Parts for 525 EFI 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Fuel Pump & Fuel Cooler

Revise Search: Sterndrive > MerCruiser Engines - Gas > 8.2L (502 Cu In) V8 GM > 525 EFI > 0M956327 - 0M962885 - USA > Fuel Pump & Fuel Cooler

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Fuel Pump & Fuel Cooler

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#-	843073A06	GASKET/SEAL SET - NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing (1 required per assembly)
		27-843073A06 - Engine Overhaul Gasket Set [ More info ] $1,787.87 Available to Order: Shipping delay up to 10 days.
#1	64014	SCREW (4 required per assembly)
		10-64014 - Screw [ More info ] $1.82 Available to Order: Shipping delay up to 10 days.
#2	846673	WASHER (4 required per assembly)
		12-846673 - Washer, (.265 X .500 X .060) Stainless Steel [ More info ] $1.10 Available to Order: Shipping delay up to 10 days.
#3	45176	WASHER @5 (2 required per assembly)
		12-45176 - Washer, (.453 X .812 X .105) [ More info ] $1.50 6 In Stock.
#4	859135	NUT @5 (2 required per assembly)
		11-859135 - Nut (7/16-20), Priced Individually [ More info ] $6.09 2 In Stock.
#5	841981T	BRACKET (1 required per assembly)
		841981T - Bracket [ More info ] $120.85 Available to Order: Shipping delay up to 10 days.
#6	62494	CLIP HOSE SUPPORT (1 required per assembly)
		54-62494 - Clip [ More info ] $7.49 Available to Order: Shipping delay up to 10 days.
#7	856774	WASHER @5 (1 required per assembly)
		12-856774 - Washer, (.406 X .750 X .105) Stainless Steel [ More info ] Unavailable
		128M0214963 - WASHER Note: Priced Individually [ More info ] $2.59 10+ In Stock.
#8	82670912	NUT @5 (1 required per assembly)
		11-826709 12 - Nut, (.375-16) Stainless Steel [ More info ] $6.79 $3.81 10+ In Stock.
#9	807685T3	INSULATOR BASE (1 required per assembly)
		807685T 3 - Insulator [ More info ] $155.32 Available to Order: Shipping delay up to 10 days.
#10	816311T	TIE STRAP @100 (AR required per assembly)
		54-816311T - Tie Strap, 8 Inches, Priced Individually [ More info ] $0.60 10+ In Stock.
#11	897345T59	LINE ASSEMBLY FUEL COOLER TO FILTER (1 required per assembly) — Replaces: 8M0021067
		32-897345T59 - Fuel Line [ More info ] $274.54 Available to Order: Shipping delay up to 10 days.
#12	8M0204683	O RING @10 (2 required per assembly) — Replaces: 805063
		25-8M0204683 - O RING Note: Priced Individually [ More info ] $2.79 Available to Order: Shipping delay up to 10 days.
#13	848183	J CLIP FUEL LINE TO PORT MOUNT (2 required per assembly)
		54-848183 - J Clip [ More info ] $18.69 Available to Order: Shipping delay up to 10 days.
#14	269011	BUMPER @5 (8 required per assembly)
		26901 1 - Bumper [ More info ] $3.99 4 In Stock.
#15	8M0063567	HOSE 58.00 INCH BULK CUT 52.00 INCHES - TO REAR TBI (1 required per assembly) — Replaces: 80617382
		32-8M0063567 - Hose -58 Inch [ More info ] $37.99 Available to Order: Shipping delay up to 10 days.
#16	861126A1	REGULATOR KIT (43 PSI) FUEL PRESSURE (1 required per assembly)
		861126A 1 - Regulator Kit [ More info ] $202.49 $194.49 In Stock
#17	805531	O-RING (.476 X .075) (1 required per assembly)
		25-805531 - O-ring, (.476 X .075) [ More info ] $5.59 Available to Order: Shipping delay up to 10 days.
#18	805406	FILTER FUEL PRESSURE REGULATOR (1 required per assembly)
		35-805406 - Filter [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#19	852368	SCREW (2 required per assembly)
		10-852368 - Screw [ More info ] $1.70 Available to Order: Shipping delay up to 10 days.
