Parts for Formula 60 4-Stroke Mercury Outboard Motor Cylinder Head
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 893505T05 | CYLINDER HEAD ASSY.-4CYL EFI (1 required per assembly) |
  |
|
893505T05 - Cylinder Head Assembly [ More info ] Unavailable |
| #- | 883599A02 | GASKET SET (1 required per assembly) |
  |
|
27-883599A02 - Engine Gasket Set [ More info ]
|
| #- | 893678T03 | GREEN PH ASY-4CYL(NO CYL HEAD) (Does Not Include Cylinder Head) (1 required per assembly) |
  |
|
61893678T03 - GREEN PH ASY-4CYL(No Cy [ More info ] Unavailable |
| #1 | 8M0119522 | CYLINDER HEAD ASSEMBLY BASIC (1 required per assembly) — Replaces: 893505A02, 893505T06 |
  |
|
9008M0119522 - Cylinder Head [ More info ]
|
| #2 | 858266 | GUIDE (8 required per assembly) |
  |
|
858266 - Valve Guide, NLA [ More info ]
|
| #3 | 4000325 | SCREW (M6 X 8) (4 required per assembly) |
  |
|
10-40003 25 - Screw [ More info ]
|
| #4 | 859768 | WASHER (4 required per assembly) |
  |
|
12-859768 - Washer [ More info ]
|
| #5 | 893549 | SEAL OIL (1 required per assembly) — Replaces: 858267 |
  |
|
26-893549 - Oil Seal [ More info ]
|
| #6 | 875209 | PIPE PLUG (8 required per assembly) |
  |
|
22-875209 - Pipe Plug [ More info ]
|
| #7 | 8M0011870 | SEAL (1 required per assembly) |
  |
|
25-8M0011870 - Seal [ More info ]
|
| #8 | 8M0174400 | COVER ASSY (1 required per assembly) — Replaces: 893694T02 |
  |
|
8M0174400 - Cover [ More info ]
|
| #9 | NSS | NOT SOLD SEPARATE BREATHER PIPE (1 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #10 | NSS | NOT SOLD SEPARATE BAFFLE PLATE (1 required per assembly) |
| #11 | NSS | NOT SOLD SEPARATE SCREW (1 required per assembly) |
| #12 | 629101 | ELBOW (1 required per assembly) |
  |
|
22-62910 1 - Elbow [ More info ]
|
| #13 | 8M0118179 | HEAD GASKET - 4CYL (1 required per assembly) — Replaces: 857081, 8M0045278 |
  |
|
27-8M0118179 - Head Gasket [ More info ]
|
| #14 | 8M0204741 | SCREW @4 (7 required per assembly) — Replaces: 40011128, 8M4503518 |
  |
|
108M0204741 - SCREW Note: Priced Individually [ More info ]
|
| #15 | 893747095 | SCREW-HX HD SEMS M9X1.25X95 (10 required per assembly) — Replaces: 82503395 |
  |
|
10893747095 - SCREW [ More info ]
|
  |
|
10-8M0241964 - SCREW [ More info ] Unavailable |
| #16 | 825010 | PIN-DOWEL (2 required per assembly) |
  |
|
17-825010 - Pin -Dowel [ More info ]
|
| #17 | 859578A1 | PLUG ASSY-OIL (1 required per assembly) |
  |
|
859578A 1 - Oil Plug Assembly [ More info ]
|
| #18 | 8M0204673 | O RING (1 required per assembly) — Replaces: 90196 |
  |
|
258M0204673 - O RING [ More info ]
|
| #19 | NSS | NOT SOLD SEPARATE DECAL-SERVICING REFERRAL (1 required per assembly) |
| #20 | NSS | NOT SOLD SEPARATE DECAL-ENGINE OIL/VALVE CLEARANCE (1 required per assembly) |
| #21 | 77653101 | HOSE (48.00 INCHES BULK) CUT TO 19 INCHES - TO FITTING IN ADAPTOR PLATE (1 required per assembly) |
  |
|
32-77653101 - Hose -48 Inch [ More info ]
|
| #22 | 816311T | TIE STRAP @100 (2 required per assembly) |
  |
|
54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ]
|
| #23 | 893745025 | SCREW-HEX HD SEMS M6X1X25 (5 required per assembly) — Replaces: 82500925 |
  |
|
10893745025 - Screw (M6 x 25) [ More info ]
|
| #24 | NSS | NOT SOLD SEPARATE DECAL HP ID (1 required per assembly) |
| #25 | 8M0026326 | DEFLECTOR (1 required per assembly) |
  |
|
8M0026326 - Deflector [ More info ]
|
| #26 | 8M0012661 | SCREW (2 required per assembly) |
  |
|
10-8M0012661 - Screw [ More info ]
|
