Parts for 9.9 HP Carb (232 Cc) 4-Stroke Mercury Outboard Motor Carburetor

Revise Search: Outboard > 4-Stroke Mercury Outboard > 9.9 HP Carb (232 Cc) > 0H000058 - 0H016909 - USA > Carburetor

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Carburetor

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	828099	STOP THROTTLE 8 BODENSEE (1 required per assembly)
		828099 - STOP Throttle NLA [ More info ] Unavailable
#-	821285	NUT-PUSH @5 8 BODENSEE (1 required per assembly)
		11-821285 - Push Nut - Priced Individually [ More info ] $1.70 $1.36 2 In Stock.
#-	827493M	REPAIR KIT-CARB (1 required per assembly)
		827493M - Carburetor Repair Kit, NLA [ More info ] $60.00 2 In Stock.
#-	855107T1	CARBURETOR [0H013399] & Below (1 required per assembly) — Replaces: 825601A1, 855107A1
		3323-855107T 1 - Carburetor [ More info ] Unavailable
		3323-855107T02 - Carburetor [ More info ] Unavailable
#-	827973T1	CARBURETOR (BODENSEE) [0H013400] THRU [0H014137] (1 required per assembly) — Replaces: 827973A1
		3323-827973T 1 - Carburetor [ More info ] Unavailable
#-	855107T02	CARBURETOR [0H014138] & Up (1 required per assembly) — Replaces: 855107A1, 855107T1
#1	82980M	SCREW (2 required per assembly)
		10-82980M - Screw, NLA [ More info ] $1.25 $1.06 10+ In Stock.
#2	82212M	LOCKWASHER (2 required per assembly)
		13-82212M - LockWasher - Priced Individually [ More info ] $1.10 10+ In Stock.
#3	827473T	STARTER ASSY (1 required per assembly) — Replaces: 827473M
		827473T - Starter,NLA [ More info ] Unavailable
#4	827472T	O RING (1 required per assembly) — Replaces: 827472M
		25-827472T - O-Ring [ More info ] $8.99 Available to Order: Shipping delay up to 10 days.
#5	827471M	PIPE (1 required per assembly)
		32-827471M - Tubing, NLA [ More info ] Unavailable
#6	827482M	CLAMP (1 required per assembly)
		54-827482M - Clamp [ More info ] $1.50 $1.28 10+ In Stock.
#7	827468M	SEAL USE WITH ADJUSTABLE SCREW (1 required per assembly)
		26-827468M - Seal, NLA [ More info ] $1.63 $1.39 10+ In Stock.
#8	827469M	SCREW AIR ADJUSTING [0H013399] & Below (1 required per assembly)
		10-827469M - Screw, NLA [ More info ] $4.00 $3.39 1 In Stock.
#8	809125M	SCREW AIR ADJUSTING (BODENSEE) [0H013400] THRU [0H014137] (1 required per assembly)
		10-809125M - SCREW Air Adjusti NLA [ More info ] Unavailable
#9	80437M	SPRING USE WITH ADJUSTABLE SCREW (1 required per assembly)
		24-80437M - Spring, Air Adjusting Screw, NLA [ More info ] $1.67 $1.42 10 In Stock.
#10	855237	PLUG [0H014138] & Up (1 required per assembly)
		19-855237 - Plug , NLA [ More info ] $2.14 10+ In Stock.
#11	826931M	SCREW (1 required per assembly)
		10-826931M - Screw -thottle [ More info ] Unavailable
#12	82596M	SPRING PILOT ADJUSTING (1 required per assembly)
		24-82596M - Spring, Pilot Adjusting [ More info ] Unavailable
#13	825522	STUD (2 required per assembly)
		16-825522 - Stud, NLA [ More info ] $6.52 $5.53 10+ In Stock.
#14	80451M	PIN (1 required per assembly)
		17-80451M - Pin, NLA [ More info ] Unavailable
#15	827485M	ROD ACCELERATOR PUMP [0H013399] & Below (1 required per assembly)
		827485M - Starter Rod, NLA [ More info ] $7.00 $5.93 4 In Stock.
#15	809127M	ROD ACCELERATOR PUMP (BODENSEE) [0H013400] & Up (1 required per assembly)
		809127M - ROD Accelerator P NLA [ More info ] Unavailable
#16	82537M	NUT (1 required per assembly)
		11-82537M - Nut, NLA [ More info ] $1.63 $1.39 10+ In Stock.
#17	827486M	SHAFT CHOKE (1 required per assembly)
		827486M - Choke Shaft, NLA [ More info ] $9.00 $7.62 4 In Stock.
