Parts for 65 HP EFI Jet 4-Stroke Mercury Outboard Motor Fuel Supply System-hoses & Module
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8M0090809 | SCREEN FUEL FLTR (1 required per assembly) |
  |
|
358M0090809 - Fuel Filter Screen [ More info ]
|
| #2 | 8M0204696 | CLAMP @5 (AR required per assembly) — Replaces: 855697 |
  |
|
54-8M0204696 - CLAMP Note: Priced Individually [ More info ]
|
| #3 | 8M0079868 | HOSE FSM TO RAIL (1 required per assembly) |
  |
328M0079868 - Hose FSM TO RAIL [ More info ] Unavailable |
|
  |
|
32-8M0237471 - HOSE FSM TO RAIL [ More info ] Unavailable |
| #4 | 8M0093068 | HOSE-MNFLD REF (1 required per assembly) — Replaces: 8M0060614 |
  |
328M0093068 - Hose-MNFLD REF [ More info ] Unavailable |
|
  |
|
32-8M0203774 - HOSE MANIFOLD [ More info ] Unavailable |
| #5 | 8M0145447 | INLT-FLT HOSE ASY (1 required per assembly) — Replaces: 8M0073119, 8M0090826 |
  |
32-8M0145447 - Inlet Flt Hose [ More info ] Unavailable |
|
  |
|
328M0203770 - Hose [ More info ]
|
| #6 | 879885Q | FUEL FILTER @2 (1 required per assembly) |
  |
|
35-879885Q - Fuel Filter, 5/16 Inch, Priced Individually [ More info ]
|
  |
|
18-7718 - Fuel Filter, 5/16 Inch, 35-879885T [ More info ]
|
  |
|
35-879885K - Fuel Filter, 5/16 Inch, Priced Individually [ More info ]
|
  |
|
35-35205 - Fuel Filter, 879885T or Q [ More info ]
|
| #7 | 8M0063572 | CLIP HOSE 28MM (1 required per assembly) |
  |
|
548M0063572 - Clip Hose 28MM [ More info ]
|
| #8 | 8M0090821 | FUEL FILT ASY FSM (1 required per assembly) — Replaces: 8M0061494 |
  |
328M0090821 - FUEL FILT ASY FSM [ More info ] Unavailable |
|
  |
|
32-8M0203769 - HOSE ASSY [ More info ] Unavailable |
| #9 | 8M0037098 | CLIP HOSE (2 required per assembly) |
  |
548M0037098 - Clip Hose [ More info ] Unavailable |
|
  |
|
54-8M0224396 - CLIP HOSE [ More info ] Unavailable |
| #10 | 8M0037204 | SCREW @2 (2 required per assembly) |
  |
|
10-8M0037204 - Screw - Priced Individually [ More info ]
|
| #11 | 8M0037209 | GROMMET (1 required per assembly) |
  |
|
8M0037209 - Grommet [ More info ]
|
| #12 | 8M0132733 | FUEL SUPPLY MOD (1 required per assembly) — Replaces: 8M0057676, 8M0121387 |
  |
8M0132733 - 8M0158586 [ More info ] Unavailable |
|
  |
8M0158586 - FUEL SUPPLY MODUL [ More info ] Unavailable |
|
  |
|
8M0235171 - FUEL SUPPLY MODUL [ More info ]
|
| #13 | 834985 | GROMMET (1 required per assembly) |
  |
|
25-834985 - Grommet [ More info ]
|
  |
|
25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ]
|
| #14 | 856954 | BUSHING (1 required per assembly) |
  |
|
23-856954 - Bushing [ More info ]
|
| #15 | 8M0103807 | SCREW @2 (1 required per assembly) — Replaces: 88552525 |
  |
|
108M0103807 - Screw (M6 x 25 MM) Stainless Steel [ More info ]
|
| #16 | 65567 | WASHER @2 (1 required per assembly) |
  |
|
12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ]
|
| #17 | 8M6002064 | FITTING QC 5/16 (1 required per assembly) |
  |
|
228M6002064 - Fitting QC 5/16 [ More info ]
|
| #17 | 8M6002065 | FITTING-10 MM (1 required per assembly) |
  |
|
228M6002065 - Fitting-10 MM [ More info ]
|
