Parts for 35 HP EFI Jet 4 Cyl 4-Stroke Mercury Outboard Motor Tiller Handle Rear Bracket Assembly (Mid Mount)

Revise Search: Outboard > 4-Stroke Mercury Outboard > 35 HP EFI Jet 4 Cyl > 1C453840 & Up - USA > Tiller Handle Rear Bracket Assembly (Mid Mount)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Tiller Handle Rear Bracket Assembly (Mid Mount)

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	8M0161096	BRACKET-TILT LOCK (1 required per assembly)
		8M0161096 - BRACKET-TILT LOCK [ More info ] Unavailable
#2	8M0161104	SCREW M4X0.7X12, SOC FLAT HD (2 required per assembly)
		10-8M0161104 - SCREW [ More info ] Unavailable
#3	8M0161103	LEVER TILT (2 required per assembly)
		8M0161103 - LEVER-TILT LOCK [ More info ] Unavailable
#4	8M0161099	BUSHING BEARING (2 required per assembly)
		23-8M0161099 - BUSHING [ More info ] Unavailable
#5	8M0161683	DENT CAM TILT (1 required per assembly)
		8M0161683 - DETENT-TILT LOCK [ More info ] Unavailable
#6	8M0161684	LOCKING TAB (1 required per assembly)
		8M0161684 - LOCKING TAB [ More info ] Unavailable
#7	8M0161687	GROOVED PIN (1 required per assembly)
		17-8M0161687 - PIN [ More info ] Unavailable
#8	8M0161686	TILT SHAFT (1 required per assembly)
		8M0161686 - SHAFT-TILT LOCK [ More info ] Unavailable
#9	8M0161685	SPRING COMPRESSION (1 required per assembly)
		24-8M0161685 - SPRING-TILT LOCK [ More info ] Unavailable
#10	826292	NUT (1 required per assembly)
		11-826292 - Nut (M10) [ More info ] $4.19 $3.36 10+ In Stock.
#11	8M0136052	SCREW (1 required per assembly)
		108M0136052 - Screw [ More info ] Unavailable
		10-8M0157385 - SCREW [ More info ] Unavailable
#12	8M0136057	CAP NUT (1 required per assembly)
		118M0136057 - CAP NUT [ More info ] Unavailable
#13	40140	NUT @2 (1 required per assembly)
		11-40140 - Nut, (M10) [ More info ] $3.39 7 In Stock.
#14	4002319	WASHER @3 (2 required per assembly)
		12-40023 19 - Washer (M10) [ More info ] $3.19 7 In Stock.
#15	8M0161098	CLAMP-TOE (1 required per assembly)
		8M0161098 - 8M0161098 - CLAMP-TOE [ More info ] Unavailable Replaced by -8M0224370
		8M0224370 - TOE CLAMP [ More info ] Unavailable
#16	43044	PIN-DOWEL-SOLID (1 required per assembly)
		17-43044 - Pin -Dowel-solid [ More info ] $2.49 Available to Order: Shipping delay up to 10 days.
#17	8M0161097	BRACKET-LOWER (1 required per assembly)
		8M0161097 - 8M0161097 - BRACKET-LOWER [ More info ] Unavailable Replaced by -8M0224367
		8M0224367 - LOWER BRACKET [ More info ] Unavailable
#18	8M0136054	BOLT (1 required per assembly)
		108M0136054 - Bolt [ More info ] $10.99 Available to Order: Shipping delay up to 10 days.
#19	8M0136060	ERING (1 required per assembly)
		8M0136060 - ERING [ More info ] $7.89 Available to Order: Shipping delay up to 10 days.
#20	12024	WASHER (1 required per assembly)
		12-12024 - Washer, (.402 X .787 X .039 ) [ More info ] $5.89 Available to Order: Shipping delay up to 10 days.
#21	8M0161101	SCREW (1 required per assembly)
		10-8M0161101 - SCREW [ More info ] Unavailable
#22	8M0161102	SCREW (1 required per assembly)
		10-8M0161102 - 10-8M0161102 - SCREW [ More info ] Unavailable Replaced by -8M0153724
		10-8M0153724 - SCREW [ More info ] Unavailable
#23	8M0051399	STOPPER (1 required per assembly)
		8M0051399 - Stopper [ More info ] $6.69 Available to Order: Shipping delay up to 10 days.
		17-8M0245322 - STOPPER [ More info ] Unavailable
#24	8M0161100	BUSHING (2 required per assembly)
		23-8M0161100 - BUSHING [ More info ] Unavailable
#25	8M0031370	SPACER (1 required per assembly)
		23-8M0031370 - Bushing [ More info ] $17.83 Available to Order: Shipping delay up to 10 days.