#18	827488M	WASHER (2 required per assembly)
		12-827488M - Washer, NLA [ More info ] Unavailable
#19	827489M	CLIP (2 required per assembly)
		53-827489M - Clip, NLA [ More info ] $4.08 10+ In Stock.
#19	809123M	MAIN NOZZLE BODENSEE (1 required per assembly)
		809123M - MAIN NOZZLE NLA [ More info ] Unavailable
#20	827467M	MAIN NOZZLE [0H013400] & Up (1 required per assembly)
		827467M - Main Nozzle, NLA [ More info ] $38.67 8 In Stock.
#20	82625M	MAIN JET BODENSEE (1 required per assembly)
		82625M - JET,NLA [ More info ] Unavailable
#21	91741M	JET [0H013400] & Up (1 required per assembly)
		91741M - Jet, NLA [ More info ] Unavailable
#21	809124M	O-RING BODENSEE (1 required per assembly)
		25-809124M - O-Ring [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#22	809128M	SCREW [0H013400] & Up (1 required per assembly)
		10-809128M - Screw, NLA [ More info ] $6.51 10+ In Stock.
#23	14182M	VALVE (1 required per assembly)
		14182M - Needle Valve [ More info ] $16.99 Available to Order: Shipping delay up to 10 days.
#24	827465M	JET PILOT (1 required per assembly)
		827465M - Jet -Pilot, NLA [ More info ] $6.99 $5.91 10+ In Stock.
#25	80960M	GASKET (1 required per assembly)
		27-80960M - Valve Gasket [ More info ] $8.61 10+ In Stock.
#26	827466M	PLUG MAIN NOZZLE (1 required per assembly)
		19-827466M - Plug, NLA [ More info ] $3.59 10+ In Stock.
#27	827470M	FLOAT (1 required per assembly)
		827470M - Float,NLA [ More info ] Unavailable
#28	827463M	GASKET FLOAT CHAMBER (1 required per assembly)
		27-827463M - Gasket, NLA [ More info ] $13.75 Available to Order: Shipping delay up to 10 days.
#29	827474M	FILTER (1 required per assembly)
		35-827474M - Filter, NLA [ More info ] $3.90 10+ In Stock.
#30	827475M	JET STARTING (1 required per assembly)
		827475M - Jet - Starter, NLA [ More info ] $9.66 $8.18 10+ In Stock.
#31	827483M	VALVE CHOKE (1 required per assembly)
		827483M - Choke Valve [ More info ] Unavailable
#32	827480M	SCREW (1 required per assembly)
		10-827480M - Screw, NLA [ More info ] $1.83 $1.56 10+ In Stock.
#33	827481M	GASKET (1 required per assembly)
		27-827481M - Screw Gasket [ More info ] $4.30 10+ In Stock.
#34	827477M	SCREW DRAIN (1 required per assembly)
		10-827477M - Drain Screw [ More info ] $10.00 10+ In Stock.
#35	827476M	O-RING (1 required per assembly)
		25-827476M - O-Ring, NLA [ More info ] $6.99 $5.91 10+ In Stock.
#36	827464M	FLOAT BOWL (1 required per assembly)
		827464M - Body, NLA [ More info ] Unavailable
#37	82206M	LOCKWASHER (4 required per assembly)
		13-82206M - LockWasher - Priced Individually [ More info ] $1.08 10+ In Stock.
#38	91738M	SCREW (4 required per assembly)
		10-91738M - Screw, NLA [ More info ] $1.50 $1.28 10+ In Stock.
#39	827479M	SPRING (1 required per assembly)
		24-827479M - Spring, NLA [ More info ] Unavailable
#40	827478M	DIAPHRAGM (1 required per assembly)
		827478M - Diaphragm, NLA [ More info ] $79.99 2 In Stock.
#41	827484M	COVER [0H013399] & Below (1 required per assembly)
		827484M - Cover, NLA [ More info ] Unavailable
#41	809126M	COVER (BODENSEE) [0H013400] & Up (1 required per assembly)
		809126M - COVER NLA [ More info ] Unavailable
#42	827487M	SPRING ( required per assembly)
		24-827487M - Spring, NLA [ More info ] $4.88 10+ In Stock.
#43	82206M	LOCKWASHER (2 required per assembly)
#44	83509M	SCREW (M4 X 10) (2 required per assembly)
		10-83509M - Screw, NLA [ More info ] $1.79 10+ In Stock.
#45	827737	SEAL (BODENSEE) [0H013400] & Up (1 required per assembly)
		26-827737 - Seal [ More info ] $6.45 10+ In Stock.
