Parts for 80 HP EFI Jet 4-Stroke Mercury Outboard Motor Power Trim Assembly - Components

Revise Search: Outboard > 4-Stroke Mercury Outboard > 80 HP EFI Jet > 2B095049 & Up > Power Trim Assembly - Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Power Trim Assembly - Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	8M0171820	ORING KIT TRIM (1 required per assembly) — Replaces: 8M0089947
		25-8M0171820 - O-Ring Kit, Trim [ More info ] $126.97 3 In Stock.
#-	8M0127334	VALVE KIT (1 required per assembly)
		988M0127334 - Valve Kit [ More info ] $29.09 Available to Order: Shipping delay up to 10 days.
#1	8M0089943	MANIFOLD KIT (1 required per assembly)
		8M0089943 - Manifold Kit [ More info ] $509.49 Available to Order: Shipping delay up to 10 days.
#2	893929A01	VALVE KIT RELIEF (1 required per assembly)
		893929A01 - Relief Valve [ More info ] $75.01 3 In Stock.
		18-6751 - Relief Valve, 893929A01 [ More info ] $64.75 4 In Stock.
#3	8M0089945	VALVE KIT (1 required per assembly)
		8M0089945 - Valve Kit [ More info ] $174.99 Available to Order: Shipping delay up to 10 days.
#4	8M0090404	VALVE KIT TRIM LIMIT (1 required per assembly)
		8M0090404 - Valve Kit Trim Limit [ More info ] $182.49 Available to Order: Shipping delay up to 10 days.
#5	833063	O-RING (2 required per assembly)
		833063 - O-RING [ More info ] Unavailable
#6	8M0055260	DOWEL PINS (3 required per assembly)
		8M0055260 - DOWEL PINS [ More info ] Unavailable
#7	811613	PLUG ASSEMBLY (1 required per assembly)
		19-811613 - Plug Assembly [ More info ] $29.99 Available to Order: Shipping delay up to 10 days.
#8	833047	SCREW (2 required per assembly)
		10-833047 - Screw [ More info ] $5.59 $1.12 10+ In Stock.
#9	8M0089941	TRIM CYLINDER KIT (1 required per assembly)
		8M0089941 - Trim Cylinder Kit [ More info ] $294.49 Available to Order: Shipping delay up to 10 days.
#10	88238A13	CABLE ASSY @5 (1 required per assembly)
		88238A13 - Cable Assembly, Priced Individually [ More info ] $13.60 3 In Stock.
		8M0207768 - CABLE ASSY @5 [ More info ] Unavailable
#11	8M6002690	SCREW (1 required per assembly)
		8M6002690 - 8M6002690 - SCREW [ More info ] Unavailable Replaced by -62568
		10-62568 - Screw - Priced Individually [ More info ] $1.10 $0.88 10+ In Stock.
#12	8M0171822	MEMORY PISTON KIT Non SeaPro (1 required per assembly) — Replaces: 810776A1
		8M0171822 - MEMORY Piston Kit [ More info ] $55.49 Available to Order: Shipping delay up to 10 days.
#12	8M0100509	MEMORY PISTON ASY SeaPro (1 required per assembly)
		8M0100509 - MEMORY Piston ASY [ More info ] Unavailable
		8M0171825 - MEMORY PISTON KIT [ More info ] Unavailable
#13	8M0171819	ORING KIT (1 required per assembly) — Replaces: 893902A01
		25-8M0171819 - O-Ring Kit [ More info ] $21.25 2 In Stock.
		25-893902A01 - O-Ring Kit [ More info ] $11.99 2 In Stock.
#14	8M0171821	SHOCK ROD KIT Non SeaPro (1 required per assembly) — Replaces: 8M0089942
		8M0171821 - SHOCK ROD KIT [ More info ] $430.49 Available to Order: Shipping delay up to 10 days.
#14	8M0171824	SHOCK ROD KIT SeaPro (1 required per assembly) — Replaces: 8M0139007
		8M0171824 - SHOCK ROD KIT [ More info ] Unavailable
#15	8M0089946	SCREW KIT (1 required per assembly)
		108M0089946 - Screw Kit [ More info ] $33.99 Available to Order: Shipping delay up to 10 days.
#16	8M0142591	MOTOR KIT (1 required per assembly) — Replaces: 8M0089940
		8M0142591 - Motor KIT [ More info ] $342.49 Available to Order: Shipping delay up to 10 days.
#17	8M0090403	COUPLING-DRIVE (1 required per assembly)
		8M0090403 - Coupling [ More info ] $30.89 Available to Order: Shipping delay up to 10 days.
#18	8M0089944	PUMP KIT (1 required per assembly)
		8M0089944 - Pump Kit [ More info ] $285.99 Available to Order: Shipping delay up to 10 days.
