info ] $50.49 In Stock
		18-3219 - Tube, 42724A3 [ More info ] $41.49 $40.54 2 In Stock.
		93-01813 - Water Housing Kit, 42724A 3 [ More info ] $38.99 $32.12 In Stock
#3	36557	SEAL RUBBER-WATER POCKET COVER (1 required per assembly)
		26-36557 - Seal - Priced Individually [ More info ] $4.49 10+ In Stock.
		18-0521 - Gasket, 26-36557 [ More info ] $1.38 $1.16 10+ In Stock.
#4	558101	GASKET WATER POCKET COVER (1 required per assembly) — Replaces: 55810
		27-55810 1 - Gasket [ More info ] $3.19 $3.10 10+ In Stock.
#5	28668	SCREW (.250-20 X .875) STAINLESS STEEL WATER POCKET COVER TO DRIVESHAFT HOUSING (4 required per assembly)
		10-28668 - Screw - Priced Individually [ More info ] $1.70 4 In Stock.
#6	54236	TUBE WATER-WATER POCKET COVER (1 required per assembly)
		32-54236 - Tubing [ More info ] $17.89 $7.87 1 In Stock.
		18-3220 - Water Tube [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#7	76731A1	DECAL SET DRIVESHAFT HOUSING (1 required per assembly)
		37-76731A 1 - Decal Set [ More info ] $66.99 Available to Order: Shipping delay up to 10 days.
#8	76749	DECAL DRIVESHAFT HOUSING (120) (1 required per assembly)
		37-76749 - Decal, NLA [ More info ] $3.12 $2.65 6 In Stock.
#8	76750	DECAL DRIVESHAFT HOUSING (140) (1 required per assembly)
		37-76750 - Decal, NLA [ More info ] $6.00 $5.08 5 In Stock.
#8	76751	DECAL DRIVESHAFT HOUSING (165) (1 required per assembly)
		37-76751 - Decal, NLA [ More info ] $5.50 $4.67 5 In Stock.
#8	76730	DECAL DRIVESHAFT HOUSING (470) (1 required per assembly)
		37-76730 - Decal, NLA [ More info ] Unavailable
#8	91969	DECAL DRIVESHAFT HOUSING (485) (1 required per assembly)
		37-91969 - Decal, NLA [ More info ] Unavailable
#8	77649	DECAL DRIVESHAFT HOUSING (898) (1 required per assembly)
		37-77649 - Decal, 898 [ More info ] Unavailable
#8	76998	DECAL DRIVESHAFT HOUSING (228) (1 required per assembly)
		37-76998 - Decal, NLA [ More info ] Unavailable
#8	79411	DECAL DRIVESHAFT HOUSING (260) (1 required per assembly)
		37-79411 - Decal, NLA [ More info ] Unavailable
#9	965031	SEAL OIL DRIVESHAFT HOUSING-LOWER (1 required per assembly) — Replaces: 96503
		26-96503 1 - Seal - Priced Individually [ More info ] $18.89 Available to Order: Shipping delay up to 10 days.
		18-2056 - Seal, 26-96503 1 [ More info ] $15.52 8 In Stock.
		26-00167 - Seal, 26-96503 1 [ More info ] $12.79 $10.71 Available to Order: Shipping delay up to 10 days.
#10	32511	SEAL OIL GEAR CHAMBER-DRIVESHAFT HOUSING (1 required per assembly)
		26-32511 - Seal - Priced Individually [ More info ] $25.99 10+ In Stock.
		18-2049 - Seal, 26-32511 [ More info ] $21.47 1 In Stock.
#11	36178A02	SHIM SET BEARING CUP TO DRIVESHAFT HOUSING (.002-3-5-10-15) (AR required per assembly) — Replaces: 36178A1
		15-36178A02 - Shim Set [ More info ] $17.99 Available to Order: Shipping delay up to 10 days.
#12	55796	DRIVESHAFT UPPER (1 required per assembly)
		45-55796 - Drive Shaft [ More info ] $168.49 $40.34 7 In Stock.
#13	55801	O-RING UPPER DRIVESHAFT (1 required per assembly)
		25-55801 - O-ring, Upper Drive Shaft [ More info ] $1.99 10+ In Stock.
#14	76098A1	COVER ASSEMBLY TOP-DRIVESHAFT HOUSING (1 required per assembly)
		76098A 1 - Cover Assembly [ More info ] $128.75 10+ In Stock.
#15	61100A1	BEARING ASSEMBLY DRIVESHAFT (1 required per assembly)
		31-61100A 1 - Bearing - Driveshaft [ More info ] $91.99 $90.88 10+ In Stock.
		18-1165 - Bearing, 31-61100A1 [ More info ] $51.33 1 In Stock.
#16	45691A1	SHIM BEARING CUP TO TOP COVER (AR required per assembly)
		15-45691A 1 - Shim Set [ More info ] $14.49 $8.13 5 In Stock.
#17	32546	O-RING TOP COVER SEALING (1 required per assembly)
		25-32546 - O-Ring - Priced Individually [ More info ] $4.09 2 In Stock.
		18-7161-9 - (PK5) O-Ring 25-32546 [ More info ] $17.05 4 In Stock.
#18	8M0113174	SCREW (.375-16 X 1.25) TOP COVER TO DRIVESHAFT HOUSING (4 required per assembly) — Replaces: 58640
		10-8M0113174 - Screw, .375-16, Priced Individually [ More info ] $7.29 1 In Stock.
