Parts for 600 Sci 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Fuel Lines & Fuel Components

Revise Search: Sterndrive > MerCruiser Engines - Gas > 8.2L (502 Cu In) V8 GM > 600 Sci > 0M952908 - 0M962885 - USA > Fuel Lines & Fuel Components

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Fuel Lines & Fuel Components

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	843073A05	GASKET/SEAL SET - NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing (1 required per assembly)
		27-843073A05 - Engine Overhaul Gasket Set [ More info ] $1,506.15 Available to Order: Shipping delay up to 10 days.
#-	844200A08	PARTIAL-600 SCI (1 required per assembly)
		844200A08 - Partial Engine Assembly [ More info ] Unavailable
#1	842468A04	REGULATOR ASSY SERVICE COMPLETE [0M952908] THRU [0M955080] (1 required per assembly) — Replaces: 842468A02
		842468A04 - Regulator Assembly [ More info ] $1,496.72 Available to Order: Shipping delay up to 10 days.
#1	842468A05	REGULATOR ASSEMBLY FUEL PRESSURE SERVICE COMPLETE [0M955081] & Up (1 required per assembly) — Replaces: 842468A03
		842468A05 - Regulator Assembly [ More info ] Unavailable
		8M0192213 - REGULATOR ASSY [ More info ] Unavailable
#2	67902	CONNECTOR (1 required per assembly)
		22-67902 - Fitting [ More info ] $12.39 Available to Order: Shipping delay up to 10 days.
#3	19697	ELBOW (1 required per assembly)
		22-19697 - Elbow [ More info ] $24.19 Available to Order: Shipping delay up to 10 days.
#4	842962	FITTING STRAIGHT (2 required per assembly)
		22-842962 - Fitting [ More info ] $8.37 Available to Order: Shipping delay up to 10 days.
#5	849526	FITTING 90 DEGREE (1 required per assembly)
		22-849526 - Fitting [ More info ] $17.16 Available to Order: Shipping delay up to 10 days.
#6	816133	FITTING (1 required per assembly)
		22-816133 - Fitting [ More info ] $13.19 Available to Order: Shipping delay up to 10 days.
#7	390721	PLUG PIPE (.125-27) BRASS (1 required per assembly)
		22-39072 1 - Plug - Priced Individually [ More info ] $9.29 1 In Stock.
#8	843063	SCREW (2 required per assembly)
		10-843063 - Screw [ More info ] $2.96 Available to Order: Shipping delay up to 10 days.
#9	8M0042642	WASHER @5 (2 required per assembly) — Replaces: 70132
		12-8M0042642 - Washer - Priced Individually [ More info ] $1.80 6 In Stock.
#10	56762	TIE STRAP @5 (3 required per assembly)
		56762 - Tie Strap - Priced Individually [ More info ] $0.50 3 In Stock.
#11	8M8023638	TUBING PLASTIC (54 INCHES) CUT 48.00 INCHES (1 required per assembly) — Replaces: 84862872
		32-8M8023638 - Tubing - 54 Inch [ More info ] $135.57 Available to Order: Shipping delay up to 10 days.
#12	8M0063567	HOSE 58.00 INCH BULK CUT 18.00 INCHES (1 required per assembly) — Replaces: 80617382
		32-8M0063567 - Hose -58 Inch [ More info ] $37.99 Available to Order: Shipping delay up to 10 days.
#13	8M0178559	DAMPER ASSY (2 required per assembly) — Replaces: 841062T01
		8M0178559 - DAMPER ASSY [ More info ] Unavailable
#14	845177	FITTING (2 required per assembly)
		22-845177 - Fitting [ More info ] $32.78 Available to Order: Shipping delay up to 10 days.
#15	842464	RAIL-FUEL-STBD [0M952908] THRU [0M955080] (1 required per assembly)
		842464 - Fuel Rail - Stbd [ More info ] $320.96 Available to Order: Shipping delay up to 10 days.
#15	8M0001411	RAIL-FUEL-STBD [0M955081] & Up (1 required per assembly)
		8M0001411 - Fuel Rail - Stbd [ More info ] Unavailable
#16	8M0053623	RAIL-FUEL-PORT [0M952908] THRU [0M955080] (1 required per assembly) — Replaces: 842462
		8M0053623 - Fuel Rail- Port [ More info ] $326.21 Available to Order: Shipping delay up to 10 days.
#16	8M0001410	RAIL-FUEL-PORT [0M955081] & Up (1 required per assembly)
		8M0001410 - Fuel Rail - Port [ More info ] Unavailable
#17	849922	O RING @4 (4 required per assembly)
		25-849922 - O-ring, Special, Fuel Line Rail To Rail, Sold Individually [ More info ] $9.24 Available to Order: Shipping delay up to 10 days.
#18	93385	FITTING (90 DEGREE) TO INTAKE MANIFOLD (2 required per assembly)
		22-93385 - Fitting [ More info ] $13.19 Available to Order: Shipping delay up to 10 days.
#19	842465	LINE ASSEMBLY FUEL FUEL RAILS TO FITTINGS IN INTAKE MANIFOLD (2 required per assembly)
		32-842465 - Fuel Line Assembly [ More info ] $71.86 Available to Order: Shipping delay up to 10 days.
