Parts for 8.2L Mag Ec (H.o. Model) 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Electrical Components

Revise Search: Sterndrive > MerCruiser Engines - Gas > 8.2L (502 Cu In) V8 GM > 8.2L Mag Ec (H.o. Model) > 2A041665 - 2A051740 > Electrical Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Electrical Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0070921	ECM Base, Manual [2A184339] & Below (1 required per assembly)
		8M0070921 - ECM Engine Control Modu [ More info ] Unavailable
#1	8M0085642	ECM Base, Manual [2A184340] THRU [2A446466] (1 required per assembly)
		8M0085642 - ECM [ More info ] Unavailable
#1	8M0175730	PCM-8.2L BASE BRV Base, Manual (1 required per assembly) — Replaces: 8M0099882, 8M0167173
		77-8M0175730 - PCM-8.2L BASE BRV [ More info ] Unavailable
#1	8M0070922	ECM High Output, Manual [2A446466] & Below (1 required per assembly)
		8M0070922 - ECM Engine Control Modu [ More info ] Unavailable
#1	8M0175731	PCM-8.2L HO BRAVO High Output, Manual (1 required per assembly) — Replaces: 8M0099883, 8M0167174
		77-8M0175731 - PCM-8.2L HO BRAVO [ More info ] Unavailable
#1	8M0070925	ECM Base, Digital Throttle & Shift [2A184339] & Below (1 required per assembly)
		8M0070925 - ECM Engine Control Modu [ More info ] Unavailable
#1	8M0085641	ECM Base, Digital Throttle & Shift [2A184340] THRU [2A446466] (1 required per assembly)
		8M0085641 - ECM [ More info ] Unavailable
#1	8M0167175	PCM-8.2 BRAVO DTS Base, Digital Throttle & Shift [2A446467] THRU [2A684209] (1 required per assembly) — Replaces: 8M0099884
		778M0167175 - PCM-8.2 BRAVO DTS [ More info ] $2,463.99 Available to Order: Shipping delay up to 10 days.
#1	8M0175732	PCM-8.2 BRAVO DTS See 2020-06 TSP Bulletin [2A684210] & Up (1 required per assembly)
		77-8M0175732 - PCM-8.2 BRAVO DTS [ More info ] Unavailable
#1	8M0070926	ECM High Output, Digital Throttle & Shift [2A446466] & Below (1 required per assembly)
		8M0070926 - ECM Engine Control Modu [ More info ] Unavailable
#1	8M0167176	PCM-8.2 HO BRAVO High Output, Digital Throttle & Shift [2A446467] THRU [2A684209] (1 required per assembly) — Replaces: 8M0099885
		778M0167176 - PCM-8.2 HO BRAVO [ More info ] $7,855.99 Available to Order: Shipping delay up to 10 days.
#1	8M0175733	PCM-8.2 HO BRAVO See 2020-06 TSP Bulletin [2A684210] & Up (1 required per assembly)
		77-8M0175733 - PCM-8.2 HO BRAVO [ More info ] Unavailable
#2	858951	J CLIP (1 required per assembly)
		54-858951 - J Clip [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
#3	856954	BUSHING (3 required per assembly)
		23-856954 - Bushing [ More info ] $6.99 Available to Order: Shipping delay up to 10 days.
#4	834985	GROMMET @5 (3 required per assembly)
		25-834985 - Grommet [ More info ] $3.00 2 In Stock.
		25-8M0190980 - GROMMET Note: Must be ordered in multiples of 5 [ More info ] $3.89 Available to Order: Shipping delay up to 10 days.
#5	82130025	SCREW @5 (3 required per assembly)
		10-821300 25 - Screw [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#6	841203T	COIL-IGNITION (2 required per assembly)
		841203T - Ignition Coil [ More info ] $363.49 Available to Order: Shipping delay up to 10 days.
#7	8M0053613	RETAINER (1 required per assembly) — Replaces: 844367
		8M0053613 - Retainer [ More info ] $44.28 Available to Order: Shipping delay up to 10 days.
#8	4010630	SCREW (6 required per assembly)
		10-40106 30 - Screw [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#9	88552560	SCREW (2 required per assembly)
		10-885525 60 - Screw [ More info ] $8.89 Available to Order: Shipping delay up to 10 days.
#10	8M0148668	SENSOR ASSEMBLY EXHAUST (1 required per assembly) — Replaces: 885342002
		8M0148668 - Temperature Sensor [ More info ] $48.39 1 In Stock.
