Parts for 8.2L Mag Ec (H.o. Model) 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Remote Oil System

Revise Search: Sterndrive > MerCruiser Engines - Gas > 8.2L (502 Cu In) V8 GM > 8.2L Mag Ec (H.o. Model) > 2A041665 - 2A051740 > Remote Oil System

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Remote Oil System

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	862958A1	FITTING KIT (1 required per assembly)
		22-862958A 1 - Fitting Kit [ More info ] $42.99 Available to Order: Shipping delay up to 10 days.
#1	866340Q03	FILTER-OIL @6 (1 required per assembly)
		35-866340Q03 - Oil Filter - Priced Individually [ More info ] $14.19 3 In Stock.
		18-7876-1 - Oil Filter - GM/Chevy Long [ More info ] $10.99 $10.62 10+ In Stock.
		35-866340K01 - Oil Filter [ More info ] $15.69 7 In Stock.
		35-57811 - Oil Filter, Long [ More info ] $11.99 $9.17 Available to Order: Shipping delay up to 10 days.
		35-57801 - Oil Filter, Standard Length Canister [ More info ] $10.69 $8.88 10+ In Stock.
#1	866340K01	FILTER-OIL (1 required per assembly)
		18-7824-2 - Oil Filter, Short [ More info ] $9.99 $8.89 10+ In Stock.
#2	8M0070128	HOUSING-REMOTE OL (1 required per assembly)
		8M0070128 - Housing-Remote OL [ More info ] $129.99 Available to Order: Shipping delay up to 10 days.
#3	8M2021626	OIL LINE COOLER TO FILTER MCM/Inline/V-Drive ETB (1 required per assembly)
		328M2021626 - Oil Line [ More info ] $118.49 Available to Order: Shipping delay up to 10 days.
#3	8M2022420	OIL LINE COOLER TO FILTER V-Drive (1 required per assembly)
		328M2022420 - Oil Line [ More info ] $164.49 Available to Order: Shipping delay up to 10 days.
#4	4010716	SCREW (1 required per assembly)
		10-40107 16 - Screw [ More info ] $4.49 1 In Stock.
#5	4010820	SCREW @5 (4 required per assembly)
		10-40108 20 - Screw - Priced Individually [ More info ] $4.79 2 In Stock.
#6	8M0069716	BRACKET REMOTE OIL MCM/Inline/V-Drive ETB (1 required per assembly)
		8M0069716 - Bracket [ More info ] $42.99 Available to Order: Shipping delay up to 10 days.
#6	8M2021921	BRACKET REMOTE OIL V-Drive (1 required per assembly)
		8M2021921 - Bracket OIL REMOT [ More info ] $32.29 Available to Order: Shipping delay up to 10 days.
#7	8M2021679	OIL LINE BLOCK TO COOLER (1 required per assembly)
		328M2021679 - Oil Line [ More info ] $75.49 Available to Order: Shipping delay up to 10 days.
#8	8M2021625	OIL LINE FILTER TO BLOCK MCM/Inline/V-Drive ETB (1 required per assembly)
		328M2021625 - Oil Line [ More info ] $119.99 Available to Order: Shipping delay up to 10 days.
#8	8M2022419	OIL LINE FILTER TO BLOCK V-Drive (1 required per assembly)
		328M2022419 - Oil Line [ More info ] $119.49 Available to Order: Shipping delay up to 10 days.
#9	8M0070911	BRACKET OIL LINE (1 required per assembly)
		8M0070911 - Bracket [ More info ] $41.99 Available to Order: Shipping delay up to 10 days.
#10	8M2009216	CLAMP (2 required per assembly)
		8M2009216 - Clamp [ More info ] $7.59 Available to Order: Shipping delay up to 10 days.
#11	8M2009217	PLATE (1 required per assembly)
		8M2009217 - Plate [ More info ] $18.49 Available to Order: Shipping delay up to 10 days.
#12	82130040	SCREW MCM (1 required per assembly)
		10-821300 40 - Screw [ More info ] $7.89 $4.43 10+ In Stock.
#12	82130045	SCREW MIE (1 required per assembly)
		10-821300 45 - Screw [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#13	806677	BOLT @5 (2 required per assembly)
		10-806677 - Bolt - Priced Individually [ More info ] Unavailable
#14	8M0204665	WASHER @10 (2 required per assembly) — Replaces: 54012
		12-8M0204665 - WASHER Note: Priced Individually [ More info ] $3.59 10+ In Stock.
#15	8M2018755	BRACKET (1 required per assembly)
		8M2018755 - Bracket [ More info ] $41.49 Available to Order: Shipping delay up to 10 days.
#16	8M0070248	COOLER-OIL (1 required per assembly)
		8M0070248 - Oil Cooler [ More info ] $757.99 In Stock
#17	401376	NUT (1 required per assembly)
		11-40137 6 - Nut [ More info ] $3.29 Available to Order: Shipping delay up to 10 days.
#18	35044	WASHER MCM (1 required per assembly)
		12-35044 - Washer, (.281 X .625 X .065) Stainless Steel [ More info ] $2.49 10+ In Stock.
#18	828442	WASHER MIE (1 required per assembly)
		12828442 - Washer [ More info ] $4.89 Available to Order: Shipping delay up to 10 days.
#19	807445T	CLAMP (1 required per assembly)
		807445T - Clamp [ More info ] $22.36 1 In Stock.
#20	98253	SCREW @2 (2 required per assembly)
		10-98253 - Screw [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#21	863905T	BRACKET (1 required per assembly)
		863905T - Bracket [ More info ] $38.49 Available to Order: Shipping delay up to 10 days.
#22	92850	J CLIP (1 required per assembly)
		54-92850 - J Clip [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#23	4010610	SCREW (2 required per assembly)
		10-40106 10 - Screw [ More info ] $2.39 Available to Order: Shipping delay up to 10 days.
#24	862870T	ADAPTOR-OIL FLTR (1 required per assembly)
		862870T - Adaptor - Oil Filter [ More info ] $80.99 Available to Order: Shipping delay up to 10 days.
#25	42077	SEAL (1 required per assembly)
		26-42077 - Seal [ More info ] $12.49 4 In Stock.
#26	862958	FITTING (1 required per assembly)
		22-862958 - Fitting [ More info ] $49.49 Available to Order: Shipping delay up to 10 days.
#27	862957	SEAL (1 required per assembly)
		26-862957 - Seal [ More info ] $2.99 Available to Order: Shipping delay up to 10 days.
#28	8M2000565	O-RING COMPONENT OF ITEM 3 AND 8 (2 required per assembly)
		8M2000565 - O-Ring [ More info ] $0.90 Available to Order: Shipping delay up to 10 days.
