Parts for 1075 Sci 9.1L (557 Cu In) V8 MerCruiser Engines - Gas Engine Components (Drive Belt) (0M957032 - 0M960972)
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 842593A01 | GASKET SET - NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing (1 required per assembly) |
  |
|
27-842593A01 - Engine Overhaul Gasket Set [ More info ]
|
| #1 | 842615 | BELT-SERPENTINE [0M957032] THRU [0M960972] (1 required per assembly) |
  |
|
57-842615 - Serpentine Belt [ More info ]
|
| #2 | 52562 | RING-RETAINING (1 required per assembly) |
  |
|
53-52562 - Ring - Retaining [ More info ]
|
| #3 | 899898T61 | PULLEY ASSY-CLEAR (1 required per assembly) |
  |
|
899898T61 - Pulley Assembly - Clear [ More info ]
|
| #4 | 33451 | BEARING BALL (2 required per assembly) |
  |
|
30-33451 - Ball Bearing [ More info ]
|
| #5 | 18917 | RING RETAINING (1 required per assembly) |
  |
|
53-18917 - Ring - Retaining [ More info ]
|
| #6 | 8M0051208 | PIN-IDLER (1 required per assembly) — Replaces: 842873001 |
  |
|
178M0051208 - Idler Pin [ More info ]
|
| #7 | 841339 | SCREW (8 required per assembly) |
  |
|
10-841339 - Screw [ More info ]
|
| #8 | 823029 | SCREW (2 required per assembly) |
  |
|
10-823029 - Screw [ More info ]
|
| #9 | F430732 | SCREW-SS (4 required per assembly) |
  |
|
10-F430732 - Screw -ss [ More info ]
|
| #10 | 843536002 | CLAMP-BLOWERSNOUT (2 required per assembly) |
  |
|
843536002 - Clamp - BlowerSnout [ More info ] Unavailable |
| #11 | 899898T64 | PULLEY-CLEAR (2 required per assembly) |
  |
|
899898T64 - Pulley - Clear [ More info ] Unavailable |
| #12 | 859271T05 | EMBLEM-SMARTCRAFT (1 required per assembly) |
  |
|
37-859271T05 - Emblem-smartcraft [ More info ] Unavailable |
| #13 | 842612 | PLATE (1 required per assembly) |
  |
|
842612 - Plate [ More info ] Unavailable |
| #14 | 861854 | WASHER (1 required per assembly) |
  |
|
12-861854 - Washer, (.453 X .750 X .032) Stainless Steel [ More info ]
|
| #15 | 90042 | SCREW (1 required per assembly) |
  |
|
10-90042 - Screw, NLA [ More info ]
|
| #16 | 4013610 | NUT @3 (1 required per assembly) |
  |
|
11-40136 10 - Nut, (M10) Stainless Steel [ More info ]
|
| #17 | 8M0027716 | WASHER (1 required per assembly) |
  |
|
12-8M0027716 - Washer, (.390 X .600 X .032) Stainless Steel [ More info ]
|
| #18 | 8M0042973 | DECAL-ENG SPECS (1 required per assembly) — Replaces: 841369 |
  |
|
37-8M0042973 - Decal -eng Specs [ More info ] Unavailable |
| #19 | 37828 | WASHER (3 required per assembly) |
  |
|
12-37828 - Washer, (.390 X .625 X .062) Stainless Steel [ More info ]
|
| #20 | 849397 | SCREW (3 required per assembly) |
  |
|
10-849397 - Screw [ More info ]
|
| #21 | 8M0052633 | TENSIONER ASSY [0M957032] THRU [0M960972] (1 required per assembly) — Replaces: 842602A02 |
  |
|
8M0052633 - Tensioner Assembly [ More info ]
|
| #22 | 326481 | WASHER (1 required per assembly) |
  |
|
[ More info ] Unavailable |
| #23 | 4009080 | SCREW (1 required per assembly) |
  |
|
10-40090 80 - Screw [ More info ] Unavailable |
| #24 | 899898T78 | PULLEY ASSY-CLEAR (2 required per assembly) |
  |
|
899898T78 - Pulley Assembly - Clear [ More info ] Unavailable |
| #25 | 33451 | BEARING BALL (4 required per assembly) |
| #26 | 18917 | RING RETAINING (2 required per assembly) |
| #27 | 52562 | RING-RETAINING (2 required per assembly) |
| #28 | 842876 | PIN-IDLER (2 required per assembly) |
  |
|
17-842876 - Idler Pin [ More info ]
|
| #29 | 54457 | J CLIP (1 required per assembly) |
  |
|
54-54457 - J Clip [ More info ]
|
| #30 | 817505 | SCREW (1 required per assembly) |
  |
|
10-817505 - Screw [ More info ]
|
| #31 | 79436 | SCREW @2 (2 required per assembly) |
  |
|
10-79436 - Screw - Priced Individually [ More info ]
|
| #32 | 899898T77 | HOUSING (1 required per assembly) |
  |
|
899898T77 - Housing [ More info ]
|
| #33 | 843863 | O RING (4 required per assembly) |
  |
|
25-843863 - O-ring, (1.612 X .103) [ More info ]
|
| #34 | 48450 | PIN-DOWEL (2 required per assembly) |
  |
|
17-48450 - Pin -Dowel [ More info ]
|
| #35 | 843852001 | BRACKET (1 required per assembly) |
  |
|
843852001 - Bracket [ More info ]
|
| #36 | 8M0027716 | WASHER (2 required per assembly) |
| #37 | 822168 | SCREW (2 required per assembly) |
  |
|
10-822168 - Screw [ More info ]
|
| #38 | 8M0082988 | SENSOR CRANKSHAFT POSITION CRANKSHAFT (1 required per assembly) — Replaces: 8283582, 8M0030022 |
  |
|
8M0082988 - Sensor Assembly [ More info ]
|
| #39 | 4010516 | SCREW @2 (2 required per assembly) |
  |
|
10-40105 16 - Screw [ More info ]
|
| #40 | 8M0011986 | SENSOR ASSY (1 required per assembly) — Replaces: 880609001 |
  |
8M0011986 - Sensor Assembly [ More info ] Unavailable |
|
  |
|
8M0233299 - SENSOR ASSY [ More info ] Unavailable |
| #41 | 817505 | SCREW (1 required per assembly) |
