Parts for 8.2L Mag Ec (H.o. Model) 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Crankshaft / Piston / Connecting Rods
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 8M6001407 | PISTON ASSY-STD (8 required per assembly) — Replaces: 8M0046521 |
  |
|
7008M6001407 - Piston Assembly -STD [ More info ]
|
| #1 | 8M6001408 | PISTON ASSY (8 required per assembly) — Replaces: 8M0046222 |
  |
|
700-8M6001408 - Piston [ More info ]
|
| #1 | 8M6001409 | PISTON ASSY (8 required per assembly) — Replaces: 8M0046223 |
  |
|
7008M6001409 - Piston [ More info ]
|
| #2 | NSS | NOT SOLD SEPARATE PISTON PIN (8 required per assembly) |
  |
|
NSS - NOT SOLD SEPARATE [ More info ] Unavailable |
| #3 | 8M6001037 | PISTON RING SET (8 required per assembly) — Replaces: 8M0046522 |
  |
|
398M6001037 - Piston Rings [ More info ]
|
| #3 | 8M6001026 | PISTON RING SET (8 required per assembly) — Replaces: 8M0046228 |
  |
|
398M6001026 - Piston Ring Set [ More info ]
|
| #3 | 8M6001027 | PISTON RING SET (8 required per assembly) — Replaces: 8M0046229 |
  |
|
398M6001027 - Piston Ring Set [ More info ]
|
| #4 | 8M0070917 | CONNECTING ROD AS (8 required per assembly) — Replaces: 8M0045255 |
  |
|
6008M0070917 - Connecting Rod AS [ More info ]
|
| #5 | 8M6000949 | BOLT (16 required per assembly) — Replaces: 8M0041978 |
  |
|
10-8M6000949 - Bolt - Priced Individually [ More info ]
|
| #6 | 8M0030217 | BEARING SET-STD (8 required per assembly) |
  |
|
23-8M0030217 - Bearing Set - Std [ More info ]
|
| #6 | 8M0030218 | BRG SET-.001 OS (AR required per assembly) |
  |
|
23-8M0030218 - Bearing Set - .001 Os [ More info ]
|
| #6 | 8M0030216 | BRG SET-.001 US (AR required per assembly) |
  |
|
23-8M0030216 - Bearing Set - .001 Us [ More info ]
|
| #6 | 8M0030982 | BRG SET -.010 (AR required per assembly) |
  |
|
238M0030982 - Bearing Set-.010 , Priced Individually [ More info ]
|
| #7 | 8M0051198 | BEARING KIT-STD (1 required per assembly) — Replaces: 842400 |
  |
|
23-8M0051198 - Bearing Kit-STD [ More info ]
|
| #7 | 8M0053743 | BRG KIT-.001 OS (AR required per assembly) — Replaces: 842401 |
  |
|
23-8M0053743 - Bearing Kit-.001 OS [ More info ]
|
| #7 | 842402 | BRG KIT-.001 US (AR required per assembly) |
  |
|
23-842402 - Bearing Set - Main - .001 Undersize [ More info ]
|
| #7 | 8M0053549 | BRG KIT-.010 US (AR required per assembly) — Replaces: 842403 |
  |
|
23-8M0053549 - Bearing Kit-.010 US [ More info ]
|
| #8 | 845607 | KEY CRANKSHAFT (1 required per assembly) |
  |
|
|
| #9 | 8M0070214 | CRANKSHAFT ASSY (1 required per assembly) — Replaces: 8M0045288, 8M0056828 |
  |
|
4008M0070214 - CrankShaft Assembly [ More info ]
|
| #10 | NSS | NOT SOLD SEPARATE PIN, DOWEL (1 required per assembly) |
| #11 | 69756 | O-RING (.549 X .103) NUMBER 5 BEARING CAP OIL HOLE (1 required per assembly) |
  |
|
25-69756 - O-ring, (.549 X .103) [ More info ]
|
| #12 | 811554 | SEAL OIL (1 required per assembly) |
  |
|
26-811554 - Seal [ More info ]
|
| #13 | 845757 | SCREW (6 required per assembly) |
  |
|
10-845757 - Screw [ More info ]
|
  |
|
10-8M0214958 - Flywheel MOUNTING SCREW ZZ [ More info ]
|
| #14 | 843374T1 | FLYWHEEL MCM (1 required per assembly) |
  |
|
230-843374T 1 - Flywheel [ More info ]
|
| #14 | 8M0154582 | FLYWHEEL MIE (1 required per assembly) — Replaces: 811560, 8M0084512 |
  |
|
200-8M0154582 - 200-8M0154582 - FLYWHEEL [ More info ] Unavailable Replaced by -8M0157639 |
  |
|
200-8M0157639 - FLYWHEEL [ More info ] Unavailable |
