Parts for 8.2L Mag Ec (H.o. Model) 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Cooling System Fresh Water Components

Revise Search: Sterndrive > MerCruiser Engines - Gas > 8.2L (502 Cu In) V8 GM > 8.2L Mag Ec (H.o. Model) > 2A041665 - 2A051740 > Cooling System Fresh Water Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Cooling System Fresh Water Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0070210	RESERVOIR (1 required per assembly)
		8M0070210 - Reservoir [ More info ] $351.49 Available to Order: Shipping delay up to 10 days.
#2	862863	CAP COOLANT RESERVOIR (1 required per assembly)
		862863 - Reservoir Cap [ More info ] $20.19 Available to Order: Shipping delay up to 10 days.
#3	8M0070890	COVER COOLANT RESERVOIR (1 required per assembly)
		8M0070890 - Coolant Cover [ More info ] $26.69 Available to Order: Shipping delay up to 10 days.
#4	8M0034675	DECAL BASE Sterndrive [2A184339] & Below (1 required per assembly)
		378M0034675 - Decal 8.2MAG SPEC [ More info ] $43.49 Available to Order: Shipping delay up to 10 days.
#4	8M0029391	DECAL BASE Sterndrive [2A184340] & Up (1 required per assembly)
		378M0029391 - Decal [ More info ] $16.49 Available to Order: Shipping delay up to 10 days.
#4	8M0034676	DECAL HIGH OUTPUT Sterndrive (1 required per assembly)
		378M0034676 - Decal 8.2 SPC [ More info ] $49.49 Available to Order: Shipping delay up to 10 days.
#4	8M0034678	DECAL BASE Inboard (1 required per assembly)
		378M0034678 - Decal 8.2 SPEC [ More info ] $100.99 Available to Order: Shipping delay up to 10 days.
#4	8M0034677	DECAL HIGH OUTPUT Inboard (1 required per assembly)
		378M0034677 - Decal 8.2 SPEC [ More info ] $51.99 Available to Order: Shipping delay up to 10 days.
#5	8M0070211	BRACKET RESERVOIR (1 required per assembly)
		8M0070211 - Bracket [ More info ] $85.99 Available to Order: Shipping delay up to 10 days.
#6	27025	WASHER @5 (2 required per assembly)
		12-27025 - Washer - Priced Individually [ More info ] $2.39 10+ In Stock.
#7	47462	SCREW @5 (2 required per assembly)
		10-47462 - Screw - Priced Individually [ More info ] $1.80 $1.44 10+ In Stock.
#8	8M2022695	SPACER (2 required per assembly)
		238M2022695 - Spacer [ More info ] $14.89 Available to Order: Shipping delay up to 10 days.
#9	4010620	SCREW (2 required per assembly)
		10-40106 20 - Screw [ More info ] Unavailable
#10	815504212	CLAMP (2 required per assembly)
		54-815504212 - Clamp [ More info ] Unavailable
#11	8M2017665	HOSE RESERVOIR TO CIRCULATING PUMP (1 required per assembly)
		32-8M2017665 - Hose - Reservoir To Circulating Pump [ More info ] $15.99 Available to Order: Shipping delay up to 10 days.
#12	629101	ELBOW (1 required per assembly)
		22-62910 1 - Elbow [ More info ] $13.39 Available to Order: Shipping delay up to 10 days.
#13	8M0095815	HEAT EXCHANGER [2A051742] & Up (1 required per assembly) — Replaces: 8M0045230
		8M0095815 - Heat Exchanger [ More info ] $2,185.99 Available to Order: Shipping delay up to 10 days.
#14	891716	GASKET (1 required per assembly)
		27-891716 - Heat Exchanger Gasket, priced individually [ More info ] $19.19 2 In Stock.
#15	8M0039163	O-RING (3/8 X 1/8) (1 required per assembly)
		25-8M0039163 - O-ring, (3/8 X 1/8) [ More info ] $8.79 Available to Order: Shipping delay up to 10 days.
#16	891717	COVER (1 required per assembly)
		891717 - Cover [ More info ] $101.99 Available to Order: Shipping delay up to 10 days.
#17	98261	SCREW (.375-16 X .750) (1 required per assembly)
		10-98261 - Screw [ More info ] $1.20 5 In Stock.
#18	8M2021340	HOSE COOLANT BLEED (1 required per assembly)
		328M2021340 - Hose - Return [ More info ] $15.49 Available to Order: Shipping delay up to 10 days.
#19	815504206	CLAMP (2 required per assembly)
		54-815504206 - Clamp [ More info ] $6.79 Available to Order: Shipping delay up to 10 days.
#20	8M2020585	BRACKET FLUSH MOUNT MIE V-Drive (1 required per assembly)
		8M2020585 - Bracket [ More info ] $34.99 Available to Order: Shipping delay up to 10 days.
#21	4010720	SCREW (M8 X 20) FLUSH MOUNT MIE V-Drive (1 required per assembly)
		10-40107 20 - Screw [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#22	4010612	SCREW (1 required per assembly)
		10-40106 12 - Screw [ More info ] $9.29 Available to Order: Shipping delay up to 10 days.
#23	8M2017891	DECAL-ENGINE COOL (1 required per assembly)
		37-8M2017891 - Decal-Engine COOL [ More info ] $2.59 Available to Order: Shipping delay up to 10 days.
#24	8M0042965	DECAL CARB 4-STAR (1 required per assembly)
		378M0042965 - Decal [ More info ] $3.39 Available to Order: Shipping delay up to 10 days.
#25	8M0071123	DECAL WATER DRAIN AND EMISSION (1 required per assembly)
		378M0071123 - Decal [ More info ] $7.79 Available to Order: Shipping delay up to 10 days.