#20	36533	WASHER (1 required per assembly)
		12-36533 - Washer [ More info ] $1.50 Available to Order: Shipping delay up to 10 days.
#21	8080021	FITTING (1 required per assembly)
		22-808002 1 - Fitting [ More info ] $81.52 Available to Order: Shipping delay up to 10 days.
#22	848438	GASKET FLARE (1 required per assembly)
		27-848438 - Flair Gasket [ More info ] $4.24 7 In Stock.
#23	8M0125854	COOLER KIT-FUEL (1 required per assembly) — Replaces: 849929A1, 849929A02
		8M0125854 - COOLER KIT-FUEL [ More info ] $563.28 Available to Order: Shipping delay up to 10 days.
#24	8M0119211	PLUG ASSEMBLY (.500-13) BLUE (1 required per assembly) — Replaces: 806608A1, 806608A02
		22-8M0119211 - Drain Plug, Priced Individually, .5 inch x 13 [ More info ] $10.19 10+ In Stock.
#25	831985	O-RING (.468 X .078) (1 required per assembly)
		25-831985 - O-ring, (.468 X .078) [ More info ] $5.29 Available to Order: Shipping delay up to 10 days.
#26	866114	SCREW (.250-28) SPECIAL (1 required per assembly)
		10-866114 - Screw [ More info ] $6.89 Available to Order: Shipping delay up to 10 days.
#27	807783A1	FITTING KIT (1 required per assembly)
		22-807783A 1 - Fitting Kit [ More info ] $42.99 Available to Order: Shipping delay up to 10 days.
#28	8M0204683	O RING @10 (4 required per assembly) — Replaces: 805063
#29	841080T01	PUMP ASSEMBLY FUEL WITH REF NUMBERS 28 AND 31 (1 required per assembly)
		841080T01 - Fuel Pump Assembly [ More info ] $1,043.07 Available to Order: Shipping delay up to 10 days.
#30	808001A1	FITTING ASSY (1 required per assembly)
		22-808001A 1 - Fitting Assembly [ More info ] $34.99 Available to Order: Shipping delay up to 10 days.
#31	805062	O-RING (.530 X .082) (1 required per assembly)
		25-805062 - O-ring, (.530 X .082) [ More info ] $4.19 Available to Order: Shipping delay up to 10 days.
#32	8M0082339	COMPOUND-HEAT TRA HEAT TRANSFER (6 GRAMS) (AR required per assembly) — Replaces: 805701
		92-8M0082339 - 928M0119689 [ More info ] Unavailable
#33	807979T	BRACKET (1 required per assembly)
		807979T - Bracket [ More info ] $114.49 Available to Order: Shipping delay up to 10 days.
#34	29598	NUT @5 (2 required per assembly)
		11-29598 - Nut (1/4-28) [ More info ] $2.89 10+ In Stock.
#35	807930T01	INSULATOR FUEL COOLER COVER (1 required per assembly) — Replaces: 807930
		807930T01 - Insulator [ More info ] $31.79 Available to Order: Shipping delay up to 10 days.
#36	897345T60	LINE ASSEMBLY FUEL SEPERATOR TO PUMP (1 required per assembly) — Replaces: 841146T
		32-897345T60 - Fuel Line [ More info ] $163.12 Available to Order: Shipping delay up to 10 days.
#37	897345T61	LINE ASSEMBLY FUEL REGULATOR TO SEPERATOR (1 required per assembly) — Replaces: 841148T
		32-897345T61 - Fuel Line [ More info ] $174.53 Available to Order: Shipping delay up to 10 days.
#38	34931	WASHER (2 required per assembly)
		12-34931 - Washer, (.406 X .734 X .063 - Stainless Steel) [ More info ] $2.59 10+ In Stock.
#39	34354	SCREW @5 (2 required per assembly)
		10-34354 - Screw - Priced Individually [ More info ] $2.39 10+ In Stock.
#40	34213	GASKET FUEL PUMP (1 required per assembly)
		27-34213 - Gasket, Priced Individually [ More info ] $7.09 3 In Stock.
