Parts for 525 EFI 8.2L (502 Cu In) V8 GM MerCruiser Engines - Gas Exhaust Header / Tailpipe Assembly
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #- | 843073A06 | GASKET/SEAL SET - NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing (1 required per assembly) |
  |
|
27-843073A06 - Engine Overhaul Gasket Set [ More info ]
|
| #- | 841178A05 | PARTIAL-525 EFI (1 required per assembly) |
  |
|
841178A05 - Partial Engine Assembly [ More info ] Unavailable |
| #1 | 843933T03 | REF MR SB2010-01 ALSO INCLUDES TAILPIPE GASKET 27-842454 (1 required per assembly) — Replaces: 843933A01, 843933T02 |
  |
|
843933T03 - REF MR SB2010-01 [ More info ] Unavailable |
| #1 | 843934T03 | REF MR SB 2010-01 ALSO INCLUDES TAILPIPE GASKET 27-842454 (1 required per assembly) — Replaces: 843934A01, 843934T02 |
  |
|
843934T03 - REF MR SB 2010-0 [ More info ] Unavailable |
| #2 | 840940 | GASKET EXHAUST HEADER (2 required per assembly) |
  |
|
27-840940 - Exhaust Header Gasket [ More info ]
|
| #3 | 821131 | SCREW (.375-16 X 1.00) (16 required per assembly) |
  |
|
10-821131 - Screw - Priced Individually [ More info ]
|
| #4 | 862210A01 | ELBOW KIT DRAIN (2 required per assembly) |
  |
|
22-862210A01 - Elbow Kit [ More info ]
|
  |
|
18-4224 - Drain Elbow 22-806926A1 [ More info ]
|
| #5 | 8M0119211 | PLUG ASSEMBLY (.500-13) BLUE (2 required per assembly) — Replaces: 806608A1, 806608A02 |
  |
|
22-8M0119211 - Drain Plug, Priced Individually, .5 inch x 13 [ More info ]
|
| #6 | 831985 | O-RING (.468 X .078) (2 required per assembly) |
  |
|
25-831985 - O-ring, (.468 X .078) [ More info ]
|
| #7 | 843384A1 | REF SHS 10-01 - Bravo Models (1 required per assembly) |
  |
|
843384A 1 - REF MR SB 2010-0 [ More info ] Unavailable |
| #7 | 843384A2 | TAILPIPE ASY-STBD - Bravo Models (1 required per assembly) |
  |
|
843384A 2 - Tailpipe Assembly - Stbd [ More info ] Unavailable |
| #8 | 180763 | CLAMP WORM GEAR (4 required per assembly) |
  |
|
54-18076 3 - Clamp [ More info ]
|
| #9 | 8424181 | HOSE MOLDED (2 required per assembly) |
  |
|
32-842418 1 - Molded Hose [ More info ]
|
| #10 | 842454 | GASKET TAILPIPE (2 required per assembly) |
  |
|
27-842454 - Tailpipe Gasket [ More info ]
|
| #11 | 842458 | NUT (312-24) (2 required per assembly) |
  |
11-842458 - Nut, (.250-20) [ More info ] Unavailable |
|
  |
|
11-8M0193946 - NUT [ More info ] Unavailable |
| #12 | 8M0051201 | CLAMP BAND (2 required per assembly) — Replaces: 842456 |
  |
|
548M0051201 - Clamp-BAND [ More info ]
|
| #13 | 842457 | T BOLT (.312-24) (2 required per assembly) |
  |
|
10-842457 - T Bolt [ More info ]
|
| #14 | 842453389 | FITTING RESTRICTOR (.389) STARBOARD (1 required per assembly) |
  |
|
22-842453389 - Fitting [ More info ]
|
| #15 | 842453192 | FITTING RESTRICTOR (.192) STARBOARD (1 required per assembly) |
  |
|
22-842453192 - Fitting [ More info ]
|
| #16 | 842453406 | FITTING RESTRICTOR (.406) PORT (1 required per assembly) |
  |
|
22-842453406 - Fitting [ More info ]
|
| #17 | 842453201 | FITTING RESTRICTOR (.201) PORT (1 required per assembly) |
  |
|
22-842453201 - Fitting [ More info ]
|
| #18 | 180765 | CLAMP (4 required per assembly) |
  |
|
54-18076 5 - Clamp [ More info ]
|
| #19 | 842754 | HOSE MOLDED EXHAUST HEADER TO TAILPIPE (2 required per assembly) |
  |
|
32-842754 - Molded Hose [ More info ]
|
| #20 | 8M0119211 | DRAIN PLUG @5 (2 required per assembly) — Replaces: 806608A1, 806608A02 |
| #21 | 831985 | O-RING (.468 X .078) (2 required per assembly) |
| #22 | 861776A2 | PLATE KIT EXHAUST BLOCKOFF (1 required per assembly) |
  |
|
861776A 2 - Exhaust Plate Kit [ More info ]
|
| #23 | 41471 | LOCKWASHER (.375) (4 required per assembly) |
  |
|
13-41471 - LockWasher [ More info ]
|
| #24 | 8M0113180 | SCREW (.375-16 X 1.00) (4 required per assembly) — Replaces: 98794 |
  |
|
10-8M0113180 - Mouting Screw AL/BRAV TOP Cover, priced individually [ More info ]
|
