Parts for 1075 Sci 9.1L (557 Cu In) V8 MerCruiser Engines - Gas Alternator & Sea Water Pump Mounting (Design I)

Revise Search: Sterndrive > MerCruiser Engines - Gas > 9.1L (557 Cu In) V8 > 1075 Sci > 0M905359 - 0M957024 - USA > Alternator & Sea Water Pump Mounting (Design I)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Alternator & Sea Water Pump Mounting (Design I)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	826709121	NUT (1 required per assembly)
		11-826709121 - Nut, (.625-18) Stainless Steel [ More info ] $20.69 Available to Order: Shipping delay up to 10 days.
#2	840030	WASHER (1 required per assembly)
		12-840030 - Washer, (.660 X 1.120 X .135) [ More info ] Unavailable
#3	849377	SCREW (4 required per assembly)
		10-849377 - Screw [ More info ] $15.13 Available to Order: Shipping delay up to 10 days.
#4	8M0042642	WASHER @5 (4 required per assembly) — Replaces: 70132
		12-8M0042642 - Washer - Priced Individually [ More info ] $1.80 6 In Stock.
#5	842588	PULLEY (BLUE) [0M905359] THRU [0M951398] (1 required per assembly)
		842588 - Pulley (Blue) [ More info ] Unavailable
#6	8M0050955	PULLEY (BLUE) [0M953057] THRU [0M957024] (1 required per assembly) — Replaces: 842588001
		8M0050955 - Pulley (Blue) [ More info ] Unavailable
#7	65210	SCREW @3 (1 required per assembly)
		10-65210 - Screw - Priced Individually [ More info ] $2.89 3 In Stock.
#8	856774	WASHER @5 (1 required per assembly)
		12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable
		128M0214963 - WASHER Note: Priced Individually [ More info ] $2.59 10+ In Stock.
#9	841855	BRACKET SEA WATER PUMP MOUNTING (1 required per assembly)
		841855 - Bracket [ More info ] Unavailable
#10	859135	NUT @5 (2 required per assembly)
		11-859135 - Nut (7/16-20), Priced Individually [ More info ] $6.09 2 In Stock.
#11	8M0133358	STUD (2 required per assembly) — Replaces: 579203
		168M0133358 - Stud [ More info ] $17.29 Available to Order: Shipping delay up to 10 days.
#12	842890	BRACKET ALTERNATOR PIVOT (1 required per assembly)
		842890 - Bracket [ More info ] $87.99 $74.52 9 In Stock.
#13	401368	NUT @3 (1 required per assembly) — Replaces: 400265
		11-40136 8 - Nut - Priced Individually [ More info ] $5.29 4 In Stock.
#14	8M0042642	WASHER @5 (1 required per assembly) — Replaces: 70132
#15	842358	BUSHING (1 required per assembly)
		23-842358 - Bushing [ More info ] $33.25 Available to Order: Shipping delay up to 10 days.
#16	842868	BUSHING (1 required per assembly)
		23-842868 - Bushing [ More info ] $102.98 Available to Order: Shipping delay up to 10 days.
#17	824459110	SCREW (1 required per assembly)
		10-824459110 - Screw [ More info ] $15.79 Available to Order: Shipping delay up to 10 days.
#18	863077T02	ALTERNATOR ASSEMBLY BLUE SERVICE COMPLETE (1 required per assembly)
		863077T02 - Alternator (Blue) [ More info ] $898.17 Available to Order: Shipping delay up to 10 days.
#19	401386	NUT @5 (2 required per assembly)
		11-40138 6 - Nut - Priced Individually [ More info ] $5.09 9 In Stock.
#20	846673	WASHER (2 required per assembly)
		12-846673 - Washer, (.265 X .500 X .060) Stainless Steel [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#21	82670912	NUT @5 (1 required per assembly)
		11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ] $6.79 $3.81 10+ In Stock.
#22	856774	WASHER @5 (1 required per assembly)
#23	840007	BRACKET ALTERNATOR TENSIONER (1 required per assembly)
		840007 - Bracket [ More info ] Unavailable
#24	63032	WASHER (1 required per assembly)
		12-63032 - Washer, (.320 X 1.00 X .120) Stainless Steel [ More info ] $0.99 $0.83 10+ In Stock.
#25	40011149	SCREW (1 required per assembly)
		10-40011149 - Screw [ More info ] $2.69 Available to Order: Shipping delay up to 10 days.
#26	843848	PIN-IDLER (1 required per assembly)
		17-843848 - Idler Pin [ More info ] $109.70 Available to Order: Shipping delay up to 10 days.
#27	8M0050958	ORD 899898T62 [0M905359] THRU [0M951398] (1 required per assembly) — Replaces: 843845A01, 843845A02
		8M0050958 - Pulley Assembly -Blue [ More info ] Unavailable
#28	33451	BEARING BALL (1 required per assembly)
		30-33451 - Ball Bearing [ More info ] $63.99 $61.04 6 In Stock.
#29	18917	RING RETAINING (1 required per assembly)
		53-18917 - Ring - Retaining [ More info ] $3.09 Available to Order: Shipping delay up to 10 days.
#30	899898T62	PULLEY ASSY-CLEAR [0M953057] THRU [0M957024] (1 required per assembly) — Replaces: 843845A02, 8M0050958
		899898T62 - Pulley Assembly - Clear [ More info ] Unavailable
#31	33451	BEARING BALL (1 required per assembly)
#32	18917	RING RETAINING (1 required per assembly)
#33	74759	WASHER (1 required per assembly)
		12-74759 - Washer, (.391 X .880 X .125) Stainless Steel [ More info ] $11.09 Available to Order: Shipping delay up to 10 days.
#34	95802	SCREW (1 required per assembly)
		10-95802 - Screw [ More info ] Unavailable
#35	842648Q	BELT (1 required per assembly) — Replaces: 842648
		57-842648Q - Belt [ More info ] $173.52 Available to Order: Shipping delay up to 10 days.