#20	842915T01	INJECTOR ASY-FUEL (8 required per assembly) — Replaces: 842915A01
		842915T01 - Fuel Injector Assembly [ More info ] Unavailable
		8M0222277 - FUEL INJECTOR [ More info ] Unavailable
#21	851889	O-RING (16 required per assembly)
		25-851889 - O-Ring [ More info ] $14.49 Available to Order: Shipping delay up to 10 days.
#22	823138	SCREW (6 required per assembly)
		10-823138 - Screw [ More info ] $2.67 Available to Order: Shipping delay up to 10 days.
#23	842961	FITTING (2 required per assembly)
		22-842961 - Fitting [ More info ] $13.05 Available to Order: Shipping delay up to 10 days.
#24	842255	LINE ASSEMBLY FUEL PORT FUEL RAIL TO FUEL REGULATOR (1 required per assembly)
		32-842255 - Fuel Line Assembly [ More info ] $43.38 Available to Order: Shipping delay up to 10 days.
#25	842256	LINE ASSEMBLY FUEL STARBOARD FUEL RAIL TO FUEL REGULATOR (1 required per assembly)
		32-842256 - Fuel Line Assembly [ More info ] $37.59 Available to Order: Shipping delay up to 10 days.
#26	843022	CLIP DUAL FUEL LINE SUPPORT (1 required per assembly)
		54-843022 - Clip [ More info ] $2.77 Available to Order: Shipping delay up to 10 days.
#27	842489	LINE ASSEMBLY FUEL FUEL PUMP TO FUEL REGULATOR (1 required per assembly)
		32-842489 - Fuel Line Assembly [ More info ] $35.24 Available to Order: Shipping delay up to 10 days.
#28	43276	ELBOW (1 required per assembly)
		22-43276 - Elbow [ More info ] $19.69 Available to Order: Shipping delay up to 10 days.
#29	889275T	PUMP ASSY-FUEL (1 required per assembly)
		889275T - Fuel Pump [ More info ] $235.87 Available to Order: Shipping delay up to 10 days.
#30	36382	PLUG - Shipping Protector (1 required per assembly)
		22-36382 - Plug [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
		18-8111-9 - Pipe Plug, 1/4 Inch, (Pack of 3) [ More info ] $12.29 Available to Order: Shipping delay up to 10 days.
		18-4256 - Plug, 1/4 Inch Brass, Sold Individually [ More info ] $2.46 2 In Stock.
#30	70146	CONNECTOR - Fuel Pump Inlet Hose (1 required per assembly)
		22-70146 - Connector [ More info ] $8.29 Available to Order: Shipping delay up to 10 days.
#31	802893T	FILTER-FUEL (1 required per assembly)
		35-802893T - Fuel Filter [ More info ] $18.09 7 In Stock.
		18-7945 - Filter, Long Version [ More info ] $8.99 $8.86 Available to Order: Shipping delay up to 10 days.
		18-7944 - Filter, 35-802893Q [ More info ] $8.99 $8.86 10+ In Stock.
		35-802893Q01 - Fuel Filter - Priced Individually [ More info ] $19.79 9 In Stock.
#32	897345T58	LINE ASSEMBLY FUEL FUEL REGULATOR TO FUEL COOLER (1 required per assembly) — Replaces: 842253
		32-897345T58 - Fuel Line [ More info ] $210.90 Available to Order: Shipping delay up to 10 days.
#33	34354	SCREW @5 (2 required per assembly)
		10-34354 - Screw - Priced Individually [ More info ] $2.39 10+ In Stock.
#34	34931	WASHER (2 required per assembly)
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#35	842490	LINE ASSEMBLY FUEL FUEL FILTER TO INTAKE MANIFOLD (1 required per assembly)
		32-842490 - Fuel Line Assembly [ More info ] $36.99 Available to Order: Shipping delay up to 10 days.
#36	848355T01	FILTER ASSY-FUEL (1 required per assembly) — Replaces: 848355A01
		35-848355T01 - Fuel Filter Assembly [ More info ] $407.09 Available to Order: Shipping delay up to 10 days.
#37	8M0050920	END CAP (1 required per assembly) — Replaces: 842495
		8M0050920 - End Cap [ More info ] $227.16 Available to Order: Shipping delay up to 10 days.
#38	812708	SPRING (1 required per assembly)
		24-812708 - Spring [ More info ] $5.39 1 In Stock.
#39	842636	O-RING (1.739 X .070) (1 required per assembly)
		25-842636 - O-ring, (1.739 X .070) [ More info ] $14.33 Available to Order: Shipping delay up to 10 days.
#40	8M0050994	FILTER-FUEL (1 required per assembly) — Replaces: 848355
		35-8M0050994 - Fuel Filter [ More info ] $49.86 1 In Stock.
#41	8M0186076	ELBOW (1 required per assembly) — Replaces: 706811
		22-8M0186076 - ELBOW [ More info ] Unavailable
#42	18904	CLIP FUEL FILTER SUPPORT (1 required per assembly)
		54-18904 - Clip [ More info ] $25.75 Available to Order: Shipping delay up to 10 days.
#43	817505	SCREW (1 required per assembly)
		10-817505 - Screw [ More info ] $2.89 Available to Order: Shipping delay up to 10 days.
