Parts for Formula 60 4-Stroke Mercury Outboard Motor Crankshaft, Pistons & Connecting Rods
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 883599A02 | GASKET SET (1 required per assembly) |
  |
|
27-883599A02 - Engine Gasket Set [ More info ]
|
| #- | 893678T03 | GREEN PH ASY-4CYL(NO CYL HEAD) (Does not include cylinder head) (1 required per assembly) |
  |
|
61893678T03 - GREEN PH ASY-4CYL(No Cy [ More info ] Unavailable |
| #1 | 857077T02 | CRANKSHAFT ASSEMBLY-4CYL (1 required per assembly) |
  |
|
413-857077T02 - CrankShaft Assemblyb [ More info ]
|
| #2 | 91800 | KEY WOODRUFF (1 required per assembly) |
  |
|
28-91800 - Key - Priced Individually [ More info ]
|
| #3 | 893761 | KEY (1 required per assembly) — Replaces: 18856M |
  |
|
28893761 - Key - Priced Individually [ More info ]
|
| #4 | 8M0151047 | SEAL-OIL (1 required per assembly) — Replaces: 825027, 893949 |
  |
|
268M0151047 - Seal-OIL [ More info ]
|
| #5 | 8M0151048 | SEAL-OIL (1 required per assembly) — Replaces: 832013, 893948 |
  |
|
268M0151048 - Seal-OIL [ More info ]
|
| #6 | 893530T01 | CONNECTING ROD ASSEMBLY (4 required per assembly) — Replaces: 856065T1 |
  |
|
600-893530T01 - Connecting Rod As [ More info ]
|
| #7 | 8M0049884 | BOLT (8 required per assembly) — Replaces: 825019 |
  |
|
10-8M0049884 - Screw [ More info ]
|
| #8 | 893630001 | BEARING BLACK (8/AR required per assembly) |
  |
|
23-893630001 - Bearing - Black [ More info ]
|
| #8 | 893630 | BEARING BROWN (8/AR required per assembly) |
  |
|
23-893630 - Bearing - Brown [ More info ]
|
| #8 | 893630002 | BEARING BLUE (8/AR required per assembly) |
  |
|
23-893630002 - Bearing - Blue [ More info ]
|
| #9 | 893524T08 | PISTON ASSY (4 required per assembly) |
  |
|
700-893524T08 - Piston Assembly [ More info ]
|
| #9 | 8M0057775 | PISTON ASSY-.25 .25MM Oversized/Bare Piston (AR required per assembly) — Replaces: 893524T01 |
  |
|
7008M0057775 - Piston Assembly -.25 [ More info ]
|
| #9 | 8M0057776 | PISTON ASSY-.50 .50MM Oversized/Bare Piston (AR required per assembly) — Replaces: 893524T02 |
  |
|
7008M0057776 - Piston Assembly -.50 [ More info ]
|
| #10 | 893525A01 | RING SET PISTON Standard (4 required per assembly) |
  |
|
39-893525A01 - Piston Rings [ More info ]
|
| #10 | 893525A02 | RING SET .25 O/S .25MM Oversized (AR required per assembly) |
  |
|
39-893525A02 - Rings .25 Oversize [ More info ]
|
| #10 | 893525A03 | RING SET .50 O/S .50MM Oversized (AR required per assembly) |
  |
|
39-893525A03 - Rings .50 Oversize [ More info ]
|
| #11 | NSS | NOT SOLD SEPARATE PISTON RING - SECOND 50 MM Oversized (AR required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #12 | NSS | NOT SOLD SEPARATE RING, PISTON OIL (4 required per assembly) |
| #13 | 893863 | PIN PISTON (4 required per assembly) |
  |
|
41-893863 - Piston Pin [ More info ]
|
| #14 | 893529 | RETAINER PISTON PIN (8 required per assembly) |
  |
|
40-893529 - Retainer [ More info ]
|