		18-0889-9 - Gasket 27-34213 2-Pack [ More info ] $5.99 $5.02 2 In Stock.
#41	36382	PLUG - Shipping Protector (1 required per assembly)
		22-36382 - Plug [ More info ] $5.49 Available to Order: Shipping delay up to 10 days.
		18-8111-9 - Pipe Plug, 1/4 Inch, (Pack of 3) [ More info ] $12.29 Available to Order: Shipping delay up to 10 days.
		18-4256 - Plug, 1/4 Inch Brass, Sold Individually [ More info ] $2.46 2 In Stock.
#41	70146	CONNECTOR - Fuel Pump Inlet Hose (1 required per assembly)
		22-70146 - Connector [ More info ] $8.29 Available to Order: Shipping delay up to 10 days.
#42	889275T	PUMP ASSY-FUEL (1 required per assembly)
		889275T - Fuel Pump [ More info ] $235.87 Available to Order: Shipping delay up to 10 days.
#43	43276	ELBOW (1 required per assembly)
		22-43276 - Elbow [ More info ] $19.69 Available to Order: Shipping delay up to 10 days.
#44	56762	TIE STRAP @5 (2 required per assembly)
		56762 - Tie Strap - Priced Individually [ More info ] $0.50 3 In Stock.
#45	8M8023638	TUBING PLASTIC (54 INCHES) CUT 48.00 INCHES (1 required per assembly) — Replaces: 84862872
		32-8M8023638 - Tubing - 54 Inch [ More info ] $135.57 Available to Order: Shipping delay up to 10 days.
#46	841153T	LINE ASSEMBLY FUEL PUMP TO SEPERATOR (1 required per assembly)
		32-841153T - Fuel Line Assembly [ More info ] $46.89 Available to Order: Shipping delay up to 10 days.
#47	802893T	FILTER-FUEL (1 required per assembly)
		35-802893T - Fuel Filter [ More info ] $18.09 7 In Stock.
		18-7945 - Filter, Long Version [ More info ] $8.99 $8.86 Available to Order: Shipping delay up to 10 days.
		18-7944 - Filter, 35-802893Q [ More info ] $8.99 $8.86 10+ In Stock.
		35-802893Q01 - Fuel Filter - Priced Individually [ More info ] $19.79 9 In Stock.
#48	816133	FITTING (1 required per assembly)
		22-816133 - Fitting [ More info ] $13.19 Available to Order: Shipping delay up to 10 days.
#49	8M0204657	PLUG (1 required per assembly) — Replaces: 36373
		228M0204657 - PLUG [ More info ] $5.69 Available to Order: Shipping delay up to 10 days.
#50	841079	CONNECTOR (2 required per assembly)
		22-841079 - Connector [ More info ] $15.58 Available to Order: Shipping delay up to 10 days.
#51	19697	ELBOW (1 required per assembly)
		22-19697 - Elbow [ More info ] $24.19 Available to Order: Shipping delay up to 10 days.
#52	805559	SCREW (2 required per assembly)
		10-805559 - Screw [ More info ] $10.29 Available to Order: Shipping delay up to 10 days.
#53	856774	WASHER @5 (2 required per assembly)
#54	841050	BRACKET FUEL SEPERATOR MOUNT (1 required per assembly)
		841050 - Bracket [ More info ] $126.84 Available to Order: Shipping delay up to 10 days.
#55	8M0042642	WASHER @5 (2 required per assembly) — Replaces: 70132
		12-8M0042642 - Washer - Priced Individually [ More info ] $1.80 6 In Stock.
#56	849377	SCREW (1 required per assembly)
		10-849377 - Screw [ More info ] $15.13 Available to Order: Shipping delay up to 10 days.
#56	843144	SCREW (1 required per assembly)
		10-843144 - Screw [ More info ] $35.27 Available to Order: Shipping delay up to 10 days.
#57	8M0095674	BASE ASY-FUELFLTR (1 required per assembly) — Replaces: 805373005
		8M0095674 - BASE ASY-FUELFLTR [ More info ] $134.49 Available to Order: Shipping delay up to 10 days.
