Parts for 40 HP EFI Seapro 4 Cyl 4-Stroke Mercury Outboard Motor Intake / Exhaust Valves

Revise Search: Outboard > 4-Stroke Mercury Outboard > 40 HP EFI Seapro 4 Cyl > 1C453840 & Up - USA > Intake / Exhaust Valves

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Intake / Exhaust Valves

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	893505T05	CYLINDER HEAD ASSY.-4CYL EFI (1 required per assembly)
		893505T05 - Cylinder Head Assembly [ More info ] Unavailable
#-	8M0118175	CYLINDER HEAD SeaPro Only (1 required per assembly)
		9008M0118175 - Cylinder Head [ More info ] Unavailable
		8M0205507 - CYLINDER HEAD [ More info ] Unavailable
#1	8M0065029	VALVE-EXHAUST (4 required per assembly)
		8M0065029 - Exhaust Valve [ More info ] $37.49 Available to Order: Shipping delay up to 10 days.
#2	832990T3	VALVE-INTAKE (4 required per assembly)
		832990T 3 - Intake Valve [ More info ] $21.09 Available to Order: Shipping delay up to 10 days.
#3	858271	SEAL (8 required per assembly)
		26-858271 - Seal [ More info ] $17.89 Available to Order: Shipping delay up to 10 days.
#4	893552	SPRING (8 required per assembly)
		24-893552 - Spring [ More info ] $36.99 Available to Order: Shipping delay up to 10 days.
#5	893553	RETAINER (8 required per assembly)
		893553 - Retainer [ More info ] $3.59 Available to Order: Shipping delay up to 10 days.
#6	893554	KEY (16 required per assembly)
		28-893554 - Key [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
#7	898821A01	ROCKER ARM ASSY (8 required per assembly)
		898821A01 - Rocker Arm Assembly [ More info ] $51.99 Available to Order: Shipping delay up to 10 days.
#8	NSS	NOT SOLD SEPARATE SCREW (8 required per assembly)
		NSS - NOT SOLD SEPARATE [ More info ] Unavailable
#9	NSS	NOT SOLD SEPARATE NUT (8 required per assembly)
#10	8570851	SHAFT-ROCKER (1 required per assembly)
		857085 1 - Shaft - Rocker [ More info ] $168.99 Available to Order: Shipping delay up to 10 days.
#11	NSS	NOT SOLD SEPARATE PLUG (2 required per assembly)
#12	893560	BRACKET (2 required per assembly)
		893560 - Bracket [ More info ] $17.49 Available to Order: Shipping delay up to 10 days.
#13	893561	BRACKET (1 required per assembly)
		893561 - Bracket [ More info ] $19.59 Available to Order: Shipping delay up to 10 days.
#14	893562	SPRING (2 required per assembly)
		24-893562 - Spring [ More info ] $16.59 Available to Order: Shipping delay up to 10 days.
#15	875218	SCREW @5 (5 required per assembly)
		10-875218 - Screw - Priced Individually [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#16	893645	GASKET (1 required per assembly)
		27-893645 - Gasket [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#17	859575	PIN-THRUST (1 required per assembly)
		17-859575 - Pin, Cam Thrust [ More info ] $7.99 Available to Order: Shipping delay up to 10 days.
#18	893563	SPRING OVERLOAD (2 required per assembly)
		24-893563 - Spring, Overload [ More info ] $7.09 Available to Order: Shipping delay up to 10 days.