#11	896699	O-RING (1.78 MM X .08 MM) (1 required per assembly)
		25-896699 - O-ring, (1.78 Mm X .08 Mm) [ More info ] $12.49 Available to Order: Shipping delay up to 10 days.
#12	8M2003959	SENSOR-O2 [2A684209] & Below (4 required per assembly)
		8M2003959 - Oxygen Sensor [ More info ] $133.99 $128.99 In Stock
#12	8M0175736	SENSOR-02 See 2020-06 TSP Bulletin [2A684210] & Up (4 required per assembly)
		8M0175736 - SENSOR-02 [ More info ] $91.49 Available to Order: Shipping delay up to 10 days.
#13	899329A09	CABLE SET-HT (1 required per assembly)
		84-899329A09 - Spark Plug Wire Set [ More info ] $124.49 $122.74 In Stock
#14	8M0114747	SP BPR6ES @4 (8 required per assembly) — Replaces: 810883
		338M0114747 - Plug BPR6ES - Priced Individually [ More info ] $8.89 Available to Order: Shipping delay up to 10 days.
#15	8M0045733	BRACKET ELECTRICAL (1 required per assembly)
		8M0045733 - Bracket [ More info ] $236.99 Available to Order: Shipping delay up to 10 days.
#16	889664	NUT (1 required per assembly)
		11-889664 - Nut, (1.500-18) Black Nylon [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
#17	8M2017792	STUD-HOT (1 required per assembly)
		8M2017792 - Stud-HOT [ More info ] $25.89 Available to Order: Shipping delay up to 10 days.
#18	8M2021953	INSULATOR HOT STUD (1 required per assembly)
		858M2021953 - Insulator [ More info ] $10.69 Available to Order: Shipping delay up to 10 days.
#19	8M0045793	HARNESS HOT STUD (1 required per assembly)
		84-8M0045793 - Harness Assembly [ More info ] Unavailable
		84-8M0223887 - HARNESS ASSY [ More info ] Unavailable
#20	82130025	SCREW @5 (2 required per assembly)
#21	56295	STUD (.437 X 2.69) ELECTRICAL BRACKET TO CYLINDER HEAD (1 required per assembly)
		16-56295 - Stud - Priced Individually [ More info ] $12.39 9 In Stock.
#22	8M0034453	STUD (7/16 X 2.19) ELECTRICAL BRACKET TO CYLINDER HEAD (1 required per assembly)
		16-8M0034453 - Stud [ More info ] $19.59 Available to Order: Shipping delay up to 10 days.
#23	45176	WASHER @5 (2 required per assembly)
		12-45176 - Washer, (.453 X .812 X .105) [ More info ] $1.50 6 In Stock.
#24	859135	NUT @5 (2 required per assembly)
		11-859135 - Nut (7/16-20), Priced Individually [ More info ] $6.09 2 In Stock.
#25	42600A09	MERCATHODE KIT (1 required per assembly)
		42600A09 - Mercathode Kit [ More info ] $164.99 $162.58 Available to Order: Shipping delay up to 10 days.
#26	68219	NUT (#10-32) STAINLESS STEEL (4 required per assembly)
		11-68219 - Nut (#10-32) [ More info ] $2.99 10+ In Stock.
#27	62568	SCREW (#10-16 X .375) (1 required per assembly)
		10-62568 - Screw - Priced Individually [ More info ] $1.10 $0.88 10+ In Stock.
#28	4010516	SCREW @2 (1 required per assembly)
		10-40105 16 - Screw [ More info ] $1.80 Available to Order: Shipping delay up to 10 days.
#29	862646	FUSE 5 AMP @5 (1 required per assembly)
		862646 - Fuse, Tan, 5 Amp [ More info ] $4.09 Available to Order: Shipping delay up to 10 days.
#30	95084A9	CABLE ASSY (1 required per assembly)
		84-95084A 9 - Cable Assembly [ More info ] $30.49 Available to Order: Shipping delay up to 10 days.
#30	95084A10	CABLE ASSY (1 required per assembly)
		84-95084A10 - Cable Assembly [ More info ] Unavailable
		84-8M0207788 - CABLE ASSY [ More info ] Unavailable
#31	54676	RETAINER (4 required per assembly)
		54676 - Retainer [ More info ] $5.19 Available to Order: Shipping delay up to 10 days.
#32	899145	CLIP (4 required per assembly)
		54-899145 - Clip [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#33	65567	WASHER @2 (3 required per assembly)
		12-65567 - Washer, (.265 X .750 X .048) Stainless Steel [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
